10" class (10.1" diagonal) Small Display for SM3TB Series

  • 10SM3TB

Key Features

  • POE & LOW POWER CONSUMPTION
  • BUILT-IN TOUCH
  • SUPPORT FOR ANDROID ENVIRONMENT
  • 5.9GB Internal Memory + SD Card
POE & LOW POWER CONSUMPTION

POE & LOW POWER CONSUMPTION

PoE* allows the installer to connect the power and network using just one wire. This greatly simplifies the installation and maintenance processes in locations where adding a power outlet is expensive or prohibited.

BUILT-IN TOUCH

Interactive process between users and displays with builtin touch, creates informative and lively user experience.

BUILT-IN TOUCH
SUPPORT FOR ANDROID ENVIRONMENT

SUPPORT FOR ANDROID ENVIRONMENT

The application which can be operated on the screen with customers can be developed and used based on Android OS.

5.9GB Internal Memory + SD Card

With 5.9GB of internal memory and an additional SD card slot, you can play a sufficient amount of content within the internal memory or additional storage.

5.9GB Internal Memory + SD Card
PANEL
Screen Size10 (10.1")
Panel TechnologyADS
Aspect Ratio16 : 9
Native Resolution1,280 x 800 (HD)
BrightnessModule : 450cd/m2, SET : 400cd/m2 (W/Touch)
Contrast Ratio900 : 1
Dynamic CRNo
Viewing Angle (H x V)160 x 160
Surface TreatmentHard Coating, 2H, Low Reflection (Front Polarizer)
Guaranteed Operating Hour16 Hours
OrientationPortrait & Landscape
CONNECTIVITY
InputUSB, SD Card
OutputNo
External ControlRJ45
CABINET
Bezel ColorBlack
Bezel Width14mm (Top / Right / Left / Bottom)
(W x H x D)9.7" x 6.5" x 1.2"
Weight1.4lbs
Carton (WxHxD)12.9” x 8.8” x 3.7”
Carton Weight2.3lbs
VESA™ Compatible50mm x 50mm
SPECIAL FEATURES
Special FeaturesKey Operation (Home, Power Key Operation), DPM Select, File Play with USB, Wi-Fi Built-in, Local Time Auto Setting, Wake on LAN, Password Change, BEACON, Internal Memory (System 0.15GB + Free 5.7GB), K-Slot
ENVIRONMENT CONDITIONS
Operating Temperature Range32 °F to 104 °F
Operating Humidity Range10 % to 90 %
POWER
Power Supply100-240V~, 50/60Hz
Power TypeBuilt-in Power, Adaptor
Power SwitchPower/Home
AUDIO
Audio Power1W (1W x 1Ch) for Internal Speaker
WARRANTY
Warranty3-Year Limited Warranty Parts/Labor/Backlight | Extended warranty options are also available
OTHER
UPC7 19192 19852 4
ACCESSORIES
BasicAdaptor, Manual (Web), ESG
OptionalNo
