47” Class Full HD Capable Monitor LS35A

47” Class Full HD Capable Monitor LS35A

All specs

GENERAL

  • Screen size (inches)

    47

  • Dynamic CR

    500,000:1

  • Panel Technology

    IPS

  • Life Span (hrs)

    50,000

  • Aspect ratio

    16:9

  • Resolution

    1920 x 1080 (FHD)

  • Brightness (cd/m2)

    450

  • Surface Treatment

    Low Haze NRT

  • Contrast ratio

    1200:1

  • Response Time (ms)

    8ms (G to G BW)

  • Viewing angle (°)

    178 x 178

  • Orientation

    Portrait and Landscape

CONNECTIVITY - INPUT

  • Digital

    HDMI(1)

  • Analog

    RGB(1)

  • Audio

    RGB(3.5Ø 1)

  • External control

    RS232C(1), RJ45(1), IR(1)

  • USB

    Yes

CONNECTIVITY - OUTPUT

  • Audio

    Speaker L/R

  • External Control

    RS232C (1)

AUDIO

  • Audio Power

    20W (10W x 2)

  • Balance

    Yes

  • Clear Voice II

    Yes

  • Speaker On/off

    Yes

  • Sound mode

    Standard, Music, Cinema, Sports, Game

SPECIAL FEATURES

  • Temperature Sensor

    Yes

  • Smart Energy Saving

    Yes

  • Key Lock

    Yes

  • DPM Select

    Yes

  • ISM Method

    Normal, White Wash

  • Energy Saving Mode

    Yes (Minimum, Medium, Maxium, Screen off)

  • File Play with USB: PDF

    Yes

  • File Play with USB: Supported Web Services

    Web-page / RSS (Text) / Widget / Streaming A/V

  • File Play with USB: Audio

    MP3 / WMA / WAV

  • File Play with USB: Open Office

    ODT / ODS / ODP (Open Office should be installed to support playback)

  • File Play with USB: Text

    Stationary or Scrolling up / down / left / right

  • File Play with USB: Photo

    JPG / PNG / BMP with 127 transition effects

  • File Play with USB: Video

    AVI / WMV / MP4 / MOV / MKV / TS / TP / MPG / MPEG / FLV Corresponding codecs should be installed to support playback)Yes (Minimum, Medium, Maxium, Screen off)

  • File Play with USB: MS Office

    PPT / PPS / PPTX / XLS / XLSX / DOC / DOCX (MS Office should be installed to support playback)

  • File Play with USB: Flash

    SWF

ENVIROMENT CONDITIONS

  • Operation Temperature

    0°C ~ 40°C

  • Operation Humidity

    10% ~ 80%

STANDARD(CERTIFICATION)

  • Safety

    UL / c-UL / CB / TUV / KC

  • EMC

    FCC Class "A" / CE / KCC

  • ErP / Energy Star

    Yes / Yes (Energy Star 6.0)

SOFTWARE COMPATIBILITY

  • Supersign Elite-wlite

    Yes

  • Supersign Elite-c

    Yes

DIMENSIONS - WXHXD(MM)

  • Monitor

    42.16 x 24.47 x 2.19 inch

  • Color

    Metallic Titan

  • Bezel Width

    Flat Bezel : 0.33inch(L/R/U), 0.55inch(B) [8.5mm(L/R/U), 14mm(B)] ; After Curvature : 0.51inch(L/R/ U), 0.73inch(B) [13.2mm(L/R/U), 18.7mm(B)]

  • Weight (Head)

    26.89 lbs

  • Monitor w/opt stand

    42.16 x 26.57 x 9.72 inch

  • Weight with opt head + stand

    27.55 lbs

  • Monitor w/opt std/spk

    42.16 x 26.57 x 9.72 inch

  • Weight with opt head + stand + speaker

    29.32 lbs

  • Carton

    45.27 x 27.95 x 5.98 inch

  • Packed Weight

    35.05 lbs

  • VESA Compatibility

    400 x 400

POWER

  • Power Supply

    100-240V, 50/60Hz

  • Power Type

    Built-in Power

  • PC - Typical

    80W (Max. 100W)

  • PC - Smart Energy Saving

    65W / 36W

  • PC - DPM

    0.7W(DVI-D, HDMI, DP)

  • PC - Power Off

    0.5W

MEDIA PLAYER COMPATIBILITY

  • External Media player Attachable

    Yes (MP500/MP700)

ACCESSORY

  • Included

    Remote Controller (include battery 2ea), Power Cord, IR Receiver, CD (Owner's Manual, SuperSign Program / Manual), ESG, RGB Cable

  • Optional

    SP-2100, ST-421T, LSW440S(wall bracket)
