47" class (46.96" diagonal) Direct LED Super Narrow Bezel Display

  • 47WV50BR-B

  • Discontinued Product

Key Features

  • IPS Superb Picture Quality / AUTO HIGHER RESOLUTION
  • SLIMMER BEZEL
  • AUTO CALIBRATION
  • 500 nit Display - 24/7 Operation
PANEL
Panel TechnologyIPS
Aspect Ratio16:9
Native Resolution1920 x 1080 (FHD)
Pixels(H x V x 3)6,220,800
Brightness500 cd/m^2
Color Gamut68%
Viewing Angle178°/178°
Color Depth1.06 Billion (10-bit)
Response Time12ms (Typ.)
OrientationPortrait & Landscape
Panel Size47" class (46.96" measured diagonally)
Contrast Ratio (Typ.)1,400:1
Dynamic CR (DCR)500,000:1
Surface TreatmentHard coating(3H), Anti-reflection treatment of the front polarizer (Reflectance < 2%)
SPECIAL FEATURES
Temperature SensorYes
Tile ModeYes
Source SelectionDigital(HDMI/DVI) / DVI / Analog(RGB) / Component/USB
Brightness/Contrast /BacklightYes
Energy SavingYes, Off / Minimum / Medium / Maximum / Screen Off
Position/SizeYes
ISM MethodNormal, Orbiter, Inversion, White wash
AdvancedClear White, Dynamic Contrast, Dynamic Color, Noise Reduction, Gamma, Black Level, Skin color, Digital Noise Reduction
Auto Config/PhaseYes
Language (OSD/USB Playback)Korean, Chinese(Traditional), Chinese(Simplified), Japanese, German, English, French, Portuguese(Brazil), Portuguese(Europe), Spanish, Italian, Russian, Swedish(Sweden), Finnish(Finland), Norwegian(Norway), Danish(Denmark), Dutch(Netherlands), Cheskey(Czech), Greek
Language (CD Manual)Korean, Chinese(Traditional), Chinese(Simplified), Japanese, German, English, French, Portuguese(Brazil), Portuguese(Europe), Spanish, Italian, Russian, Swedish(Sweden), Finnish(Finland), Norwegian(Norway), Danish(Denmark), Dutch(Netherlands), Cheskey(Czech), Greek
Smart Energy SavingYes
Auto Power/Source MemoryYes
Tile mode @ Natural modeYes, Up to 15 x 15
File Play with USBYes
DPM SelectYes (Installation Menu)
Information DisplayModel/Type, Serial Number, S/W Version, IP Address, Homepage
Input LabelYes
TimeClock, On/off Time, Sleep Timer, Power on Delay
VIDEO
Max Input Resolution1920 X 1080@ 60Hz(RGB, HDMI, DVI-D, Display Port)
Rec. Resolution1920 X 1080@ 60Hz(RGB, HDMI, DVI-D, Display Port)
Sync CompatabilitySeparate, Composite, Digital
H-Scanning Freq.30 ~ 83kHz(RGB, HDMI, DVI-D, Display Port)
V-Scanning Freq.56~75Hz(RGB) / 56~60 Hz(HDMI, DVI-D, Display Port)
Pixel Frequency148.5MHz(RGB, HDMI, DVI-D, Display Port)
Video InputRGB, HDMI, DVI-D, AV, Component, Display Port
Color TemperatureWarm/Medium/Cool
Picture modeVivid, Standard, Cinema, Sports, Game
INPUT (Rear)
USBUSB(1)
AudioPC Audio In(1), AV/Component Audio In(RCA, 1)
DigitalDVI-D(1), HDMI(1) with HDCP for all input, Display Port(1)
External ControlRS232C(1), RJ45(1), IR Receiver(1)
AnalogRGB(1), Component(RGB Shared), AV(BNC, 1)
OUTPUT (Rear)
External ControlRS232C(1)
AnalogRGB(1)
DigitalDVI-D(1)
AudioExternal speaker(1)
AUDIO
Sound ModeStandard, Music, Cinema, Sports, Game
Speaker on/offYes
BalanceYes
Clear Voice IIYes
Audio Power20W (10W x 2)
CABINET
ColorBlack
Monitor Dimensions41.1” x 23.2” x 3.5”
Monitor Weight40.8 lbs.
Carton Dimensions 46.5” x 30.3” x 6.5”
Packed Weight51.8 lbs.
Bezel Width3.2mm (left/top) / 1.7mm (right/bottom)
HandleYes
VESA™ Standard Mount Interface600mm x 400mm
ACCESSORIES
AccessoriesRemote Controller, Power cable, DVI Cable, Manual, IR Receiver, RS-232C Cable, Guide Bracket, Screw
POWER
Power Supply100–240V~, 50/60Hz
Power TypeBuilt-in Power
Power Consumption-DPM0.7W
Power Consumption-Typical150W
Power Consumption-Smart Energy Saving On80W
Power Consumption-Power Off0.5W
STANDARD CERTIFICATIONS
SafetyUL / cUL / CB / TUV / KC
EMCFCC Class "B" / CE / KCC
Erp/Energy Star ENERGY STAR® Qualified
MEDIA PLAYER COMPATIBILITY
External Media Player AttachableYes
ENVIRONMENT CONDITIONS
Operation Temperature0 °C to 40 °C
Operation Humidity10%~90%
UPC
UPC7 19192 19268 3
WARRANTY
WARRANTY3-Year Limited Warranty (Parts/Labor/Backlight)
