Discontinued
N2B1D
2 Bay Super Multi NAS with Blu-ray Disc Rewriter
  • Access all your data anywhere via the internet
  • Built-in Blu-ray Disc Rewriter for additional data backup option & protection
  • Hot Swappable and Lockable Trays
  • RAID Management Support (0, 1, JBOD, 1 + JBOD, Individual)
2 Bay Super Multi NAS with Blu-ray Disc Rewriter

SUMMARY

  • Processor
    Marvell 88F6192 800MHz
    Number of HDD Bays
    2
  • SDRAM
    1024Mbits
    Data Transfer Rates
    16bit/DDR2 (400MHz Data Rate)
  • Recommended HDD Capacity
    250GB, 500GB, 750GB, 1TB, 1.5TB
    Operating System
    Embedded Linux (Kernel 2.6)
  • Client OS Support
    Win 2000, XP, Vista, Windows Server 2003, Mac OS 10.3 and later; Linux (Redhat 9, Ubuntu, Suse)
    Warranty
    1 Year Parts & Labor

SIZE AND WEIGHT

  • Dimensions (W x H x D)
    6.5” x 6.4” x 9.1”
    Weight (without HDD)
    9.26 lbs.
  • Weight (with HDD)
    11.46 lbs.

HDD

  • Included Storage
    Enclosure only (HDDs not included)
    Interface
    E-SATA (SATA II)
  • RPM
    7200
    Buffer
    8MB / 16MB
  • Size
    3.5"

LAN INTERFACE

  • Standard Compliance
    IEEE802.3 (1000/100/10 Base-T)
    Data Transfer Rates
    10/100/1000Mbps
  • Connector Type
    RJ-45
    Number of Ports
    1

BLU-RAY RE-WRITER

  • SupportedMedia
    BD/DVD/CD
    Writing Speed
    BD (6xMax.)/ DVD (16xMax.) CD (40xMax.)
  • Reading Speed
    BD (6xMax.)/ DVD (12xMax.) CD (40xMax.)

USB INTERFACE

  • Standard Compliance
    USB 2.0
    Connector Type
    USB Type A
  • Number of Ports
    3 (Top 1 ea., Rear 2 ea.)
    Data Transfer Rates
    Max: 480Mbps (High Speed Mode), Max: 12Mbps (Full Speed Mode)

OTHER INTERFACE

  • Memory Card Reader
    4 in 1 (SD,MMC,MS, xD)

NETWORK FILE SERVICES

  • Transport Protocol
    TCP/IP
    Network Services
    DHCP, NTP Support
  • Management
    HTTP/HTTPS, FTP/FTPS
    Time Syncronization
    NTP
  • Network Options
    DHCP, NTP

POWER

  • Voltage/Hz
    90V - 264V, 47Hz ~ 63Hz
    Idle Mode (Typical)
    44W
  • Sleep Mode (Typical)
    14W
    Standby Mode (Typical)
    1.0W

OTHER

  • Operating System
    Embedded Linux (Kernel 2.6)
    Client OS Support
    Win 2000, XP, Vista, Windows Server 2003, Mac OS® 10.3 and later Linux (Redhat 9, Ubuntu, Suse)
  • Regulations & Standards
    FCC, UL, CE, CE Marking, RoHS
    Software Bundle
    Power2Go v.6, PowerDVD v.8,MVP Album. PhotoDVD 4.0 SE
What people are saying
Rated 5 out of 5 by from Perfect Home Network Attached Storage Excellent Network Storage Device for your home. Provides central backup location, great for sharing photo's and video throughout your home to all your network devices. Easy to access over the internet with smart phones and ipads. Price is unbeatable and large home videos can be stored and moved to Blu-ray with the built-in burner to mail to other family members. All that is lacking is the poor interface. Might be difficult for user without some basic computer usage skills, needs better interface.
Date published: 2012-07-25
Rated 4 out of 5 by from LifeSaver And I don't mean the candy. The NAS system makes daily backups a breeze and because that was the case, when my system crashed hard and I needed to restore, I was back in business in under 2 hours. The Blu-ray writer is a real plus to making offsite backups of a good chunk of data. I would recommend this to my friends and would buy another.
Date published: 2011-10-25
  • y_2019, m_10, d_20, h_8
  • bvseo_bulk, prod_bvrr, vn_bulk_2.0.13
  • cp_1, bvpage1
  • co_hasreviews, tv_0, tr_2
  • loc_en_US, sid_MD00001263, prod, sort_[SortEntry(order=SUBMISSION_TIME, direction=DESCENDING)]
  • clientName_lg
  • bvseo_sdk, java_sdk, bvseo-4.0.0
  • CLOUD, getReviews, 316ms
  • REVIEWS, PRODUCT
ASK & ANSWER

Ask your questions. Share your answers.
Please review the detailed product information and help guides in the
Product Support section for this product prior to posting a question.

I have an N2B1 but without any hard drives.  How can I get the device working as a NAS again?

Asked by: Ubernoob
Our offices, in the United States, do not have specific product information units released in the United Kingdom. In order to obtain such information, it is recommended to check our subsidiary’s website, at http://www.lg.com/uk/support/contact/support-here-to-help.jsp.
Answered by: NeilE
Date published: 2016-02-26

Is There Any Planned Upgrades To Support A 3TB Hard Drive In RAID?

Is There Any Planned Upgrades To Support A 3TB Hard Drive In RAID? Also is there any planned upgrades at all in the near future due to this NAS being discontinued?
Asked by: karlypants
I apologize, but no; at this time, there are no known plans to upgrade this system to be compatible with 3TB hard drives. The latest update on our website is dated 5/16/2012. This can be reviewed at http://www.lg.com/us/support-product/lg-N2B1D.
Answered by: NeilE
Date published: 2013-10-22

I would like to give my LG N2B1D a public address and use it for an FTP server. How can I load ftp software onto this device?

Asked by: Utah
We appreciate your interest in this operations of this NAS device. FTP Software cannot be added, although the unit can be accessed through FTP without requiring software. A public IP Address is already provided by the Internet Service Provider. We offer DDNS which will allow connection with a specific address (i.e. name.lgnas.com). If you have additional questions about this unit and its operation, please contact our Customer Interactive Center at 800-243-0000.
Answered by: NeilE
Date published: 2013-10-22

Can I attach an external hard drive to the NAS?

I would like to transfer information from the NAS to another external hard drive. I want to hook up a Clickfree 2tb external hard drive to the NAS.
Asked by: Anonymous
Yes through the eSata port.
Answered by: Supercoolin
Date published: 2013-10-22

RAID 1 configuration questions for N2B1

I have a NAS drive, model # N2B1. I configured Volume 1 to be RAID 1 (Mirroring). It only shows one drive letter (though both disks appear in the Hard Disk status web menu). Can I assume that the 2nd disk is the failover disk? Also, if disk 1 fails, how do I access the data from the 2nd disk? Final question: how frequently does the sync occur between disks 1 and 2? Thanks for your help!
Asked by: Tappanzee
Raid 1 is simply mirroring of both drives, the data is the written to both at the same time and read from the active drive. Should the active drive fail, the N2B1 will automatically make the second drive primary and alarm you to the failed drive that needs to be replaced. Once you install the new drive, the rebuild is automatic. You would then have to go into the brouser software to change the primary drive back to the new drive, or you can simply keep the original second drive as primary active automatically.
Answered by: Supercoolin
Date published: 2013-10-22

What are the recommended hdd's for the n2b1d?

Asked by: dazed
This unit will work just fine with any of the following HDD sizes: 250GB, 500GB, 750GB, 1TB, 1.5TB
Answered by: LGJoel
Date published: 2013-10-22

Lion copatibility

I does the update (1.0.0_2660) and still need to smb to access HD still. Also can't use print server, time machine, iTunes....GRRRRR why???????
Asked by: Photoman
We regret the delays you have experienced with getting this update. The last ETA date we have listed for this particular model was November 18th. Some updates have been released, so this is being worked. Unfortunately, at this time, we do not have an ETA data available for you. However, it may be possible to use the alternate protocol, .SMB. To access it from a Mac, select Finder, and then 'Go' and then 'Connect to Server'. From there, you will have to type smb://xxx.xxx.xxx.xxx (the ip address for the NAS). Once this process is complete, you should be able to access the drive. If you need additional information about this situation, please contact our Customer Interactive Center at 800-243-0000.
Answered by: NeilE
Date published: 2013-10-22

Lion compatibility!!!

I does the update (1.0.0_2660) and still need to smb to access HD still. Also can't use print server, time machine, iTunes....GRRRRR why???????
Asked by: steevegAlma
Our offices, in the United States, do not have product information for Canada. In order to obtain such information, it is recommended to check our subsidiary’s website, at http://www.lg.com/ca_en/index.jsp. You may also contact our Canada offices at 1-888-542-2623.
Answered by: NeilE
Date published: 2013-10-22
