KEY FEATURES

  • Brightness 300nit
  • Buit-in TV Tuner
  • Built-in Speaker
55" class (54.64" diagonal) TV tuner built-in Digital Signage

PANEL

    • Panel Technology
    • Slim Direct LED
    • Panel Size (Measured Diagonally)
    • 55” Class(54.64”)
    • Response Time
    • 8 ms (G to G)
    • Native Resolution
    • 1920x1080 (FHD)
    • Brightness
    • 230 cd/m2
    • Static (Panel) Contrast Ratio
    • 1,200:1
    • Dynamic Contrast Ratio (Dynamic MCI (Hz))
    • 2,000,000:1
    • Frame Rate
    • 60Hz
    • Viewing Angle(HxV)
    • 178° x 178°

BROADCASTING SYSTEM

    • Analog
    • Yes (NTSC)
    • Digital
    • Yes (ATSC/Clear QAM/VSB)

AUDIO

    • Audio Output
    • 10W + 10W
    • Speaker System
    • 2.0 ch
    • Sound Mode
    • Yes (6 Modes: Standard, News, Music, Cinema, Sport, Game)
    • Optical Sound Sync
    • Yes
    • Clear Voice II
    • Yes
    • Invisible Speaker
    • Yes

VIDEO

    • Triple XD Engine
    • Yes
    • Dynamic Color Enhancer
    • Yes
    • Aspect Ratio
    • Yes, 6 Modes (16:9, Just scan, Set by program, 4:4, Zoom, Cinema zoom1)
    • Real Cinema 24p (3:3 pull down)
    • Yes

INTERFACE (Side)

    • USB (2.0)
    • 2 Side
    • HDMI In
    • 1 Side

INTERFACE (Rear)

    • Digital Audio Out (Coaxial / Optical)
    • 1 (Optical)
    • RS-232C (D-Sub 9pin)
    • 1 (Control & Service)
    • PC Audio Input
    • 1(Share with component audio input)
    • AV In
    • 1 (Sharing with Component in)
    • RGB In (D-sub 15pin) - PC
    • 1 Rear
    • RF In
    • 1 Rear
    • Component in (Y,Pb,Pr) + Audio
    • 1 (5)
    • External Speaker Out
    • 1 Rear (Variable/Fixed/Line Out, 3.5mm, Stereo, Single ended Type(GRD,L+,R+), 1W with 8Ω), Digital Opitical
    • HDMI/HDCP Input
    • 1 Rear

POWER

    • Stand-by
    • 0.5W↓
    • Watts (typical)
    • 52.7W
    • Power Source
    • 110 ~ 240V, 50/60Hz

SPECIAL FEATURES

    • Digital Signage CMS
    • Yes (SuperSign lite)
    • IR Out
    • Yes (RS232C)
    • Remote Diagnosis
    • Yes (USB)
    • HTNG-CEC
    • Yes (1.3)
    • Welcome Screen (Splash Image)
    • Yes
    • HDMI-CEC
    • Yes
    • Multi IR Code
    • Yes
    • Lock Mode
    • Yes
    • Motion Eye Care (Intelligent Sensor)
    • Yes
    • USB Auto Play Back
    • Yes
    • USB
    • Yes (USB 2.0)
    • External Speaker Out
    • Yes (Ext Variable/Fixed, 3.5mm, Stereo, Single ended Type(GND,L+,R+), 1W with 8Ω)
    • Audio Codec
    • MP3, AC3, MPEG, AAC,HEAAC, CDDA, LPCM
    • RJP Compatibility
    • Yes, LG/Teleadapt (RS232C), Teleadapt/Guestlink (HDMI CEC)
    • One Channel Map/ Logical Channel Map
    • Yes
    • Smart Energy Saving
    • Yes
    • USB Cloning
    • Yes
    • MHL
    • Yes
    • Kensington Lock
    • Yes
    • Auto Off / Auto Sleep
    • Yes / Yes
    • RJP Interface
    • Yes (RS232C, HDMI CEC)
    • Hotel Mode/ PDM /Installer Menu
    • Yes
    • Picture
    • JPEG
    • Moving Picture Playback (SD/HD/Plus HD)
    • Divx HD

CABINET

    • Bezel Width (on Bezel) (mm)
    • 11mm/11mm/16.5mm
    • Bezel Width (off Bezel) (mm)
    • 8.5mm/8.5mm/14mm
    • Dimensions with stand(WxHxD)
    • 48.9" X 30.4" X 9.7"
    • Weight (with stand)
    • 39.0 Ibs
    • Dimensions without stand (WxHxD)
    • 48.9” x 28.5” x 2.2”
    • Weight (without stand)
    • 38.1 lbs
    • Carton
    • 52.4” x 31.9” x 6.9”
    • Weight (with carton)
    • 48.7 Ibs
    • VESA™ Standard Mount Interface
    • 400mm x 400mm
    • Flame Retardent
    • Yes
    • Color
    • Dark Titan

ACCESSORIES

    • Cable
    • Power cord (1.5m, Angle Type)

REQUIRED LISTING (Certification)

    • RoHS Compliant
    • Yes
    • Safety
    • cUL, UL, FCC, NOM
    • Energy Star 6.1
    • Yes

UPC

    • 55LY540S
    • 7 19192 91621 0

WARRANTY

    • Warranty
    • 2 Year Limited Warranty (Parts/Labor)
