55SVH7PF-H
55” SVH7PF-H Series 0.44mm Even Bezel FHD IPS Video Wall with External Power Box, built-in SoC and webOS Smart Signage Platform, gap reduction and smart calibration.
  • Brightness(Typ.) : 700 cd/m²
  • Power Type : External Power Box
  • Bezel : 0.44 mm(Even)
  • Surface Treatment(28%)
  • Interface : HDMI(2)/ DP/ DVI-D/ USB/ RS232C/ RJ45/ Audio/ IR
  • Smart Calibration
55” SVH7PF-H Series 0.44mm Even Bezel FHD IPS Video Wall with External Power Box, built-in SoC and webOS Smart Signage Platform, gap reduction and smart calibration.
$
*Power redundancy support is available in 'redundancy on' mode
**An external power box needs to be purchased separately, and one operates up to 9 signage units in the length of 6 meter and can extend 60 meter with 8 signage units operation
*Power redundancy support is available in 'redundancy on' mode
**An external power box needs to be purchased separately, and one operates up to 9 signage units in the length of 6 meter and can extend 60 meter with 8 signage units operation
***Images are for illustrative purpose only
* Uniformity among 13 points of the screen. Results based on in-house testing.Actual test results may differ depending on environment and measuring equipment.
* Results based on in-house testing, Actual test results may differ depending on environment and measuring equipment
* Uniformity among 13 points of the screen. Results based on in-house testing Actual test results may differ depending on environment and measuring equipment.
* The availability of "Signage 365Care" service can differ by region, so please contact the LG Sales representative in your region for further details.

PANEL

  • Screen Size
    55"
    Panel Technology
    IPS RGB
  • Aspect Ratio
    16:9
    Native Resolution
    1,920 x 1,080 (FHD)
  • Brightness(Typ.,cd/m²)
    700
    Contrast Ratio
    1,100:1
  • Viewing Angle (H x V)
    178 x 178
    Response Time
    8 ms (G to G)
  • Surface Treatment
    Haze 28%
    Life Time (Typ.)
    60,000 Hrs
  • Operation Hours
    24 Hrs
    Orientation
    Landscape & Portrait

CONNECTIVITY

  • Input
    HDMI(2), DP, DVI-D, Audio, USB
    Output
    DP, Audio
  • External Control
    RS232C In/Out, RJ45 (LAN) In/Out, IR In

MECHANICAL SPECIFICATION

  • Bezel Color
    Black
    Bezel Width
    0.44 mm (Even)
  • Monitor Dimension (W × H × D)
    1,210.5 x 681.2 x 86.5 mm
    Weight (Head)
    16.2 kg
  • Carton Dimensions (W × H × D)
    1,353 x 855 x 263 mm
    Packed Weight
    23.2 kg
  • Handle
    Yes
    VESA™ Standard Mount Interface
    600 x 400 mm

ENVIRONMENT CONDITIONS

  • Operation Temperature
    0°C to 40°C
    Operation Humidity
    10% to 80%

POWER

  • Power Type
    External Power Box (An external power box (LPLG001-FV) needs to be purchased separately.)

POWER CONSUMPTION

  • Typ.
    188W
    Max.
    240W

STANDARD(CERTIFICATION)

  • Safety
    TBD
    EMC
    FCC Class "A" / CE / KC

MEDIA PLAYER COMPATIBILITY

  • OPS type compatible
    Yes (Piggyback)
    External Media Player Attatchable
    Yes (MP500 / MP700)

SOFTWARE COMPATIBILITY

  • Content Management Software
    SuperSign CMS
    Control and Monitoring Software
    SuperSign Control/ Control+

ACCESSORY

  • Basic
    Remote Controller, RS232C Cable, Lan Cable, DP Cable, IR Receiver, Guide Bracket, Screws, Manual, Power loop cable
    Optional
    Wall Mount (Landscape : WM-L640V, Portrait : WM-P640V), External Power Box (LPLG001-FV3)), Power cable (6m, ACC-LAPPC06), Power cable (60m, ACC-LAPPC60)
