NS242H3
DUALCOOL Inverter AC, 24000 BTU Heat and Cool, Split Air Conditioner, 50/60Hz

SAR 3,506
SAR 5,748

Shipping options may vary by region.

component-OBScountrySelectDesc

DUALCOOL Inverter AC, 24000 BTU Heat and Cool, Split Air Conditioner, 50/60Hz
SAR 3,506
SAR 5,748
  •  Dual Inverter Compressor™1

    Dual Inverter Compressor™

    A compressor with a wider rotational frequency saves more energy and has a faster cooling range.

  • 10 Year Warranty1

    10 Year Warranty

    Verification obtained from TUV Rheinland for 10-year product life cycle.

  • TUV Rheinland1

    TUV Rheinland

    TUV Rheinland, Verification on Fast Cooling & Power Saving Rate(US-W242Kxy0/TS-H2465DA0).

  • Comfort Sleep1

    Comfort Sleep

    One button adjusts “Indirect airflow/7hr off time set/Soft wind & sleep time logic” automatically.

  • Dual Protection Filter1

    Dual Protection Filter

    The Dual Protection Filter captures large dust particles.

  • Gold Fin™1

    Gold Fin™

    The Gold Fin™ ensures that the surface is more resistant to corrosion and enhances the durability of heat exchanger for a much longer period.

  • Auto Cleaning1

    Auto Cleaning

    The comprehensive auto cleaning function prevents the forming of bacteria and mold on the heat exchanger and thus provides a more pleasant and comfortable environment for the user.

Dimensions

SK_E_02_U24A_Dimension_-NS242H3 SK_E_02_U24A_Dimension_-NS242H3

Summary

  • Capacity
    24000 BTU
  • Dimension (W x H x D)
    998 x 345 x 210
  • Main Technology
    65ºC Operation Tropical Dual Inverter Compressor
  • Additional Benefit
    Up to 53% Energy saving & Up to 60% Fast cooling

GENERAL SPECIFICATIONS

  • Energy Label Grade (Cooling)
    D
    Annual Energy Consumption (Cooling) (kWh/year)
    4681.8
  • Power Supply (Ø, V, Hz)
    1, 230, 60
    Available Voltage Range (V)
    187 ~ 253
  • Power Factor (Cooling/Heating) (%)
    97.7/98.7
    Moisture Removal (l/h)
    2.50
  • Circuit Breaker (A)
    30
    Power Supply Cable (No. × mm²)
    3x2.5
  • Power Supply to Unit
    Outdoor
    Power and Communication Cable (No. × mm²)
    4x0.75
  • Drain Hose Size (O.D, I.D) (mm)
    21.5, 16.0
    Defrost Method
    Reverse Cycle
  • Cooling Capacity [BTU]
    24,000
    Cooling & Heating
    Cooling & Heating

CAPACITY

  • Cooling (Min ~ Rated ~ Max) (kW)
    0.90 ~ 6.33 ~ 8.00
    Cooling (Min ~ Rated ~ Max) (Btu/h)
    3,070 ~ 21,500 ~ 27,200
  • Cooling (T3) (Min ~ Rated ~ Max) (kW)
    0.79 ~ 5.43 ~ 7.03
    Cooling (T3) (Min ~ Rated ~ Max) (Btu/h)
    2,700 ~ 18,500 ~ 24,000
  • Heating (Min ~ Rated ~ Max) (kW)
    0.90 ~ 7.05 ~ 8.70
    Heating (Min ~ Rated ~ Max) (Btu/h)
    3,070 ~ 24,050 ~ 29,690

POWER INPUT

  • Cooling (Min ~ Rated ~ Max) (W)
    340 ~ 1,734 ~ 3,700
    Cooling (T3) (Min ~ Rated ~ Max) (W)
    394 ~ 2,127 ~ 3,700
  • Heating (Min ~ Rated ~ Max) (W)
    340 ~ 1,986 ~ 3,700

RUNNING CURRENT

  • Cooling (Min ~ Rated ~ Max) (A)
    1.65 ~ 7.70 ~ 17.00
    Cooling (T3) (Min ~ Rated ~ Max) (A)
    1.90 ~ 9.70 ~ 17.00
  • Heating (Min ~ Rated ~ Max) (A)
    1.65 ~ 8.80 ~ 17.00

EER

  • EER (W/W)
    3.65
    EER ((Btu/h)/W)
    12.40

EER(T3)

  • EER (T3) (W/W)
    2.55
    EER (T3) ((Btu/h)/W)
    8.70

COP

  • COP (W/W)
    3.55
    COP ((Btu/h)/W)
    12.11

INDOOR

  • Air Flow Rate (Cooling, Max/H/M/L) (㎥/min)
    19.0/14.5/13.0/10.5
    Air Flow Rate (Heating, Max/H/M/L) (㎥/min)
    20.0/16.0/13.5/11.0
  • Sound Pressure Level (Cooling, H/M/L/SL) (dB(A))
    46/42/37/28
    Sound Pressure Level (Heating, H/M/L) (dB(A))
    46/42/37
  • Dimensions (WxHxD) (Net) (mm)
    998x345x210
    Dimensions (WxHxD) (Shipping) (mm)
    1080x422x281
  • Weight (Net) (kg)
    12.6
    Weight (Shipping) (kg)
    14.3
  • Exterior Color Code
    Munsell 7.5BG 10/2 (RAL 9016)

OUTDOOR

  • Air Flow Rate (Max) (m³/min)
    49.0
    Fan Motor Speed (Cooling, Min ~ Max) (rpm)
    190 ~ 900
  • Fan Motor Speed (Heating, Min ~ Max) (rpm)
    190 ~ 900
    Sound Pressure Level (Cooling, Rated) (dB(A))
    55
  • Sound Pressure Level (Heating, Rated) (dB(A))
    55
    Dimensions (WxHxD) (Net) (mm)
    870x650x330
  • Dimensions (WxHxD) (Shipping) (mm)
    1026x693x446
    Weight (Net) (kg)
    44.0
  • Weight (Shipping) (kg)
    48.0
    Max. Fuse Size (A)
    30
  • Exterior Color Code
    Munsell 9.54Y 8.34/1.31 (RAL 9001)
    Operation Range (Cooling) (°C DB)
    18 ~ 54
  • Operation Range (Heating) (°C DB)
    -5 ~ 24
    Operation Range (Heating) (°C WB)
    -5 ~ 18

PIPING

  • Size (Liquid) (mm)
    6.35ø
    Size (Gas) (mm)
    15.88ø
  • Connections Method (Indoor/Outdoor)
    Flared

BETWEEN INDOOR & OUTDOOR

  • Piping Length (Min/Standard/Max) (m)
    3/5/30
    Piping Length (No Charge) (m)
    7.5
  • Max. Elevation Difference (m)
    25
    Piping Connection Heat Insulation
    Both liquid and gas pipes

REFRIGERANT

  • Type
    R410A
    Pre Charge (g)
    1450
  • Additional Charge (g/m)
    20
    Control
    Electronic Expansion Valve
  • Global Warning Potential
    2087.5
    t-CO₂ eq
    3.027

TOOL CODE(CHASSIS)

  • Indoor/Outdoor
    SK/U24A

COMPRESSOR

  • Type
    Dual Inverter Compressor
    Model
    GKT208MAB
  • Motor Type
    BLDC
    Oil Type/Maker
    PVE (FVC68D)/IDEMITSU
  • Oil Charge (cc)
    670
    Manufacturer/Country of Origin
    LG Electronics/China

FAN(INDOOR)

  • Type
    Cross Flow Fan
    Motor Output (W)
    30

FAN(OUTDOOR)

  • Type
    Propeller Fan
    Motor Type
    BLDC
  • Motor Output (W)
    85
    Motor Insulation
    Class E
  • Motor Enclosure/Ingress Protection
    TEAO/IPX4

HEAT EXCHANGER

  • Evaporator (Material, Tube/Fin)
    Cu/Al
    Evaporator ((øxRowxColumnxFPIxL) x Qty.) (#1)
    (7øx2x16x20x744) x 1
  • Evaporator ((øxRowxColumnxFPIxL) x Qty.) (#2)
    (5øx1x4x22x744) x 2
    Evaporator (Corrosion Protection)
    PCM
  • Evaporator (Fin Type)
    Slit
    Condenser (Material, Tube/Fin)
    Cu/Al
  • Condenser ((øxRowxColumnxFPIxL) x Qty.) (#1)
    (7øx2x28x18x940) x 1
    Condenser (Corrosion Protection)
    Gold
  • Condenser (Fin Type)
    Louver

DISCLAIMER

  • Performance
    Except for rated value, the performance can be varied based on the operation and the installation conditions.
