65" Class (64.8"/1646mm diagonal) LX540S TV Tuner Built-In Digital Signage

  • 65LX540S

Key Features

  • INSTANT MESSAGE DELIVERY
  • ALL-IN-ONE DIGITAL SIGNAGE SOLUTION
  • SIMPLE CONNECTION
  • EMBEDDED SUPERSIGN W-LITE SOFTWARE
<span>DELIVER YOUR MESSAGES WHILE BROADCASTING LIVE CHANNELS SIMULTANEOUSLY.</span>

DELIVER YOUR MESSAGES WHILE BROADCASTING LIVE CHANNELS SIMULTANEOUSLY.

AN AFFORDABLE ALL-IN-ONE DISPLAY SOLUTION

No need to purchase any additional hardware or software.

AN AFFORDABLE <span>ALL-IN-ONE DISPLAY SOLUTION</span>
<span>SIMPLE CONNECTIVITY </span>

SIMPLE CONNECTIVITY

Needs only a power, LAN connection and a USB to operate.

FREE SUPERSIGN LITE SOFTWARE

1. 74 pre-installed templates for multiple verticals 2. Schedule your messages to show on all or on specific TV's, at the times you choose. 3. Remotely control maximum 50 TVs over the network

FREE SUPERSIGN LITE SOFTWARE<!--74 Free Template-->
HOW TO USE SUPERSIGN TV - Option 1.<span> As a stand-alone use</span>

HOW TO USE SUPERSIGN TV - Option 1. As a stand-alone use

1. Create & schedule your content 2. Export the content onto a USB 3. Plug & Play USB on SuperSign TV

HOW TO USE SUPERSIGN TV - Option 2. Networked TVs

1. Create & schedule your content 2. Transfer the content to SuperSign TVs through the network. A maximum of 50 TVs can be operated.

HOW TO USE SUPERSIGN TV - Option 2. <span>Networked TVs</span>

Visit our SuperSign Software Center for all the latest software needs

Click here to download SuperSign Software

PANEL
Panel Size65" Class (64.8"/1646mm diagonal)
Backlight TypeLED (Edge)
Panel TechnologyIPS
Static Panel Contrast Ratio1,400:1
Frame Rate240Hz
Response Time (G to G)8 ms
Brightness350cd/m2
Viewing Angle178°/178°
Dynamic Contrast Ratio1,000,000 : 1
BROADCASTING SYSTEM
AnalogNTSC
DigitalATSC, Clear QAM/VSB
AUDIO
Audio Output10W + 10W
Clear VoiceYes
Sound Mode6 modes (16:9, Just Scan, Set by Program, 4:3, Zoom, Cinema Zoom1)
Sound System2.0 ch
Sound Optimizer3 modes (Normal, Wall-Mount Type, Stand Type)
INTERFACE (Side)
USB2 (2.0)
HDMI In1
INTERFACE (Rear)
RF In1
RGB In1 (D-sub 15pin)
AV In (Composite)1 (Sharing with Component In)
Digital Audio Out1 (Optical)
PC Audio Input1 (Sharing with Component in)
HDMI In1
LAN1 (RJ45)
RS-232C1 (D-sub 9pin)
Component In1 (Y, Pb,Pr) + Audio(L/R)
External Speaker Out1 (3.5mm Phone Jack)
CABINET
VESA™ Mount300mm x 300mm
WxHxD (carton)60.9”x38.2”x6.3”
WxHxD (w/o stand)57.5”x33.4”x1.5”
Weight75.0 lbs
WxHxD (with stand)57.5”x35.4”x11.6”
Depth39mm
Bezel Off (L/R, T, B) (mm)13.6, 12.6, 19.3
Bezel On (L/R, T, B) (mm)16.1, 15.1, 21.8
Weight (with carton)90.4 lbs
VIDEO
Resolution1920 x 1080 (FHD)
Triple XD EngineYes
Aspect Ratio6 modes (16:9, Just Scan, Set by Program, 4:3, Zoom, Cinema Zoom1)
ACCESSORIES
CablePower Cord
Manual/ESGSimple Book
POWER
Typical59.9W
Voltage100 ~ 240V, 50/60Hz
Stand-by0.5W↓
SPECIAL FEATURES
SuperSign Lite (3.0)Yes
RTC (Real Time Clock)Yes
USB Auto Play BackYes
Remote Diagnosis/ Self DiagnosisUSB
Welcome ScreenYes (Splash Image)
Wi-FiWi-Fi Dongle Ready
Public Display ModeYes
IR OutRS-232C
HTNG-CECYes
HDMI-CECYes (without ARC)
Multi IR CodeYes
Lock ModeYes
External Speaker OutYes (Variable/Fixed/Line Out, 3.5mm, Stereo, Single Ended Type (GND, L+, R+), 1W with 8Ω)
Audio Codecmp3, AAC, M4A, OGG, WMA, WMA 10 Pro
RJP CompatibilityYes, LG/Teleadapt (RS232C), Teleadapt/Guestlink (HDMI CEC)
Smart Energy SavingYes
USB CloningYes
Kensington LockStand
Auto Off / Auto SleepYes
RJP InterfaceRS232C, HDMI CEC
Moving Picture Playback (SD/HD/Plus HD)asf, wmv, 3gp, 3gp2, divx, avi, mp4, m4v, mov, mkv, ts, trp, tp, mts, m2ts, vob, mpg, mpeg, mpe
Picturejpeg, jpg, jpe, BMP, PNG
CERTIFICATION (STANDARD)
SafetyUL, FCC
Energy Star® 7.0Yes
EnvironmentRoHS, cUL, NOM
WARRANTY
Warranty2-Year Limited Warranty (Parts and Labor) | Extended Warranties Available
OPTIONAL ACCESSORIES
AN-WF500 (Wi-Fi Dongle)Yes
OTHER
UPC7 19192 19701 5
