Discontinued
LRG3097ST

5.4 cu. ft. Capacity Premium Gas Single Oven Range with EvenJet™ Convection System and Warming Drawer

  • Large Capacity Oven
  • UltraHeat™ 19,000 BTU Burner
  • Convection Oven
  • Flat Broil Heater
5.4 cu. ft. Capacity Premium Gas Single Oven Range with EvenJet™ Convection System and Warming Drawer

SUMMARY

    • Range Type
    • Single Door
    • Cooktop Material
    • Stainless Steel
    • Capacity
    • 5.4 cu. ft.
    • Product Dimensions (WxHxD)
    • 29 15/16” x 47 5/8” x 26 29/32”
    • Color
    • Stainless Steel
    • WideView™ Window
    • Yes
    • Warming Drawer
    • Yes
    • Control System
    • SmoothTouch™/Knobs
    • Number of Burners
    • 5
    • Interior Color
    • Brilliant Blue
    • Electronic Clock & Timer
    • Yes
    • Control Lock Function
    • Yes
    • Audible Preheat Signal
    • Yes
    • Self-Cleaning
    • Yes
    • Special Functions
    • Temperature Unit of Measure (F/C) Beeper Volume (High, Low, Mute), Language: English or Spanish, Preheating Alarm Light On/Off
    • Languages
    • English / Spanish
    • Door Lock
    • Yes
    • Burner Power (BTUs)
    • Left Front (High Output): 12,000 BTU, Left Rear (All Purpose): 9,100 BTU, Center: 8,000 BTU, Right Front (UltraHeat™): 19,000 BTU, Right Rear (Simmer): 5,000 BTU
    • Convection System
    • EvenJet™ Advanced Convection System
    • Convection Bake/Roast
    • Yes
    • Convection Conversion
    • Yes
    • Variable Cleaning Time
    • 2 hr, 3 hr, 4 hr
    • Delay Clean
    • Yes
    • Broil Burner
    • 15,500 BTU Flat Broiler
    • Bake Burner
    • 18,000 BTU
    • Delay Bake
    • 12 Hours
    • Automatic Shut-Off
    • After 12 Hours
    • Oven Light
    • GoCook™ Smart Oven Light
    • Capacity
    • 1.0 cu. ft.
    • Type
    • Warming
    • Oven Interior
    • Brilliant Blue
    • Knobs
    • Matching Metal
    • Other Colors
    • Smooth White, Smooth Black
    • Handles
    • Matching Commercial Handle

OVEN FEATURES

    • Configuration
    • Freestanding Gas Oven with Storage Drawer

DIMENSIONS

    • Width
    • 29 15/16"
    • Height (to top of cooktop)
    • 36"
    • Height (to top of backguard)
    • 47 5/8"
    • Depth (including door)
    • 26 1/2"
    • Depth (including handle)
    • 26 29/32"
    • Oven Capacity (WxHxD)
    • 24 1/2" X 19 1/2" X 19 11/16"
    • Drawer (WxHxD)
    • 23" x 4 11/16" x 16 1/2"
    • WideView™ Window (WxH)
    • 19 19/32 x 11 1/32"
    • Net Weight
    • 237 lbs

TYPE

    • Type
    • Free Standing Gas
    • Oven/Cooktop
    • SmoothTouch™/Knobs

FEATURES

    • Display
    • White VFD
    • Electronic Clock & Timer
    • Yes
    • Control Lock Function
    • Yes
    • Audible Preheat Signal
    • Yes
    • Special Functions
    • Temperature Unit of Measure (F/C) Beeper Volume (High, Low, Mute), Language: English or Spanish, Preheating Alarm Light On/Off
    • Door Lock
    • Yes

COOKTOP SPECIFICATIONS

    • Type
    • Stainless Steel Cooktop
    • No. of Radiant Elements
    • 5
    • Element Size and Wattage (Left Front)
    • 12K
    • Element Size and Wattage (Left Rear)
    • 9.1K
    • Element Size and Wattage (Center Rear - Warming Zone)
    • 8K
    • Element Size and Wattage (Right Front)
    • UltraHeat 19K
    • Element Size and Wattage (Right Rear)
    • 5K

OVEN SPECIFICATIONS

    • Capacity
    • 5.4 cu. ft.
    • Type
    • Self-Cleaning
    • Variable Cleaning Time
    • 2hr, 3hr, 4hr
    • Delay Clean
    • Yes
    • Broil Burner
    • 15.5k BTU
    • Broiler Type
    • Flat Broiler
    • Bake Burner
    • 18K BTU
    • Convection System
    • Dual True Convection (Convection Bake & Convection Roast)
    • Convection Conversion
    • Yes
    • Delay Bake
    • 12 Hours
    • Automatic Shut-Off
    • After 12 Hours
    • WideView™ Window
    • Yes
    • GoCook™ Smart Oven Light
    • Yes
    • Interior Oven Light Adjustment
    • 1, Auto/Manual

DRAWER

    • Capacity
    • 1.0 cu. ft.
    • Type
    • Warming

MATERIALS/FINISHES

    • Available Colors
    • Stainless Steel (ST)
    • Oven Interior
    • Brilliant Blue
    • Knobs
    • Matching Metal
    • Handle
    • Matching Commercial Handle

POWER SOURCE

    • Electrical Requirements
    • 1.14kW/9.5A, 120 VAC

WARRANTY/UPC

    • Limited Warranty
    • One Year Parts & Labor

What people are saying

Rated 5 out of 5 by from overall function I purchased this range 3 years ago, I am very happy with my gas range. It bakes wonderful, the burners work great, I especially like the extra large burner and the oval burner in the middle. After preheating is done, the oven lets me know its time to bake. The warming drawer on the bottom is a plus. Overall function is excellent for me. Happy Customer!!!
Date published: 2016-04-21
Rated 5 out of 5 by from large capacity oven,great a bit pricey,but easy to use and clean up is a breeze. I would recommend to my friends.
Date published: 2015-01-13
Rated 5 out of 5 by from Amazing range!!! My family loves this range. It has it all, large oven, even a warming draw. The burners are insane. pastat is half the time. Looks beautiful in my new kitchen. No issues alt all...what an appliance..
Date published: 2014-04-17
  • y_2020, m_9, d_19, h_15
  • bvseo_bulk, prod_bvrr, vn_bulk_3.0.12
  • cp_1, bvpage1
  • co_hasreviews, tv_1, tr_21
  • loc_en_US, sid_MD00001000, prod, sort_[SortEntry(order=SUBMISSION_TIME, direction=DESCENDING)]
  • clientName_lg
  • bvseo_sdk, java_sdk, bvseo-4.0.0
  • CLOUD, getReviews, 7ms
  • REVIEWS, PRODUCT

ASK & ANSWER

Ask your questions. Share your answers.
Please review the detailed product information and help guides in the
Product Support section for this product prior to posting a question.

How to clean the external wall

Asked by: Clipper
To clean the stainless steel surface, use warm sudsy water or a stainless steel cleaner/polish. Always wipe the surface in the direction of the grain. Information on cleaning the stainless steel may be found on page 40 of the owner's manual. If you are in need of any further assistance, our support team may be reached via Twitter @LGUSSupport. ^ST
Answered by: Shena
Date published: 2017-10-26

Cleaning Stove Top of LRG3097ST Stainless.

What type of cleaner should we use on the stainless stove top. I know it should not be abrasive but what do you recommend to keep it clean. We have had our stove for about a year or so.
Asked by: Bo4bby
To clean the stainless steel surface, use warm sudsy water or a stainless steel cleaner or polish. Always wipe the surface in the direction of the grain. Follow the cleaner instructions for cleaning the stainless steel surface.
Answered by: NeilE
Date published: 2015-03-20

adjust burner flame setting

Page 12 installation manual explains how to adjust the flame. Somehow I can not find the adjustment scwew. It is a new stove, so is clean. LRG3097ST
Asked by: GasinMiami
We regret the trouble you have experienced with this gas range. If this cannot be located, the gas valve may need to be adjusted by a qualified technician. To make service arrangements, you may either contact our Customer Interactive Center at 800-243-0000, or you can check our Repair Provider Lookup on our website, at http://www.lg.com/us/support/repair/support-repair-provider-lookup.jsp.
Answered by: NeilE
Date published: 2014-06-17

Is there a specific place to rough in gas piping for the LRG3097 gas stove

Asked by: martinbrendan
We appreciate your interest in this gas range. Check the installation specifications attached.
Answered by: NeilE
Date published: 2018-09-03

How to clean the glass inside the door of a gas range?

Is there away to clean the glass on a gas range if something spills inside the door between the glass?
Asked by: LGclean
I apologize, but no; there is no method available for the owner to access the space between the glass panes on the range door. Any such adjustment to the glass should only be attempted by a service technician. However, such a cleaning is not covered by the manufacturer’s warranty. It is for such reasons that it is recommended to quickly clean spills and splatters before they have a chance to run between the panes.
Answered by: NeilE
Date published: 2013-10-22

My second knob keeps turning even when it is at the off position. It dosen't lock like my other knobs. Do I have to replace it?

The white part in the knob seems to have a crack. Is that the reason why it dosen't lock when it is in the off position?
Asked by: adida
From your description, it would seem that the plastic core of the knob may have cracked and is the cause for it to continue turning. The knob will need to be replaced. Please contact our Customer Interactive Center at 800-243-0000 to obtain parts information.
Answered by: NeilE
Date published: 2013-10-22

I WILL BE PURCHASING LG LRG3097ST - RANGE. WHAT KIND/SIZE OF HOOD WILL I REQUIRE?

Asked by: ziontagteam
This range is 30" wide, you will want to consider a range hood of at least 30" or larger.
Answered by: tk247
Date published: 2013-10-22

What type of plug/connector does it come with

Would like to know if the range comes with the power cord with plug/wall connector. If so, what is they type of plug/wall connectory
Asked by: DT
This range comes with the power cord already attached , it is a standard 110v plug.
Answered by: tk247
Date published: 2013-10-22
