49” class (48.5” diagonal) 49LV340C Essential Commercial TV Functionality

  • 49LV340C

Key Features

  • Public Display Mode
  • USB Cloning
  • USB Auto Playback +
  • RS-232C
  • WOL(Wake on LAN)
  • Crestron Connected Certification

Public Display Mode

From channel selection to volume level, you can control the TV settings in public areas. Public Display Mode also enables you to restore default settings, as required, on the TVs.

RS-232C Control

Via the TV's RS-232C port, you can remotely control power and volume settings simultaneously.

WOL (Wake on LAN)

WOL (Wake on LAN) helps you remotely turn on TVs over the internet. Connect TVs and a PC in the same network, and send Magic Packet program to the MAC addresses of registered TVs. Then, it will wake up the TVs via LAN port.

Lock Mode

Lock Mode blocks external input signals with non-compliant content. This is a useful feature for preventing misuse of TVs in various facilities or public spaces.

Self Diagnosis

Self Diagnosis enables engineers and IT to engineers to analyze the data and identify technical issues quickly and easily through a USB memory device.

USB Auto Playback+

Create a media playlist of your choosing (video, music, and/or images) via USB Auto Playback+. Save it to a USB memory device, and then simply connect the USB memory device to the TV to stream your playlist sequentially.

SuperSignTM C

With SuperSign C, LG's signage management software, you can control and remotely monitor via the LAN port

Welcome Screen (Splash Image)

Display a customized greeting message with your business name/logo on the TV when it is turned on.

USB Cloning

Clone your LV340C's with efficiency and ease. The USB Cloning feature allows you to simply copy the TV settings to all the LV340C's using a USB memory device (sold separately).

DISPLAY
Diagonal Size48.5"
TypeDirect LED
Resolution1,920 x 1,080 (FHD)
Brightness400cd/m2
Viewing Angle Degree178° / 178°
Response Time (G to G)9
Frame Rate60 Hz
BROADCASTING SYSTEM
AnalogNTSC
DigitalATSC / VSB / Clear QAM
VIDEO
Triple XD EngineYes
Real Cinema 24p (3:3 pull down)Yes
Dynamic Color EnhancerYes
Aspect Ratio6 modes (16:9, Just Scan, Set by Program, 4:3, Zoom, Cinema Zoom1)
AUDIO
Audio Output / Speaker System10W + 10W / 2.0 ch
Sound Mode6 modes (Standard, News, Music, Cinema, Sport, Game)
Optical Sound SyncYes
Clear VoiceYes
GENERAL FEATURES
InstallationUSB Cloning
ManagementWOL (Wake On LAN), SNMP, USB Diagnostics, Multi IR Code, HTNG/HDMI-CEC
USBUSB Auto playback+, Moving Picture Playback (.asf, .wmv, .divx, .avi, .mp4, .m4v, .mov, .mpg, .mpeg, .mpe, etc.), Picture (jpeg, jpg, jpe, BMP, PNG), Audio Codec (MP3, AAC, M4A, WMA, WMA 10 pro, OGG)
Setting OptionAuto Off / Sleep Timer, Smart Energy Saving, Motion Eye Care
HOSPITALITY FEATURES
YesPDM (Public Display Mode), Lock Mode, Welcome Screen (Splash Image), Insert Image, External Speaker Out, RJP Compatibility, Crestron® Connected Certified, Time Scheduler
INTERFACE
SideHDMI In, USB 2.0
RearRF In, AV In (Sharing with Component In), Component In + Video, Optical Video Audio Out, HDMI/HDCP In, RGB In, PC Audio Input (Sharing with Component Audio), RS-232C In, RJ45 (SNMP), External Speaker Out
DIMENSION
Bezel Width (L/R, U, B) : on bezel based (mm)10, 10, 15.2
Bezel Width (L/R, U, B) : off bezel based (mm)8.5, 8.5, 13.7
Vesa (mm)300 x 300
WxHxD / weight (with stand)43.6" x 27.6" x 9.3" / 25.2lb
WxHxD / weight (Carton)47.0" x 30.3" x 6.2" / 29.8lb
POWER
Voltage, Hz100 ~ 240V, 50/60Hz
Typical (Watts)37.0
Stand-by (Watts)0.5
STANDARD APPROVAL
SafetyUL
EnvironmentFCC
Etc.RoHS, UL, NOM, ENERGY STAR® Qualified
UPC
49LV340C719192611832
