In the conference room, there's a large TR3PN installed on the wall, vividly displaying materials for the meeting on the screen.
* All images in this page are for illustrative purposes only.
LG CreateBoard offers a lifelike touch experience, allowing users to interact with content directly on the board. You can write, draw, zoom, and rotate using just your fingers, making it an effective tool for creative projects or presentations. Additionally, LG CreateBoard enables screen and content sharing, making it an excellent tool for seamless collaboration even with remote team members.
In the ideation space of the lecture room, there are two TR3PNs—one mounted on the wall and the other a stand-alone unit. Students freely share their opinions by writing on the TR3PNs.
LG CreateBoard offers a variety of educational templates and tools such as a ruler, table, and sticky note, fostering active student participation and facilitating intuitive lessons.
During class, one person is writing on the TR3PN screen, while another is using a tool from the menu.
LG CreateBoard incorporates straightforward import and export features. Resources can be saved and directly imported to and from Google Drive or OneDrive. After meetings, you can directly send emails to share materials, or scan a QR code to transfer them to your personal device.
Materials utilized during the meeting can be shared through the LG CreateBoard's various functions such as import and export after the meeting.
LG’s proprietary whiteboarding software
A TR3PN is mounted on the wall of the conference room, with the menu bar displayed on the screen.
A variety of tools such as a calculator, clock, and sticky note are available to facilitate smooth
discussions and ensure seamless idea sharing and communication. Also, users can personalize the
menu bar with their most frequently used tools, thereby improving their work efficiency.
When you need a reference during a discussion, you can access various information in real time with the simple click of a web browser. The necessary information found on the internet can be easily dragged and dropped into the material you’re creating, enhancing the productivity of your meetings.
By simply double-tapping the LG CreateBoard screen with 4-5 fingers, an attention sign will pop up with a sound. This feature makes it easy to capture the participants’ attention during moments when you need them to focus.
LG CreateBoard Share offers a wireless screen sharing feature, providing users with a flexible discussion environment. Users can share their screen from their own devices, simplifying the process of sharing and collaborating on team projects or presentation materials.
The materials displayed on the TR3PN screen are wirelessly shared and shown identically on laptops, tablets, and smartphones simultaneously.
* LG CreateBoard also supports app-less sharing for PC (via website) and mobile devices within the same network.
* For a more stable connection, we recommend the installation of a dedicated app (LG CreateBoard Share).
* LG CreateBoard Share app is compatible with Android 5.1 and higher, iOS 12.0 and higher, and MacOS 11.0 and higher.
LG CreateBoard Share establishes a seamless and stable meeting room without the need for extra cables or connections. Presenters can now share their screens without the need to inconveniently move around and unplug and plug cables each time the presenter changes. With the capability to share up to 9 screens in real-time, it’s possible to display multiple people’s materials simultaneously when needed, thereby enhancing the efficiency of collaboration.
Two images are shown side by side for a before-and-after comparison. One image displays multiple cables connected to different devices used for screen sharing. The other image shows a tidy table with screen sharing facilitated wirelessly through the Wireless ScreenShare feature, eliminating the need for multiple cables.
Users can easily utilize the wireless screen sharing feature via LG CreateBoard Share app, and even without the app, they can still conveniently access this feature through the website. A quick connection to LG CreateBoard Share can be established by entering a 6-digit code.
Wireless screen sharing empowers presenters to navigate freely within a meeting room, unencumbered by cables. This feature enables them to seamlessly control their presentations directly from their own devices. In addition, they can conveniently send photos and videos stored on their personal devices, enhancing the fluidity and richness of their presentations.
A presentation is underway in the TR3PN-equipped meeting room, with the presenter seamlessly controlling his materials via wireless screen sharing on his tablet.
In the classroom, the lecturer or presenter doesn’t need to conduct the lesson near the LG CreateBoard, but can flexibly conduct the lesson from anywhere in the classroom. This promotes a more flexible classroom environment and can help keep students more focused.
In the TR3PN-equipped classroom, a presenter conducts a session, managing presentation materials on his tablet via wireless screen sharing while simultaneously sharing content in real-time on other students' devices.
* USB Type-C cables are sold separately.
LG CreateBoard Share supports Secure Mode, which allows users to grant permissions for sharing. This allows users to prevent unauthorized content from being shared.
LG ConnectedCare DMS is a cloud solution for remotely monitoring, controlling, and managing the status of LG CreateBoard and signage displays. This feature enables IT managers to operate and manage important resources on operating devices without physically visiting sites.
IT managers keep a remote watch over LG CreateBoard through LG ConnectedCare DMS.
* ‘LG ConnectedCare DMS’ needs to be purchased separately.
* The availability of the ‘LG ConnectedCare DMS’ service differs by region, so please contact the LG sales representative in your region for more details.
The LG ConnectedCare DMS dashboard allows you to view and monitor multiple devices at the same time, thereby saving time and boosting efficiency.
Five screens available on LG ConnectedCare DMS are currently being displayed.
The LG ConnectedCare DMS enables centralized and simple control of digital signage connected to the system. Frequently used functions such as power on/off, scheduling and screen brightness adjustment can be applied remotely.
The IT manager can remotely control devices in the classroom such as the power on/off, scheduling, brightness, and screen lock functions.
Messages and a range of other content can be sent from the main system to individual devices connected to LG ConnectedCare DMS. Company events or announcements can be broadcasted remotely from the cental system at once.
Company notices are uniformly displayed on screens in the office, lobby, and break areas.
In case of urgent occasions such as a fire or a natural disaster, alert messages can be distributed manually across the system, which help teachers and students to swiftly perceive the situation and promptly take safety action.
When grouping multiple classrooms into one group for management, it showcases the ability to send the same message simultaneously.
LG CreateBoard has received Google certification, enabling users to seamlessly integrate with the Google ecosystem by connecting their Google accounts.
* Exceptions apply in countries without Google services.
Users have access to the Google Play Store, where they can download a wide range of applications, including educationrelated games, tools, and more for an expanded experience.
* Exceptions apply in countries without Google services.
The Screen Lock function allows users to lock and unlock the screen.
Users can lock the screen using the Screen Lock function, and unlock it by entering a password.
This protective measure can be set up in the Settings menu, safeguarding the device from unauthorized access.
USB Lock Mode is a security measure that helps prevent data from being copied to unauthorized devices, which is essential when being used in spaces where security is critical.
Users can set LG CreateBoard to delete files regularly for enhanced security.
In the meeting room, individuals are actively exchanging ideas by writing on the LG CreateBoard screen at the same time.
LG CreateBoard boasts a multi-touch functionality that can concurrently detect up to 50 touch
points. This feature facilitates simultaneous touch and gesture inputs from multiple users, fostering
easy collaboration and idea sharing among team members. This enables efficient interaction in
group activities or meetings.
Logging in with a QR code is easy, saving meeting preparation time and enhancing personal information security. Simply logging out secures the information.
Users can sign up for a variety of apps on the LG CreateBoard including Google Drive and OneDrive
with just one QR verification. After use, users can simply click the Logout button to disconnect,
thereby reducing the risk of personal information leakage.
LG CreateBoard simplifies connectivity via USB-C, easily transmits data, and can charge up to 65W.
USB-C connectivity simplifies connections which enables charging and sending data simultaneously over just one single cable.
* USB Type-C cables are sold separately.
LG CreateBoard is designed with front display ports, making it easy for users to connect or disconnect cables. Additionally, its front-facing speakers facilitate content delivery with improved sound quality.
* Some ports including the power connector, are located on the side and back of the unit.
LG CreateBoard has introduced a flicker-free function. With the reduced flickering of the monitor’s backlight, users can use the device with more comfort even when using it for a long time.
* All sizes of TR3PN models received official certification from TUV Rheinland in February 2024.
LG CreateBoard supports OPS slots, allowing users to conveniently mount OPS Module at the back of the screen without the hassle of connecting to an external desktop. This enables various PC functions and Windows software.
* OPS : Open Pluggable Specification
LG CreateBoard supports a multi-screen mode, allowing users to utilize multiple screens simultaneously. Users can take notes, play videos, and browse the web at the same time, thereby enhancing work efficiency.
* Multi window mode may not work for some apps.
* Picture-in-picture mode is available for the external source screen.
If there is no input for a certain period of time, the device changes to standby mode, and it can be turned on or off automatically by setting the time, thus saving power.
When a device doesn’t receive an external input signal for a specific amount of time set by the user,
the device goes into standby mode. Devices can also be automatically turned on or off at specific
time or day set by the user, which contributes to save energy.
Basic
Power Cord 3 M*1, USB Cable(Type A-Type B) 5 M*1, USB Type-C Cable(C to C) 1.8 M*1, HDMI Cable 3 M*1, Writing Pen*2pcs, User Manual, QSG, Carton Box, Remote Controller(include battery 2ea), Wifi module
Optional
Wall Mount(WM-L000S), Floor Stand(ST-000F / ST-860F)
EMC
FCC Class "A“
ERP / Energy Star
Yes / Yes
Safety
IEC62368, EN62368, GB4943, UL62368
Audio In
Yes(1)
Audio Out
Yes(1)
DP In
Yes(1), HDCP1.3/2.3
HDMI In
Yes(4), HDCP2.3
HDMI Out
Yes(1)
RJ45(LAN) In
Yes(1)
RJ45(LAN) Out
Yes(1)
RS232C In
Yes(1)
Touch USB
USB2.0 Type A(2)
USB In
USB Type C(2), USB3.0 Type A(4), USB2.0 Type A(3)
Bluetooth
Bluetooth 5.0
CPU
Octa-core A76x4 + A55x4
GPU
Mali G52MP2
LAN
Gigabit LAN
Memory(RAM)
8GB
OS ver. (Android)
Android 13(EDLA)
Storage
64GB
Wi-Fi
802.11 a/b/g/n/ac/ax
Accuracy (Typ.)
±1mm
Available Object Size for Touch
Ø2 mm ↑
Interface
USB2.0
Multi Touch Point
Max 50 points
Operating System Support
Windows10/Windows8/Windows7/Android /Linux/Mac OS X/Chrome
Protection Glass Thickness
3.2mm
Protection Glass Transmission
88%
Response Time ('Paint' app on Windows 10 PC)
≤2.5ms
Operation Humidity
10 % to 90 %
Operation Temperature
0 °C to 40 °C
Auto Brightness Sensor
Yes
Internal Memory (eMMC)
64GB
Power Indicator
Yes
Temperature Sensor
Yes
Wi-Fi/BT (Built-in)
Yes (Slot type)
Booting Logo Image
Yes
HDMI-CEC
Yes
Network Ready
Yes (Fast Power On)
OS Ver. (webOS)
Android13(EDLA)
PIP
Yes (1) external source
Screen Share
Yes (CreateBoard Share)
Smart Energy Saving
Yes (Energy Saving)
Wake on LAN
Yes
OSD
English, French, German, Spanish, Italian, Korean , Chinese(Simplified), Chinese(Original), Portugues(Brazil), Swedish, Finnish, Norwegian, Danish, Russian, Portugues(Europe), Dutch, Czech, Greek, Arabic, Polski, Hungary, Romania, Thai, Turkiye, Ukraine, Basque, Catalan, Kazakhstan, Indonesia
Bezel Color
Black
Bezel Width
T/R/L/B : 34.3/15.6/15.6/37mm
Carton Dimensions (W x H x D)
2110 × 225 × 1291mm
Handle
Yes(2)
Monitor Dimensions (W x H x D)
1957 × 1171 × 86mm
Packed Weight
80.1kg
VESA Standard Mount Interface
800x600mm
Weight (Head)
63.5kg
OPS Power Built-in
Yes
OPS Type compatible
Yes
Aspect Ratio
16:9
Back Light Type
Direct
Brightness
400nit (Typ.)
Color Depth (Number of Colors)
10bit(8bit + FRC)
Color Gamut
72% (NTSC)
Contrast Ratio
4,000:1
Dynamic CR
5,000:1
Life time
50,000 Hrs (Min.)
Native Resolution
3840x2160 (UHD)
Operation Hours (Hours/Day)
16/7
Panel Technology
IPS
Portait / Landscape
No / Yes
Refresh Rate
60Hz
Response Time
6.5ms(Typ)
Screen Size (Inch)
86"
Surface Treatment (Haze)
25%
Viewing Angle (H x V)
178 x 178
Power Supply
AC 100-240V~, 50/60Hz
Power Type
Built-In Power
BTU (British Thermal Unit)
1280 BTU/Hr(Typ.), 1945 BTU/Hr(Max)
DPM
0.5W
Max.
530W
Power off
0.5W
Smart Energy Saving (70%)
(TBD)
Typ.
280W
Degree of Protection
Safety Glass
Tempered / Chemical strengthening
Tempered strengthening
Thickness
3.2mm
Connected Care
Yes
Speaker (Built-in)
Yes (18Wx2 + 8Wx2)
