LSES302ST

Key features

  • Extra-Large capacity oven space (5.4)
  • Dual True Convection with 3 convection modes
  • Brilliant Blue Interior
  • Award winning LG design
Specifications
Download Spec Sheetdownload-guide iconDownload Energy Guide
  • DRAWER
  • WARRANTY/UPC
  • OVEN FEATURES
  • SUMMARY
  • DIMENSIONS
  • POWER SOURCE
  • OVEN SPECIFICATIONS
  • COOKTOP SPECIFICATIONS
  • TYPE
  • FEATURES
  • MATERIALS/FINISHES
  • See All
    • DRAWER
    Capacity
    1.0 cu. ft.
    Type
    Bake Drawer
    DRAWER
    Capacity
    1.0 cu. ft.
    Type
    Bake Drawer
    WARRANTY/UPC
    Limited Warranty
    2 Years Parts and Labor, 5 Years Limited on Cooktop and Radiant Surface Units
    UPC
    048231316705
    OVEN FEATURES
    Configuration
    Slide-in Electric Oven
    True Convection
    Yes
    SUMMARY
    Oven Interior
    Brilliant Blue
    Knobs
    Matching Metal
    Handles
    Matching Commercial Handle
    Range Type
    Single Door
    Capacity
    5.4 cu. ft.
    Product Dimensions (WxHxD)
    29 7/8" x 36" x 28 7/8"
    Color
    Stainless Steel
    Convection System
    Dual True Convection
    Control System
    SmoothTouch™/Knobs
    Number of Radiant Elements
    5
    Interior Color
    Brilliant Blue
    Electronic Clock & Timer
    Yes
    Control Lock Function
    Yes
    Audible Preheat Signal
    Yes
    Self-Cleaning
    Yes
    Special Functions
    Temperature Unit of Measure (F/C) Beeper Volume (High, Low, Mute), Language: English or Spanish, Preheating Alarm Light On/Off
    Languages
    English / Spanish
    Door Lock
    Yes
    Warming Zone
    Yes
    Element Size and Wattage
    Left Front: 6”, 9”/1400W & 3000W, Left Rear: 6”/1200W, Center Rear (Warming Zone): 7”/100W, Right Front: 6”, 9”, 12”/1100W, 2200W, 3000W, Right Rear: 6”/1200W
    Convection Bake/Roast
    Yes
    Convection Conversion
    Yes
    No.of Racks
    2 Full, 1 Gliding, 1 Split
    No. of Rack Positions
    7
    Variable Cleaning Time
    2 hr, 3 hr, 4 hr
    Delay Clean
    Yes
    Broil Element
    6 Pass / 4000W
    Bake Element
    6 Pass/3400W
    Delay Bake
    12 Hours
    Automatic Shut-Off
    After 12 Hours
    Oven Light
    GoCook™ Smart Oven Light
    Capacity
    1.0 cu. ft.
    Type
    Bake Drawer
    WideView™ Window
    Yes
    LG STUDIO
    Yes
    DIMENSIONS
    Overall Height
    36"
    Overall Width
    29 7/8"
    Oven Capacity (WxHxD)
    24 1/2" x 19 11/16" x 19 3/8"
    Drawer (WxHxD)
    22 1/4" x 5" x 16 1/2"
    WideView™ Window (WxH)
    20 1/4" x 12 1/4"
    Net Weight
    216 lbs.
    POWER SOURCE
    Electrical Requirements
    120/240 VAC, 120/208 VAC, 15.3kW/40A, 11.5kW/40A
    OVEN SPECIFICATIONS
    Capacity
    5.4 cu. ft.
    Type
    Self-Cleaning
    Variable Cleaning Time
    2hr, 3hr, 4hr
    Delay Clean
    Yes
    Broil Element
    6 Pass/4000W
    Bake Element
    6 Pass/3400W
    Delay Bake
    12 Hours
    Convection System
    Dual True Convection (Convection Bake & Convection Roast)
    Convection Conversion
    Yes
    Automatic Shut-Off
    After 12 Hours
    WideView™ Window
    Yes
    GoCook™ Smart Oven Light
    Yes
    Interior Oven Light Adjustment
    2, Auto/Manual
    No. of Racks/Positions
    2 Full, 1 Gliding, 1 Split/7
    COOKTOP SPECIFICATIONS
    Type
    Radiant
    No. of Radiant Elements
    5
    Warming Zone
    Yes
    Element Size and Wattage (Left Front)
    6", 9"/1400W & 3000W
    Element Size and Wattage (Left Rear)
    6"/1200W
    Element Size and Wattage (Center Rear - Warming Zone)
    6"/100W
    Element Size and Wattage (Right Front)
    6", 9", 12"/1100W, 2200W, 3000W
    Element Size and Wattage (Right Rear)
    6"/1200W
    TYPE
    Type
    Electric Slide-In
    Oven/Cooktop
    SmoothTouch™/Knobs
    FEATURES
    Electronic Clock & Timer
    Yes
    Control Lock Function
    Yes
    Audible Preheat Signal
    Yes
    Special Functions
    Temperature Unit of Measure (F/C) Beeper Volume (High, Low, Mute), Language: English or Spanish, Preheating Alarm Light On/Off
    Door Lock
    Yes
    Display
    VFD
    MATERIALS/FINISHES
    Oven Interior
    Brilliant Blue
    Available Colors
    Stainless Steel (ST)
    Handle
    Matching Commercial Handle
    Knobs
    Matching Metal
