LDG3017ST

6.1 cu. ft. Capacity Gas Double Oven Range with Infrared Grill and EasyClean™

6.1 cu. ft. Capacity Gas Double Oven Range with Infrared Grill and EasyClean™

SUMMARY

    • Range Type
    • Double Door
    • Cooktop Material
    • Porcelain
    • Capacity
    • 6.1 cu.ft.
    • Product Dimensions (WxHxD)
    • 29 9/10" x 35 9/10" x 26 2/5"
    • Color
    • Stainless Steel
    • WideView™ Window
    • Yes
    • Number of Burners
    • 5
    • Interior Color
    • Brilliant Blue
    • Self-Cleaning
    • Upper/Lower Ovens
    • Convection Bake/Roast
    • Yes
    • Convection Conversion
    • Yes
    • No.of Racks
    • 2 Standard Racks
    • No. of Rack Positions
    • 7
    • Delay Clean
    • Yes
    • Automatic Shut-Off
    • Yes
    • Oven Light
    • Yes
    • Knobs
    • Nikel Plating
    • Handles
    • Matching Stainless
    • Warranty
    • 1 Year Parts and Labor, 5 Years Glass Cooktop/ Electric Elements/Sealed Gas Burners

CAPACITY

    • Oven Capacity
    • 2.2 cu.ft. Upper / 3.9 cu.ft. Lower
    • Total Capacity
    • 6.1 cu. ft.

OVEN FEATURES

    • Configuration
    • Freestanding Gas Double Oven

POWER/RATINGS

    • Requirements
    • 120 VAC
    • KW / Amp Rating @120V
    • 11.65kW / 13.75A

DIMENSIONS

    • Cabinet Width
    • 30"
    • Overall Depth
    • 26 2/5"
    • Overall Height
    • 35 9/10"
    • Overall Width
    • 29 9/10"
    • Oven Interior (WxHxD) Upper
    • 24 1/2" x 8 4/5" x 19 1/5"
    • Oven Interior (WxHxD) Lower
    • 24 1/2" x 13 2/5" x 19 1/5"
    • Shipping Weight
    • 272 lbs.

TYPE

    • Type
    • Free Standing Gas

FEATURES

    • Configuration
    • Freestanding Gas Double Oven
    • Control Type
    • Knobs/Keypad
    • Display
    • VFD Scrolling
    • Bake Element (Upper)
    • 14500Btu/h / 13500Btu/h
    • Broil Element (Upper)
    • 18000Btu/h / 13500Btu/h (Infrared Grill)
    • Bake Element (Lower)
    • 16000Btu/h / 14000Btu/h
    • Convection Conversion
    • Yes
    • Convection Roast
    • Yes
    • Convection Bake
    • Yes
    • Cooking Modes
    • Bake, Broil, Proof, Warm
    • Control Features
    • Delay Bake, Delay Clean, Automatic Shut-Off
    • Self-Cleaning
    • Upper/Lower Ovens
    • Oven Light
    • Yes
    • No. of Racks
    • 2 Standard Racks
    • Large WideView™ Window
    • Yes

COOKTOP SPECIFICATIONS

    • Burner Type
    • Sealed Gas Burners
    • Configuration - Left Front
    • 12000Btu/h / 9500Btu/h
    • Configuration - Left Rear
    • 9100Btu/h / 9100Btu/h
    • Configuration - Center (Single Oval)
    • 8000Btu/h / 8000Btu/h
    • Configuration - Right Front
    • 17000Btu/h / 10000Btu/h
    • Configuration - Right Rear
    • 5000Btu/h / 5000Btu/h

MATERIALS/FINISHES

    • Available Colors
    • Stainless Steel (ST)
    • Knobs
    • Nikel Plating
    • Handle
    • Matching Stainless
    • Door
    • Full Stainless Steel Wrap
    • Cooktop Finish
    • Porcelain

WARRANTY/UPC

    • Limited Warranty
    • 1 Year Parts and Labor, 5 Years Glass Cooktop/ Electric Elements/Sealed Gas Burners

What people are saying

Rated 4 out of 5 by from My wife loves it. We use it for baking, broiling cooking and timing everything and anything Easy to clean
Date published: 2016-05-21
Rated 5 out of 5 by from I just bought it and so far I love it. It is beautiful and is easy to use. The pretty interior color is great.
Date published: 2015-09-29
Rated 5 out of 5 by from Overall I love this product . The stove top is quick as well as the oven and clean up in minutes!!
Date published: 2015-04-16
  • y_2020, m_11, d_30, h_15
  • bvseo_bulk, prod_bvrr, vn_bulk_3.0.12
  • cp_1, bvpage1
  • co_hasreviews, tv_1, tr_26
  • loc_en_US, sid_MD00001377, prod, sort_[SortEntry(order=SUBMISSION_TIME, direction=DESCENDING)]
  • clientName_lg
  • bvseo_sdk, java_sdk, bvseo-4.0.0
  • CLOUD, getReviews, 251ms
  • REVIEWS, PRODUCT

ASK & ANSWER

Ask your questions. Share your answers.
Please review the detailed product information and help guides in the
Product Support section for this product prior to posting a question.

I have a f19 error code

Asked by: Nadas
Our offices, in the United States, do not have product information for Canada. In order to obtain such information, it is recommended to check our subsidiary’s website, at http://www.lg.com/ca_en/index.jsp. You may also contact our Canada offices at 1-888-542-2623.
Answered by: NeilE
Date published: 2016-01-13

Clean internal glass in bottom oven

Liquid has dripped down the vent openings in the lower oven and now the glass has baked on drip lines. Is there a way to clean this?
Asked by: ihrslf
We regret the trouble you have experienced with this double gas range. These glass panes are not removable from the door, for cleaning purposes. As such, if the glass panes have something between them, the only option for cleaning them would be to obtain the assistance of a qualified technician.
Answered by: NeilE
Date published: 2015-02-16

LDG3017ST - The plastic film on the control panel is getting off

LDG3017ST - The plastic film on the control panel is getting off/Cracked, and getting fluffed. Is there any solution, can i buy this film and install it.
Asked by: Bharat
We regret the trouble you have experienced with this control panel. We have no suggestions available for the repair of a control panel, as we are not technicians. To make service arrangements, you may either contact our Customer Interactive Center at 800-243-0000, or you can check our Repair Provider Lookup on our website, at http://www.lg.com/us/support/repair/support-repair-provider-lookup.jsp.
Answered by: NeilE
Date published: 2014-08-08

LDE3017st standard racks and freestanding rack

Purchased this oven believing it to be "new" finding out it has only one shelf. Need additional shelf and freestanding rack.
Asked by: jude797
We regret the inconvenience you have experienced with this dual gas range. According to our information, this model should have 2 standard racks and one offset rack. Accessories can be obtained through our parts distributor, MCM Electronics. Their contact number, for placing orders, is 800-824-9491. You can also use their website, at http://www.mcmelectronics.com/content/en-US/forms/lg_parts. The part number for the 2 Standard Shelves is MHL61952101, and the other Shelf is MHL62131403.
Answered by: NeilE
Date published: 2014-06-30

What is the height to the top of the range, not to the top of the control?

I have a lower counter top now (about 35 1/2"). I wonder if this range will stick up a little.
Asked by: Beebo
36 inches
Answered by: Crystal79912
Date published: 2014-03-11

Is there a bread proofing mode?

The oven mode details say proof, but does the oven truly have a bread proofing mode? I've seen almost no double ovens with this feature.
Asked by: Quinn
I have used it many times to proof bread and it works great
Answered by: Crystal79912
Date published: 2014-03-11

Can the knobs be removed for cleaning?

Haven't figured out how to take off the knobs for easier cleaning.
Asked by: Crystal79912
Nothing "simple" about it, but I they did pull off with a lot of force.
Answered by: Crystal79912
Date published: 2014-03-11

I have the griddle that came with the range. The cooking surface is flat.. Is there one that can be purchased with ridges?

Asked by: klw56
I apologize, but no; we do not have any ridged-surfaced griddles available, nor are there any known that we might recommend.
Answered by: NeilE
Date published: 2013-10-22
