GSCD100-GN

GSCD 10.41mm Ultra Light Series Outdoor LED with two cabinet options, 5,000 nits Brightness, IP65 Rated, & 90° Corner Option

GSCD 10.41mm Ultra Light Series Outdoor LED with two cabinet options, 5,000 nits Brightness, IP65 Rated, & 90° Corner Option
$

Lightweight Design

The cabinets of the GSCD series are much lighter than other outdoor LED displays weighing 46.7 lbs. & 41.88 lbs. This reduces the load on the building when a large LED screen is installed on it.
*Image for illustration purposes only.
*Image for illustration purposes only.
*Image for illustration purposes only.

90° Corner Design Available

If you add a 90° corner option*, the GSCD series can deliver virtually flawless content even when installed on the corners.
*Image for illustration purposes only.
*This option is an extra cost.

IP Rated Weatherproof Design

The front and back of the cabinet are IP65 certified, allowing stable operation during bad weather and harmful outdoor environments.
*Image for illustration purposes only.

PHYSICAL PARAMETERS

    • Pixel Configuration
    • 3 in 1 SMD
    • Pixel Pitch
    • 10.41 mm
    • Module Resolution (W x H)
    • 48 x 24
    • Module Dimensions (W x H)
    • 19.7 x 9.8 in / 500 x 250 mm
    • Weight per Module
    • 2.9 lbs / 1.3 kg
    • LED Package Manufacturer
    • Nationstar
    • No. of Modules per Unit Case (W x H)
    • 2 x 4
    • Unit Case Resolution (W x H, pixels)
    • 96 x 96
    • Unit Case Dimensions (W x H x D)
    • 39.4 39.4 x 3.4 in 1000 x 1000 x 85.1mm
    • Unit Case Surface Area
    • 10.8 m2 / 1 m2
    • Weight per Unit Case
    • 41.9 lbs / 19 kg
    • Weight per Square Meter
    • 3.9 lb/ft2 / 19 kg/m2
    • Physical Pixel Density (pixels/m²)
    • 857 pixels/ft2 / 9,216 pixels/m²
    • Flatness of Unit Case (mm)
    • ±0.5
    • Unit Case Material
    • Aluminum Profiles
    • Service Access
    • Front or Rear (select one only)

OPTICAL SPECIFICATIONS

    • Brightness
    • 5,000nits
    • Color Temperature
    • 3,500 to 9,000 K
    • Visual Viewing Angle (Horizontal)
    • 160°
    • Visual Viewing Angle (Vertical)
    • 136°
    • Brightness Uniformity
    • 97%
    • Color Uniformity
    • ±0.003CxCy
    • Contrast Ratio
    • 10,000
    • Processing Depth
    • 14 bit

ELECTRICAL SPECIFICATIONS

    • Max Power Consumption per Unit
    • 650 W
    • Average Power Consumption per Unit
    • 216 W
    • Max Power Consumption per Unit Area
    • 650 W/m²
    • Max Power Consumption per Unit
    • 2218 BTU
    • Average Power Consumption per Unit
    • 737 BTU
    • Max Power Consumption per Unit Area
    • 2,218 BTU/m²
    • Power Supply
    • 100 to 240 Vac
    • Frame Rate
    • 50 / 60 Hz
    • Refresh Rate
    • 3847 Hz

OPERATION SPECIFICATIONS

    • LED Lifetime (Half brightness)
    • 100,000 hrs
    • Operating Temperature
    • -4°F to 122°F/-20°C to +50°C
    • Operating Humidity
    • 10-99% RH
    • IP Rating Front
    • IP65
    • IP Rating Rear
    • IP65

CERTIFICATIONS

    • FCC (Regulatory)
    • Yes
    • CE (Regulatory)
    • Yes
    • ETL (Safety)
    • Yes
    • RoHS (Environmental)
    • Yes

CONTROLLER

    • Controller
    • LCIN006
    • 90 degree corner cut
    • Yes
