GSCC080-GN

8.0mm GSCC Series Outdoor LED with Customizable Screen Ratio, 5,000nits Brightness, IP65 Rated, 90° Corner Options & Easy Assembly & Maintenance

KEY FEATURES

  • Pixel Pitch: 8.00mm
  • Brightness: 5,000nits
  • Fast Assembly and Easy Maintenance
  • IP65 Weatherproof Design
  • 90º Corner Option Available
  • Rental/Staging/Temporary deployments
8.0mm GSCC Series Outdoor LED with Customizable Screen Ratio, 5,000nits Brightness, IP65 Rated, 90° Corner Options & Easy Assembly & Maintenance
$

Customizable Screen Ratio

Cabinets of the GSCC series can be assembled to configure virtually any screen size including the 16:9,
8:9 and 4:3 screen ratio. This enables customers to apply LED Screens according to installation sites.

PHYSICAL PARAMETERS

    • Pixel Configuration
    • 3 in 1 SMD
    • Pixel Pitch
    • 8.00mm
    • Module Resolution (W x H)
    • 40 x 30
    • Module Dimensions (W x H)
    • 12.6 x 9.4 in/320 x 240 mm
    • Weight per Module
    • 2.9 lbs/1.3kg
    • LED Package Manufacturer
    • Nationstar
    • No. of Modules per Unit Case (W x H)
    • 2 x 3
    • Unit Case Resolution (W x H, pixels)
    • 80 x 90
    • Unit Case Dimensions (W x H x D)
    • 25.2 x 28.3 x 4.5 in/640 x 720 x 114.9 mm
    • Unit Case Surface Area
    • 4.96 ft²/0.461m²
    • Weight per Unit Case
    • 37.5 lbs/17kg
    • Weight per Square Meter
    • 7.6 lb/ft²/36.9kg/m²
    • Physical Pixel Density (pixels/m²)
    • 1,452pixels/ft² | 15,625pixels/m²
    • Flatness of Unit Case (mm)
    • ±0.5
    • Unit Case Material
    • Die-cast Aluminum
    • Service Access
    • Front or Rear (select one only)

OPTICAL SPECIFICATIONS

    • Brightness
    • 5,000nits
    • Color Temperature
    • 3,500 to 9,000 K
    • Visual Viewing Angle (Horizontal)
    • 160°
    • Visual Viewing Angle (Vertical)
    • 115°
    • Brightness Uniformity
    • 97%
    • Color Uniformity
    • ±0.003Cx,Cy
    • Contrast Ratio
    • 6,700
    • Processing Depth
    • 14 bit

ELECTRICAL SPECIFICATIONS

    • Max Power Consumption per Unit
    • 330W
    • Average Power Consumption per Unit
    • 110W
    • Max Power Consumption per Unit Area
    • 720W/m²
    • Max Power Consumption per Unit
    • 1126 BTU
    • Average Power Consumption per Unit
    • 375 BTU
    • Max Power Consumption per Unit Area
    • 2,457 BTU/m²
    • Power Supply
    • 100 to 240 Vac
    • Frame Rate
    • 50/60 Hz
    • Refresh Rate
    • 3841Hz

OPERATION SPECIFICATIONS

    • LED Lifetime (Half brightness)
    • 100,000 hrs
    • Operating Temperature
    • -4°F to 122°F/-20°C to +50°C
    • Operating Humidity
    • 10-99% RH
    • IP Rating Front
    • IP65
    • IP Rating Rear
    • IP54

CERTIFICATIONS

    • FCC (Regulatory)
    • Yes
    • ETL (Safety)
    • Yes
    • CE (Regulatory
    • Yes
    • RoHS (Environmental)
    • Yes

CONTROLLER

    • Controller
    • LCIN006

Specification Sheet
