Discontinued
LW2415HR
Window Air Conditioner
  • 22,500/23,000 BTU Cooling
  • 9,400/11,600 BTU Heating
  • Seasonal Heating & Cooling
  • Multiple Cooling/Heating Speeds
Window Air Conditioner

PERFORMANCE

  • EER
    9.8 / 9.8
    CEER
    9.8/9.8
  • Dehumid. (Pts/Hr)
    6.5
    Dry Air Flow (CFM)
    560
  • dBA Level (Indoor / Outdoor)
    64/69
    Est. Cooling Area (Sq. Ft.)
    1420
  • BTU Performance Cooling
    22,500/23,000
    BTU Performance Heating
    9,400/11,600

DIMENSIONS

  • Product (WxHxD)
    25 1/2" x 16 27/32" x 30 1/2"
    Shipping (WxHxD)
    29 3/8" x 21 3/16" x 33"
  • Net Weight (lbs.)
    145
    Shipping Weight (lbs.)
    159

FEATURES

  • Thermostat Control
    Thermistor
    Air Deflection
    Oscillating Air Vent
  • Auto Restart
    Yes
    Energy Saver Function
    Yes
  • Filter Alarm Function
    Yes
    Fan Only Speed
    2
  • Auto Swing
    Yes
    Fan Speed: Cooling (Heating)
    2(2)
  • Compressor
    Rotary
    Indoor Fan Type
    Blower
  • Type Air Discharge
    Side
    Outdoor Vent / Exhaust
    Yes
  • Chassis Type
    Slide In-Out

MATERIALS/FINISHES

  • Available Colors
    White

ELECTRICAL RATINGS

  • Voltage / 60 Hz
    208/230
    Watts (Cooling)
    2,290/2,340
  • Watts (Heating)
    3,750/3,770
    Rated Amps (Cooling)
    11.5/10.6
  • Rated Amps (Heating)
    15.0/16.0

WARRANTY

  • Limited Warranty
    1 Year Parts and Labor
    UPC
    048231376549
ASK & ANSWER

Ask your questions. Share your answers.
Please review the detailed product information and help guides in the
Product Support section for this product prior to posting a question.

My unit has worked well then all of a sudden the compressor keeps going with no fan

Asked by: Conste
It sounds like we'll need to walk through some troubleshooting for your air conditioner. Please head over to our support team via @LGUSSupport on Twitter or you can give us a call at 800-243-0000 so that we can dig into this a little more for you. ^CP
Answered by: ChrisPSM
Date published: 2019-05-13

My unit blows warm air for about 5-10 minutes when first turned on to the heat setting. After that, it blows cool air. It is just over a year old. It worked fine last winter but now it wants to freeze up on heat! I had trouble this past summer freezing up

Asked by: Tigers1842
We regret the trouble you have experienced with this air conditioner. It is suggested to ensure that the VENT duct has been sealed, and is not allowing cold air into the room. If this does not resolve the matter, please contact our Customer Interactive Center at 800-243-0000.
Answered by: NeilE
Date published: 2017-01-16

Is it normal to have some water in the air discharge area?

Asked by: Bo422
We regret the inconvenience you have experienced with this air conditioner. The appearance of moisture in Air Discharge duct is not uncommon when in a high-humidity environment. If there is moisture on the vents, this can simply be wiped away.
Answered by: NeilE
Date published: 2016-04-29

Use 20 amp or 30 amp fuse for LG 23,000 BTU window unit AC with built in heater (Model # LW2415HR)?

I will be installing the 23,000 BTU LG window unit AC with built in heater (Model # LW2415HR) in my garage. I will install a new dedicated fuse, wire and outlet for this unit. Only the unit will run on this fuse/wire/outlet. The unit calls for a 220 volt fuse, but what amp on the fuse should I install? The unit spec says it pulls up to 16 amp. Should I install a 20 amp or 30 amp fuse? I do not want the fuse tripping frequently during normal use. The guy at the hardware store says 16 amp is right at the threshold where they start to recommend using a 30 amp fuse instead of just 20 amp.
Asked by: Peter1975
In my opinion, always use 30 minimum with 220 volt service, your wire will not heat up as much and you will use less energy. The rule of thumb is, only load your wires 60%. 60% of 20 amps is only 12 amps. I guaranty, you will be blowing a 20 amp fuse since your unit will be drawing 16 amps. The exact thing happen to us at the church. We had to go to a #10 wire and a 30 amp fuse.
Answered by: allston1971
Date published: 2015-08-23

What is the advantage of using a mini split system over a through wall unit for the same BTU output.

Asked by: JP01
Mini Splits are more like central systems and have two main components: an outdoor compressor/condenser, and an indoor air-handling unit. A conduit, which houses the power cable, refrigerant tubing, suction tubing, and a condensate drain, links the outdoor and indoor units. They are small in size and offer flexibility for zoning or heating and cooling individual rooms. Many models can have as many as four indoor air handling units (for four zones or rooms) connected to one outdoor unit. The number depends on how much heating or cooling is required for the building or each zone. Each of the zones will have its own thermostat, so you only need to condition that space when it is occupied, which saves energy and money...^IFV
Answered by: LGJoel
Date published: 2015-08-11

give me a good suggestion of your make with prices and a detailed description on a 2 ton wpower saver indow ac having a good cooling effect suitable for a larger area of two adjacent rooms...thank you !

Asked by: thaju

Does it have a heat pump or heat strip?

Asked by: A plus
