- Umweltfreundliche Lösung (Nutzung von grüner Energie, Reduzierung der CO2-Emissionen)
- Platzsparend (kompakte Größe und Design)
- Kostenersparnis durch hohen Wirkungsgrad
- Energieeinsparung durch Wärmerückgewinnung
Alle Spezifikationen
BETRIEBSSTROM
#1
50/60 Hz 220-240 V~
KÜHLLEISTUNG
Nennleistung (kW)
28
HEIZLEISTUNG
Nennleistung (kW)
31.5
LEISTUNGSAUFNAHME(KÜHLEN)
Nennleistung (kW)
0.01
LEISTUNGSAUFNAHME(HEIZEN)
Nennleistung (kW)
0.01
WÄRMETAUSCHER
Typ
Brazed Plate HEX
Nenndurchfluss (l/min)
92
Druckverlust (kPa)
69
ABMESSUNGEN
Netto(B x H x T) (mm)
520 x 631 x 330
GEWICHT
Netto (kg)
33.7
KÄLTEMITTEL
Typ
R410A
GWP(Global Warming Potential)
2087.5
Kontrollart
Electronic expansion valve
ROHRLEITUNGSANSCHLÜSSE
Flüssig (mm(inch))
Ø 9.52(3/8)
Gas (mm(inch))
Ø 22.2(7/8)
WASSERANSCHLUSSLEITUNGEN
Eintritt (inch)
Male PT 1
Austritt (inch)
Male PT 1
SCHALLDRUCKPEGEL
Kühlen / Heizen (dB(A))
26/26
