Pixel Configuration
3 in 1
Pixel Pitch (mm)
2.50
Module Resolution (WxH)
128x64
Module Dimensions(WxH,mm)
320x160
Weight per Module (kg)
0.50
Physical Pixel Density (pixels/㎡)
160,000
Flatness of Cabinet (mm)
±1.0
Cabinet material
Al
Service access
Front
Max Brightness (After Calibration, nit)
1,200
Color Temperature (K)
3,200~9,300
Visual Viewing Angle (Horizontal)
160
Visual Viewing Angle (Vertical)
160
Brightness Uniformity(%)
97%
Color Uniformity
±0.003CxCy
Contrast Ratio
5,000:1
Processing Depth (bit)
14 (HDR10, HDR10 Pro)
Power Consumption (W/Cabinet, Max.)
36
Power Consumption (W/Cabinet, Avg.)
12
Power Consumption (W/㎡, Max.)
720
Heat Dissipation (BTU/h/Cabinet, Max.)
123
Heat Dissipation (BTU/h/Cabinet, Avg.)
41
Heat Dissipation (BTU/h/㎡, Max.)
2,457
Power Supply (V)
100 to 240
Frame Rate (Hz)
50 / 60
Refresh Rate (Hz)
1,920
LED Lifetime (Half brightness)
100,000
Operating Temperature(℃)
-30℃ to +45℃
Operating Humidity
10~90%RH
IP rating Front
IP30
IP rating Rear
IP30
Certification
CE, FCC, ETL
Environment
RoHS, REACH
Controller
CVCA
