49VM5C

49” class (48.50” diagonal) - Ultra-Narrow Bezel Video Wall

MSRP
$3,625.00

KEY FEATURES

  • Narrow Bezel
  • Built-in SoC* and Synced Playback
  • webOS 2.0
  • Clear Viewing Angle
  • Uniform Brightness
49” class (48.50” diagonal) - Ultra-Narrow Bezel Video Wall
$ 3,625.00



With their slim bezels and virtually borderless designs, 49VM5C video walls offer maximum immersion. Their quad-core SoC system plays various types of content without the need for an external media player, with easy and efficient management tools. These video walls have been designed to raise engagement in areas such as museums, airports, galleries and large retail spaces.

Narrow Bezel

Borderless design with its 0.9mm even panel bezel* and 1.8mm BtB(Bezel to Bezel)** size, verified by Nemko***, enables immersive and near seamless viewing experiences on assembled video wall screens.

*Panel Bezel : The black matrix section where an image is not displayed on the front panel. **BtB (Bezel to Bezel) : Panel Bezel + Panel Bezel (Borderless type, no metal bezel)

***Nemko (Nogerois Elektriske Materiellkontroll) was established in 1933 as an institution for mandatory safety testing and national approval of electrical equipment to be marketed and sold in Norway. Since it was transformed into independent, self-owned foundation in 1991, it has provided worldwide testing and certification.

Built-in SoC* and Synced Playback

The optimized built-in quad-core SoC in the 49VM5C can play various content formats and eliminates the need for an external media player. Using its built-in SoC, each display plays its video tile without lag for synchronized content playback.
*System-on-Chip

webOS 2.0

The webOS 2.0 platform provides easy and convenient tools to create contents. LG’s SDK* and technical supports make content development and management easier.

Clear Viewing Angle

The 55VH7B, 55VM5B and 49VM5C ensure clear picture quality, even when installed in arrays of more than four, ideal for installations in large spaces.

*The angle from the center of the screen to have 50 of the initial luminance.

Uniform Brightness

LG’s LED backlight technology provides high uniformity in brightness to ensure a clear picture. On other screens, certain spots may appear darker than others, but the 49VM5C generates high visibility and a consistent brightness across the whole screen.

Video Wall Image Creation

Through Video Wall Image Creation (VIC) technology; color and brightness differences are compensated for by an algorithm within the circuitry that gives the panels the same characteristics, enabling the video wall to maintain a consistent white balance from panel-to-panel.

Image Gap Reduction

The 49VM5C includes an image-improvement algorithm that can adjust to images moving within the boundaries of the bezels, enabling a seamless viewing experience from screen-to-screen.

LAN Daisy Chain Performance

The LAN daisy chain allows you to execute commands to control and monitor the screens, and even update their firmware.

Guide Bracket / Classified Port

A guide bracket is an attachment that ensures the video wall remains flat. The classified in/out port prevents errors when connecting a daisy chain.

Control Buttons

With 8 control buttons, it’s easy to operate various functions of the 49VM5C, such as   controlling the OSD (On Screen Display) and changing the input source.

BIM File

PANEL

    • Screen Size
    • 49"
    • Native Resolution
    • 1,920 x 1,080 (FHD)
    • Dynamic CR
    • 500,000 : 1
    • Contrast Ratio
    • 1,300:1
    • Response Time
    • 8 ms (G to G)
    • Brightness
    • 500 cd/m^2
    • Panel Technology
    • IPS
    • Aspect Ratio
    • 16 : 9
    • Viewing Angle (H x V)
    • 178 x 178
    • Surface Treatment
    • Hard Coating (3H), Anti-Glare Treatment of the Front Polarizer (Haze 10%)
    • Guaranteed Operating Hour
    • 24 Hours
    • Orientation
    • Portrait & Landscape

CONNECTIVITY

    • Input
    • HDMI, DP, DVI-D, OPS, Audio, USB 2.0, USB3.0, RGB
    • Output
    • DP, Audio
    • External Control
    • RS232C, RJ45, IR Receiver

PHYSICAL SPECIFICATIONS

    • Bezel Color
    • Black
    • Bezel Width
    • 0.9 mm (Top/Bottom/Left/Right even bezel) / 1.8 mm *B to B : Panel Bezel + Panel Bezel
    • Dimension (Monitor) (W x H x D)
    • 1,075.6 x 605.8 x 86.2 mm
    • Weight (Head)
    • 17.5 kg
    • Dimension (Carton) (W x H x D)
    • 1,214 x 775 x 263 mm
    • Packed Weight
    • 23.2 kg
    • VESA™ Standard Mount Interface
    • 600 x 400mm

SPECIAL FEATURES

    • USB Cloning
    • Yes
    • Smart Energy Saving
    • Yes
    • Tile Mode
    • Yes (Up to 15x15)
    • Energy Saving
    • Yes
    • Temperature Sensor
    • Yes
    • Internal Memory
    • 8GB (System 4GB + Available 4GB)
    • Fail Over
    • Yes
    • Wi-Fi
    • WiFi Dongle Ready
    • Contents Scheduling
    • Yes
    • File Play With USB
    • Yes
    • Natural Mode @Tile Mode
    • Yes
    • Yes
    • Temperature Sensor, Tile Mode (up to 15 x 15), Natural Mode@Tile Mode, Energy Saving, Smart Energy Saving, File Play with USB, Internal Memory (8 GB, System 4 GB + Available 4 GB), Wi-Fi Dongle Ready, USB Cloning, Content Scheduling, Fail over (USB, RGB, DVI, HDMI, Internal Memory)

MEDIA PLAYER COMPATIBILITY

    • External Media Player Attachable
    • Yes (MP500/MP700)
    • OPS Type Compatible
    • Yes

ENVIRONMENTAL CONDITIONS

    • Operating Temperature Range
    • 0 °C to 40 °C
    • Operating Humidity Range
    • 10% to 80%

POWER

    • Power Supply
    • 100–240V~, 50/60Hz
    • Power Type
    • Built-In Power
    • Power Consumption (Typ)
    • 120W
    • Power Consumption-Smart Energy Saving On
    • 70W

CERTIFICATIONS

    • Safety
    • UL / cUL / CB / TUV / KC
    • EMC
    • FCC Class "A" / CE / KCC

SOFTWARE COMPATIBILITY

    • SuperSign-C
    • Yes
    • SuperSign W-Lite
    • Yes

ACCESSORIES

    • Basic
    • Remote controller, Power cable, DP cable, Manual, IR receiver, RS-232C cable, LAN cable, Guide bracket, Screws
    • Optional
    • Wall mount (Landscape: WM-L640V, Portrait: WM-P640V), OPS kit (KT-OPSA), HDBaseT (EB-B100)
