LDG3011ST

6.1 cu. ft. Capacity Gas Double Oven Range with 4 Sealed Gas Burners

KEY FEATURES

  • Maximum Usable Cook top Space in a Gas Double Oven
  • Large Capacity Gas Oven (6.1 cu ft)
  • IntuiTouch™ controls
  • 4 cooktop burners
6.1 cu. ft. Capacity Gas Double Oven Range with 4 Sealed Gas Burners

SUMMARY

    • Range Type
    • Double Door
    • Capacity
    • 6.1 cu.ft.
    • Color
    • Stainless Steel
    • Control System
    • Knobs/Keypad
    • Number of Burners
    • 4
    • Interior Color
    • Brilliant Blue
    • Self-Cleaning
    • Upper/Lower Ovens
    • No.of Racks
    • 2 Standard Racks, 1 Offset Rack (Standard)
    • Delay Clean
    • Yes
    • Delay Bake
    • Yes
    • Automatic Shut-Off
    • Yes
    • Warranty
    • 1 Year Parts and Labor

CAPACITY

    • Oven Capacity
    • 2.2 cu.ft. Upper / 3.9 cu.ft. Lower
    • Total Capacity
    • 6.1 cu. ft.

OVEN FEATURES

    • Configuration
    • Freestanding Gas Double Oven

POWER/RATINGS

    • KW / Amp Rating @120V
    • 11.65kW / 13.75A

DIMENSIONS

    • Cabinet Width
    • 30"
    • Overall Depth
    • 26 2/5"
    • Overall Height
    • 47 7/16"
    • Overall Width
    • 29 9/10"
    • Oven Interior (WxHxD) Upper
    • 24 1/2” x 9 9/16” x 18 15/16"
    • Oven Interior (WxHxD) Lower
    • 24 1/2" x 16 5/16" x 18 15/16"
    • Height to Cooking Surface
    • 36"
    • Product Weight
    • 228.1 lbs.
    • Shipping Weight
    • 268 lbs.

TYPE

    • Type
    • Free Standing Gas
    • Oven/Cooktop
    • IntuiTouch™/Knobs

FEATURES

    • Configuration
    • Freestanding Gas Double Oven
    • Control Type
    • Knobs/Keypad
    • Display
    • LED
    • Bake Burner (Upper)
    • 14500Btu/h / 13500Btu/h
    • Broil Burner (Upper)
    • 14500Btu/h / 13500Btu/h
    • Bake Burner (Lower)
    • 16,000 Btu/h / 13,000 Btu/h
    • Cooking Modes
    • Bake, Broil, Proof (Lower), Warm
    • Control Features
    • Delay Bake, Delay Clean, Automatic Shut-Off
    • Self-Cleaning
    • Upper/Lower Ovens
    • Oven Light
    • Yes
    • No. of Racks
    • 2 Standard Racks, 1 Offset Rack (Standard)
    • Large WideView™ Window
    • Yes

COOKTOP SPECIFICATIONS

    • Burner Type
    • Sealed Gas Burners
    • Configuration - Left Front
    • 12000Btu/h / 9500Btu/h
    • Configuration - Left Rear
    • 9100Btu/h / 9100Btu/h
    • Configuration - Right Front
    • 17000Btu/h / 10000Btu/h
    • Configuration - Right Rear
    • 5000Btu/h / 5000Btu/h

MATERIALS/FINISHES

    • Available Colors
    • Stainless Steel (ST)
    • Knobs
    • Stainless Material
    • Handle
    • Aluminum
    • Cooktop Finish
    • Grey Patterned on Black Ceramic Glass

WARRANTY/UPC

    • Limited Warranty
    • 1 Year Parts & Labor

What people are saying

Rated 5 out of 5 by from Love the double over I cannot remember how long I ago I bought this range but I love it and love it now. I will definitely buy a new just like it.
Date published: 2021-04-18
Rated 5 out of 5 by from It has the things that wanted. It was delivered about two weeks ago. I am happy with my choice.
Date published: 2021-03-14
Rated 5 out of 5 by from Standing by their product! This Evan for over eight years and love using it. It’s incredibly versatile with having a smaller upper oven as well as the larger lower oven. I think the convection oven cooks very evenly and I use it many times a week. I think it’s especially great for baking so I preferred only put in one cookie sheet at a time or one pizza at a time otherwise the lower tray will get overcooked.
Date published: 2020-12-12
  • y_2021, m_4, d_21, h_17
  • bvseo_bulk, prod_bvrr, vn_bulk_3.0.14
  • cp_1, bvpage1
  • co_hasreviews, tv_2, tr_15
  • loc_en_US, sid_MD00001349, prod, sort_[SortEntry(order=SUBMISSION_TIME, direction=DESCENDING)]
  • clientName_lg
  • bvseo_sdk, java_sdk, bvseo-4.0.0
  • CLOUD, getReviews, 7ms
  • REVIEWS, PRODUCT

ASK & ANSWER

Ask your questions. Share your answers.
Please review the detailed product information and help guides in the
Product Support section for this product prior to posting a question.

my lower oven burns yellow and smells like gas

Asked by: randy63
We regret the trouble you have experienced with this gas range. If the flames are burning yellow, instead of blue, then it would seem that the gas valves were not adjusted properly at the time of installation. It is recommended to contact your gas installer to ensure proper installation and operation.
Answered by: NeilE
Date published: 2016-12-10

Do u sell broiler pans for the lg double ovens

Asked by: Wiggles
I apologize, but no; the range manufacturer does not sell any cookware or broiler pans.
Answered by: NeilE
Date published: 2016-04-12

What is the temperature for the proof setting?   Thank you!

Asked by: Michellesa
We appreciate your interest in this gas range. The PROOF setting maintains a temperature between 100-125 degrees. According to page 29 of your owner’s manual, the PROOF function will not operate when the oven is above 125 degrees. HOT will show in the display.
Answered by: NeilE
Date published: 2016-01-19

What is the purpose of the off set rack?

We just got our LDG3036ST yesterday. During the leveling process, we discovered the off set rack is bowed and wondered what it is for. Thank you
Asked by: Mikey48
We appreciate your interest in the specifications of this oven and the off-set rack. This device is to allow additional room for large items to be cooked, while at the same time, cooking other items on the upper oven racks.
Answered by: NeilE
Date published: 2014-10-30

Is it possible to replace the decorative panel that covers the stoves control panel? It has been acidentally scratched.

Note: This is the panel at the top of the stove that houses the clock and oven controls.
Asked by: JB58
Yes, it is possible to replace the cover on the display panel. It is recommended to contact a technician who can perform this task without damage to the electronic control panel. To make service arrangements, you may either contact our Customer Interactive Center at 800-243-0000, or you can check our Repair Provider Lookup on our website, at http://www.lg.com/us/support/repair/support-repair-provider-lookup.jsp.
Answered by: NeilE
Date published: 2014-02-26

We just purchased a LDG3011ST. We do not have natural gas here. Do we need a conversion kit?

I called Sears Parts Direct because this was a floor model that had some missing parts (two burner ceramic covers) which we ordered. I asked them about a conversion kit and they do not stock them. Is the conversion system built into the stove itself? In the installation manual it says on page 15 that the conversion kit is located in the back of the unit. Is that correct? We have no natural gas in all of SW Florida so conversion is essential. Can it be converted?
Asked by: char33
Yes, the LP Orifice should be located on the back of the range, attached near the gas intake valve. The needed part number should be AGM73069206. Accessories can be obtained through our parts distributor, MCM Electronics. Their contact number, for placing orders, is 800-824-9491. You can also use their website, at http://www.mcmelectronics.com/content/en-US/forms/lg_parts.
Answered by: NeilE
Date published: 2013-10-22

What type/size range hood insert do I need for the LDG3011ST?

We are renovating our kitchen and had a custom wood hood made for over this LG oven. I'm trying to buy the range hood insert but am confused by all the different sizes and specs. What should I be looking for, like how much CFMs, etc.? Anyone have a specific suggestion? Thanks!
Asked by: jennmi
We appreciate your interest in this product and its accessories. LG only manufactures two vent hoods for over the range. These are the LSVC302ST and the LSV362ST. The deciding factor between these would be if you have a 30” range top or a 36” range top. These can both be reviewed on our website at http://www.lg.com/us/appliance-accessories/view-all.
Answered by: NeilE
Date published: 2013-10-22

Where can I purchase the broiler pan mentioned in the brochure?

Asked by: Honeypop
We appreciate your interest in this double oven range. The broiler pan will be an accessory available through either your local appliance store, or your local baking supply provider.
Answered by: NeilE
Date published: 2013-10-22
