KEY FEATURES

  • Enhanced Performance Warranty
  • High Power Output
  • Double-sided Generation
High Efficiency LG NeON® 2 BiFacial Module Cells: 6 x 12 Module efficiency 18.5% Connector Type: MC4
$
    VDE Logo

    VDE

    Photovoltaic Modules Logo

    Photovoltaic Modules

    Intertek-ETL Logo

    Intertek-ETL

    CE Logo

    CE

  • Enhanced Performance Warranty

    LG NeON® 2 BiFacial has an enhanced
    performance warranty.
    LG NeON® 2 BiFacial is guaranteed at least
    86% of initial performance.

  • Bifacial Energy Yield

    LG NeON® 2 BiFacial modules use highly
    efficient bifacial solar cell, “NeON” applied Cello
    technology. Through the Cello technology,
    LG NeON® 2 BiFacial can achieve up to 30 more
    energy than standard PV module.

  • Better Performance
    on a Sunny Day

    LG NeON® 2 BiFacial now performs better on
    sunny days thanks to its improved temperature
    coefficient.

  • More Generation
    on a Cloudy Day

    LG NeON® 2 BiFacial gives good performance
    even on a cloudy day due to its low energy
    reduction in weak sunlight.

  • BOS (Balance Of System) Saving

    LG NeON® 2 BiFacial can reduce the total number
    of strings due to its high module
    efficiency resulting in a more cost effective and
    efficient solar power system.

  • Near Zero LID
    (Light Induced Degradation)

    The n-type cells used in LG NeON® 2 BiFacial
    have almost no boron, which may cause the
    initial efficiency to drop, leading to less LID.

CERTIFICATIONS & WARRANTY

    • Certifications
    • UL 1703,IEC 61215, IEC 61730-1/-2,IEC 61701 (Salt mist corrosion test),IEC 62716 (Ammonia corrosion test),;ISO 9001
    • Module Fire Performance
    • Type 1(UL 1703)
    • Fire Resistance Class
    • Class C (ULC/ORD C1703, IEC 61730)
    • Product Warranty
    • 25 Years
    • Output Warranty of Pmax
    • Linear warranty*
    • *
    • 1) 1st year: 98%, 2) After 1st year: 0.5% annual degradation, 3) 86% for 25 years

ELECTRICAL PROPERTIES(NOCT*)

    • Maximum Power(Pmax)
    • 289
    • MPP Voltage (Vmpp)
    • 38.3
    • MPP Current (Impp)
    • 7.54
    • Open Circuit Voltage (Voc)
    • 45.9
    • Short Circuit Current (Isc)
    • 8.17
    • *
    • NOCT (Nominal Operating Cell Temperature): Irradiance 800 W/m2, ambient temperature 20 °C,<br>wind speed 1 m/s

Electrical Properties (STC*)

    • MPP Voltage (Vmpp)
    • 41.4
    • MPP Current (Impp)
    • 9.43
    • Open Circuit Voltage (Voc)
    • 49.2
    • Short Circuit Current (Isc)
    • 10.15
    • Module Efficiency (%)
    • 18.5
    • Operating Temperature (°C)
    • -40 ~ +90
    • Maximum System Voltage (V)
    • 1,500(UL) / 1,000(IEC)
    • Maximum Series Fuse Rating (A)
    • 20
    • Power Tolerance (%)
    • 0 ~ +3
    • *
    • STC (Standard Test Condition): Irradiance 1000 W/m2, module temperature 25 °C, AM 1.5 / The nameplate power output is measured and determined by LG Electronics at its sole and absolute discretion.
    • Pmax Bifaciality Coefficient*** [%]
    • 76
    • <br>
    • The nameplate power output is measured and determined by LG Electronics at its sole and absolute discretion.
    • **
    • Bifacial Gain: The additional gain from the back side compared to the power of the front side at the standard test condition. It depends on installation condition.
    • ***
    • Pmax Bifaciality Coefficient 25years warranty based on front output warranty. tolerance±7%

MECHANICAL PROPERTIES

    • Cells
    • 6 x 12
    • Cell Type
    • Monocrystalline / N-type
    • Cell Dimensions
    • 161.7 x 161.7 mm / 6 inches
    • # of Busbar
    • 12(Multi Wire Busbar)
    • Dimensions (L x W x H)
    • 2,064 x 1,024 x 40 mm / 81.26 x 40.31 x 1.57 in
    • Front Load
    • 5,400 Pa / 113 psf*
    • Rear Load
    • 4,300 Pa / 90 psf*
    • Weight
    • 22.0 kg / 48.72 lb
    • Connector Type
    • MC4 (MC), PV-JM601A (JMTHY)
    • Junction Box
    • IP68 with 3 Bypass Diodes
    • Frame
    • Anodized aluminium
    • Glass
    • Tempered Glass with AR Coating
    • *
    • Please refer to the installation manual for the details
    • Cables
    • 1,200 mm x 2 ea / 47.24 in x 2 ea

Temperature Characteristics

    • NOCT
    • 45 ± 3
    • Pmpp
    • 0.0036
    • Voc
    • -0.0027
    • Isc
    • 0.03 %/°C
    • Pmax [%/°C]
    • -0.36
