LAT240DT1

24mm Self-adhesive Transparent Color LED Film that is TAA Compliant with Concave & Convex Curvature, webOS™ Smart Platform & Control Manager

KEY FEATURES

  • Pitch: 24mm
  • LED Type: R,G,B 3in1 Color Package
  • Transmittance: 73%
  • Curvature(Convex and Concave): 1,100R
  • Self-adhesive Film
24mm Self-adhesive Transparent Color LED Film that is TAA Compliant with Concave & Convex Curvature, webOS™ Smart Platform & Control Manager
$

LED Film

    • Adhesion (After Installation)
    • 50,000 Hrs
    • Brightness
    • >1,000 nits
    • Color Chromaticity
    • Cx: 0.28±0.03, Cy: 0.28±0.03
    • Color Processing
    • 130/120/110 Level (R, G, B)
    • Colors
    • 1,716,000 Colors
    • Contrast Ratio
    • ≥ 100,000:1
    • Curved Installation
    • 1,100R (Concave)
    • Daily Usage
    • 24 Hrs / 7 Days
    • Dimensions (W x H x D)
    • 26.3" x 18.9" x 0.8" / 668 x 480 x 2.0 mm (with Front & Back Protection Film)
    • Film Trimming
    • Yes (Parallel to the Bezel Side Only)
    • LED Type
    • R, G, B 3in1 Color Package (SMD1818)
    • Life Time (Brightness 50%)
    • 50,000 Hrs
    • Luminance Uniformity
    • ≥ 70%
    • Operating Temperature
    • 32°F~ 113°F / 0°C ~ 45oC (Indoor Glass Installation Only)
    • Pitch
    • 24 mm
    • Pixel Density [points/m2]
    • 1,736
    • Power consumption
    • 37 W (Transparent Panel and Bezel Kit, @ film 1ea), 150 W (Transparent Panel and Bezel Kit, @ film 2x2)
    • Resolution
    • 28 x 20
    • Transmittance
    • 73%
    • Viewing Angle (H x V)
    • 120° x 120°
    • Weight
    • 1.6 lbs / 0.73 kg

System Controller

    • Accessories
    • Power Cord, HDMI Cable, IR Sensor, 4P Phone-to-RS232C Gender
    • CMS S/W
    • Yes
    • Dimensions (W x H x D)
    • 10.7" x 7.4" x 1.5" / 273 × 186.8 × 37 mm
    • Input
    • HDMI, DP, DVI-D, RS232C, RJ45 (w/o LED Indicator), IR Receiver (for Installation), USB 3.0
    • Light Sensor
    • O
    • Output
    • LVDS, DP, RS232C, RJ45 (w/o LED Indicator)
    • Power consumption
    • 17 W
    • Source Selection
    • HDMI, DVI-D, DP
    • Temperature Sensor
    • O
    • TPC
    • Yes
    • Video
    • 3,840 x 2,160 @30Hz
    • Weight (Head)
    • 3.5 lbs / 1.6 kg

Unit Controller

    • Accessories
    • Power Cord, LVDS MCX Cable, ESG, Regulation Book
    • Dimensions (W x H x D)
    • 10.7" x 7.4" x 1.5" / 273 × 186.8 × 37 mm
    • Interface
    • LVDS in with I2C, RJ45 x 4ea
    • Maximum Transmission Length
    • 328.1' / 100m
    • Power consumption
    • 20 W
    • Resolution
    • Up to FHD (4 Unit Controllers Needed for FHD)
    • Weight
    • 3.3 lbs / 1.5 kg
