55TC3CG-H

55” IPS UHD Multi Touch Screen Digital Display with webOS 4.1 Smart Signage Platform, Anti-shatter Glass, Conformal Coating & Embedded Group Manager

FROM
$4,760.00

KEY FEATURES

  • IPS Display with wide viewing angles
  • Multi Touch Screen (Up to 40 points)
  • webOS 4.1 Smart Signage Platform
  • Anti-shatter Glass & Conformal Coating
  • SuperSign CMS, Control/Control+
55” IPS UHD Multi Touch Screen Digital Display with webOS 4.1 Smart Signage Platform, Anti-shatter Glass, Conformal Coating & Embedded Group Manager
$ 4,760.00

Engage your Audience

The 55TC3CG-H offers high touch performance and great color with vivid details that can seen at virtually any angle.
*Image for illustration purposes only.

High Touch Performance

*Image for illustration purposes only.
*Image for illustration purposes only.

Excellent Picture Quality

  • Beautiful Color, Wide View

    LG IPS panel features a wide viewing angle to deliver clear content regardless of where meeting participants are seated.

  • Vivid Details with Ultra HD

    Ultra High Definition resolution allows users to view details even when zooming in on the display, with four times higher definition than Full HD.

Product Reliability

Easy Content Management

*Image for illustration purposes only.
*Image for illustration purposes only.

High Compatibility

DISPLAY

    • Screen Size
    • 55"
    • Panel Technology
    • IPS
    • Back Light Type
    • Edge
    • Aspect Ratio
    • 16:9
    • Native Resolution
    • 3840 x 2160 (UHD)
    • Refresh Rate
    • 60Hz
    • Brightness
    • 350nits (Typ.)
    • Contrast Ratio
    • 1100:1
    • Color gamut
    • NTSC 72%
    • Viewing Angle (H x V)
    • 178° x 178°
    • Response Time
    • 8ms (G to G)
    • Surface Treatment (Haze)
    • 28%
    • Lifetime Operation
    • 50,000 Hrs (min)
    • Operation Hours (Hours/Day)
    • 24/7
    • Orientation
    • Portrait or Landscape

TOUCH PANEL

    • Available object size for touch
    • ≥6mm
    • Reponse Time
    • 10ms
    • Accuracy
    • 2mm ± 0.2mm
    • Interface
    • USB 2.0
    • Protection Glass Thickness
    • 3.2T (Anti-Glare)
    • Protection Glass Transmission
    • 83%
    • Operating System Support
    • Win 8.1, Win 10, Linux (Kernel v3.0 above)
    • Multi touch point
    • Max 40 Points

CONNECTIVITY

    • HDMI
    • Yes (2), HDCP2.2/1.4
    • DP
    • Yes (1), HDCP2.2/1.3
    • RS232C In
    • Yes (1)
    • RJ45 (LAN)
    • Yes (1)
    • IR In
    • Yes (1)
    • USB
    • USB2.0 Type A (2)
    • DP Out
    • Yes (1), Input HDMI1/2/DP/OPS
    • Audio Out
    • Yes (1)
    • Touch USB
    • USB2.0 Type-B (1)
    • Externel Speaker Out
    • Yes (6ohm)
    • RS232C OUT
    • Yes (1)
    • OPS type compatible
    • Yes (Piggyback)

MECHANICAL

    • Bezel Color
    • Black
    • Bezel Width
    • 33.5/33.4/33.4/38 mm
    • Weight
    • 78.0 lbs/34.5kg
    • Shipping Weight
    • 87.7 lbs/39.8kg
    • Monitor Dimension (W x H x D)
    • 50.3 x 29.6 x 1.8 in/1276.4 x 751.9 x 44.9 mm
    • Shipping Dimensions (W x H x D)
    • 55.5 x 34.6 x 8.1 in/1410 x 880 x 207 mm
    • VESATM Standard Mount Interface
    • 300 x 300
    • Power Consumption (Smart Enegy Saving)
    • 74W
    • Power Consumption (DPM / Power Off)
    • Less than 0.5W

HARDWARE FEATURES

    • Internal Memory
    • 8GB (System 4GB + Available 3.6GB)
    • Temperature Sensor
    • Yes
    • Auto Brightness sensor
    • Yes
    • Local Key Operation
    • Yes
    • Operation Temperature
    • 32°F to 104°F/0°C to 40°C
    • Operation Humidity
    • 10% to 80%

SOFTWARE FEATURES

    • webOS Signage
    • Version 4.1
    • Local Contents Scheduling
    • Yes
    • Group Manager
    • Yes
    • USB Plug & Play
    • Yes
    • Fail over
    • Yes
    • Booting Logo Image
    • Yes
    • No Signal Image
    • Yes
    • RS-232C Sync
    • Yes
    • Local Network Sync
    • Yes
    • PIP
    • Yes
    • PBP
    • Yes
    • Video Tag
    • Yes
    • Play via URL
    • Yes
    • Screen Rotation
    • Yes
    • External Input Rotation
    • Yes
    • Gapless Playback
    • Yes
    • Tile Mode Setting
    • Yes
    • Setting Data Cloning
    • Yes
    • SNMP
    • Yes
    • ISM Method
    • Yes
    • Auto Set ID
    • Yes
    • Status Mailing
    • Yes
    • Control Manager
    • Yes
    • Crestron Inside
    • Yes
    • Smart Energy Saving
    • Yes
    • PM mode
    • Yes
    • Wake on LAN
    • Yes
    • HDMI-CEC
    • Yes
    • SI Server Setting
    • Yes
    • webRTC
    • Yes
    • Pro:Idiom
    • Yes

ELECTRICAL

    • Power Supply
    • AC 100-240 V~, 50/60 Hz
    • Power Type
    • Built-In Power
    • Power Consumption (Typ.)
    • 105W
    • Power Consumption (Max.)
    • 145W
    • Power Consumption (Smart Enegy Saving)
    • 74W
    • Power Consumption (DPM / Power Off)
    • Less than 0.5W

CERTIFICATIONS

    • FCC (Regulatory)
    • FCC Class "A" (NRTL)
    • ErP (Environmental)
    • EPA 8.0

LG SOFTWARE & SERVICES*

    • SuperSign CMS
    • Yes
    • SuperSign Control / Control+
    • Yes
    • Signage365Care
    • Yes
    • *
    • LG SuperSign CMS, Control+ and Signage365Care are optional paid Software/Services.

Warranty & Other

    • Standard Warranty
    • 3 Years Parts & Labor
    • UPC
    • 719192641341
    • Basic Accessories
    • Power Cord 1.55 M*1, USB Cable (Type A-Type B) 1.8 M*1, HDMI Cable 3 M*1, User Manual, QSG, Remote Controller (include battery 2ea), RS232C cable, IR Receiver , Magnet Sheet (3ea)
    • Optional Accessories
    • Wall bracket (LSW350B), VESA Adapter (AM-B330S), OPS Kit (KT-OPSF), SP-5200
