86UH5E-B
86'' 500 nits 120 Hz UHD Signage
  • Brightness(Typ.) : 500 cd/m²
  • Bezel : 14.3 mm (Even, Off-Bezel)
  • Depth : 60.6 mm (without Handle and Logo)
  • Interface : HDMI(3)/DP/DVI-D/USB 2.0(2)/ RS232C/ RJ45/ Audio/ IR
  • Built-in Speaker(10W+10W)

component-OBScountrySelectDesc

86" 500 nits 120 Hz UHD Signage
  • Superior Picture Quality

    Superior Picture Quality1 Superior Picture Quality2
  • True Color, Immersive View

    The UH5E series is large enough to display content and get undivided attention from various viewers. LG IPS panel features a wide range of angle to deliver clear content regardless of the position of viewers. Each pixel in the IPS panel reproduces image colors true-to-life, without distortion.

  • Vivid Color Details with Ultra HD

    The UHD resolution allows users to view details even when zooming in on the display, with four times higher definition than FHD. The UH5E ensures stable UHD video playback with HEVC(High Efficiency Video Coding).

1) One master display can create a max. of 25 groups, and each group can consist of a max. of 12 slave display.
* The availability of "Signage 365 Care" service can differ by region,
so please contact the LG sales representative in your region for
further details.
1) Network-based control
1) The integrated control of the display and Cisco system is enabled
through the HDMI cable connection.
1) Except 98"

ACCESSORY

  • Included:
    Remote Controller(include battery 2ea), Power Cord, RS232C cable, Lan cable, DP cable, IR Receiver, Guide Bracket, Screws, Manual
    Optional
    OPS Kit (KT-OPSF), Wall Mount (LSW640A/B)

CERTIFICATION

  • EMC
    FCC Class "A" / CE / KC
    ErP / Energy Star
    Yes
  • Safety
    CB / NRTL

CONNECTIVITY

  • External Control
    RS232C In/out (4 Pin Phone-Jack), RJ45 (LAN) In, IR In
    Input
    HDMI (3), DP, DVI-D, Audio, USB 2.0 (2)
  • Output
    DP, Audio (Off/Fixed/Variable)

ENVIRONMENT CONDITIONS

  • Operation Humidity
    10 % to 80 %
    Operation Temperature
    0°C to 40°C

MECHANICAL SPECIFICATION

  • Bezel Width
    14.3 mm (Even) * Off-Bezel
    Carton Dimensions (W × H × D)
    2,073 x 1,260 x 292 mm
  • Monitor Dimension (W × H × D)
    1,926.2 x 1,097.2 x 60.6 mm (without Handle and Logo)
    Packed Weight
    61.1 kg
  • VESA™ Standard Mount Interface
    600 x 400 mm
    Weight (Head)
    49 kg

MEDIA PLAYER COMPATIBILITY

  • OPS Type Compatible
    Yes

PANEL

  • Aspect Ratio
    16 : 9
    Brightness (Typ., cd/m²)
    500
  • Resolution
    3,840 x 2,160 (UHD)
    Screen Size
    86"

POWER

  • Power Supply
    100-240V~, 50/60Hz
    Power Type
    Built-In Power

POWER CONSUMPTION

  • Smart Energy Saving
    151 W
    Typ. / Max.
    215 W / 280 W

SOFTWARE COMPATIBILITY

  • Content Management Software
    SuperSign CMS
    Control and Monitoring Software
    SuperSign Control/Control+
