Model name
LSBB015-GD
Frame Rate (Hz)
50 / 60
Power Consumption (W/Cabinet, Avg.)
40
Power Consumption (W/Cabinet, Max.)
120
Power Consumption (W/㎡, Max.)
600
Power Supply (V)
AC 100-240 V (50-60 Hz)
IP rating Front
IP5X
IP rating Rear
IP5X
LED Lifetime (Half brightness)
100,000
Operating Humidity
10-80% RH
Operating Temperature(℃)
-20 to +40
Brightness Uniformity(%)
97
Color Temperature (K)
3,200-9,300
Color Uniformity
±0.003 Cx,Cy
Contrast Ratio
5,000 : 1
Max. Brightness (After Calibration)
600
Processing Depth (bit)
16 (HDR10, HDR10 Pro)
Visual Viewing Angle (Horizontal)
160
Visual Viewing Angle (Vertical)
140
Cabinet material
Die Casting Aluminum
Cabinet Dimensions (W x H x D, mm)
600 × 337.5 × 56
Cabinet Resolution (WxH)
384 × 216
Cabinet Surface Area (㎡)
0.203
Flatness of Cabinet (mm)
0.5
Module Dimensions(WxH,mm)
150 × 337.5
Module Resolution (WxH)
96 × 216
No. of Modules per Cabinet (WxH)
4 × 1
Physical Pixel Density (pixels/㎡)
409,600
Pixel Configuration
3 in 1 SMD
Pixel Pitch (mm)
1.563
Service access
Front
Weight per Cabinet (kg/unit)
6.0
Weight per Module (kg)
0.50
Weight per Square Meter (kg/㎡)
30.0
