LDS5040WW

Front Control Dishwasher with Flexible EasyRack™ System

KEY FEATURES

  • EasyRack™
  • 10-Year Limited Wararnty on Inverter Direct Drive Motor
  • LoDecibel™ Operation - 50 dB
  • SmartDiagnosis™ System
Front Control Dishwasher with Flexible EasyRack™ System

CAPACITY

    • Total Place Settings
    • 14
    • Upper Rack Dish Height Limit
    • 12"
    • Lower Rack Dish Height Limit
    • 14"

RACKS AND BASKETS

    • Cutlery Baskets
    • 3-in-1 Detachable Baskets
    • Racks and Tines
    • Nylon Coated with Rounded Tips
    • EasyRack™ System
    • Yes
    • EasyRack™ System: Upper Rack Color-Coded Foldable Tines (2 Rows)
    • Yes
    • EasyRack™ System: Height Adjustable Upper Rack
    • Yes
    • EasyRack™ System: Lower Rack Color-Coded Foldable Tines
    • Yes

STYLE AND DESIGN

    • Electronic Controls
    • Front Control Physical Tactile Buttons with LED Display
    • Time Remaining Indicator
    • Yes
    • Rinse-Aid Indicator
    • Yes
    • Tub Material
    • NeveRust™ Stainless Steel
    • Available Colors
    • White (WW), Black (BB), Stainless Steel (ST)

FEATURES

    • LoDecibel™ Quiet Operation
    • Yes
    • Slim Direct Drive Motor
    • Yes
    • Overflow Detector
    • Yes
    • 120°F Inlet Water Capability
    • Yes
    • Self-Cleaning Filtration System
    • Yes
    • Delay Start
    • Up To 19 Hours
    • Child Lock
    • Yes

PERFORMANCE

    • Number of Wash Cycles
    • 5
    • Wash Cycles
    • Power Scrub, Normal, Delicate, Quick, Upper Only
    • SenseClean™ Wash System
    • Yes
    • Sanitary Rinse Cycle
    • Yes
    • Extra Rinse Option
    • Yes
    • Multi-Level Water Direction
    • 5
    • Hybrid Condensing Drying System
    • Yes
    • Noise Level
    • 50 dB

POWER SOURCE/RATING

    • Ratings/Requirements/Type
    • UL Listed/120 V, 12 Amps/60 Hz
    • Circuit Breaker Size
    • 15 Amps

DIMENSIONS

    • Unit Dimensions (WxHxD)
    • 23 3/4" x 33 1/2" x 24 5/8"
    • Required Clearances (WxHxD)
    • 24” x 33 1/2" x 24”
    • Carton Dimensions (WxHxD)
    • 27 1/5" x 35 1/10" x 29 3/5"
    • Weight (Unit/Carton)
    • 89.0 lbs / 96 lbs

WARRANTY/UPC

    • Limited Warranty
    • 1 Year Labor, 2 Year Parts, 5 Years Limited on Control Board and Rack Parts, 10 Years Direct Drive Motor, Lifetime on the Stainless Steel Tub and Door Liner
    • UPC
    • 048231 012126

What people are saying

Rated 3 out of 5 by from dishwasher is ok My wife and I use to own an LG LDS5040WW dishwasher. It was great. The normal washing cycle was close to two hours long and the dishes, silverware and the dish racks were dry when the cycle ended. Now we have this dishwasher, LG LDF5545WW. The normal washing cycle takes just over three hours. To get the dishes and silverware to dry most of the time I have turned on two options. The first option is “Extra Dry” and the second one is “High Heat.” The dishes and silverware are mostly dry when the cycle ends, but the dish racks are still wet. When I remove the silverware from the holder water can get on the silverware. that’s why I must dry some of the silverware manually. Most of the time the dishes seem fine. Why it takes an extra hour to run the same cycle is beyond me. I have no idea what they have done to the new dishwasher but the old one worked a lot better. It’s as if they went backwards with the technology. Maybe the reason the water doesn’t dry on the racks is they might not have metal in them anymore. I like the fact that there is no heating element at the bottom like a lot of the other dishwashers have. The heating element on this unit like our last dishwasher is built-in. You can also download a different wash cycle only if you have a phone that supports NFC (Near-Field-Communication) option. My phone does not. Neither do either of my tablets. Would I buy this dishwasher again if I knew about these issues? I guess I would but my wife and I miss our old dishwasher. It worked great.
Date published: 2020-12-13
Rated 1 out of 5 by from Don't recommend Purchased 5 years ago. got extremely loud about year 4. had a burning plastic smell last week, took off front cover to find arcing.
Date published: 2019-03-24
Rated 2 out of 5 by from Poor design I love my other LG appliances, but this dishwasher is a complete disappointment. The bottom rack pulls all the way out too easily and is very difficult to replace on its tracks. The top rack does not accommodate stemware, such as wineglasses. Very disappointing.
Date published: 2016-09-14
  • y_2021, m_5, d_8, h_18
  • bvseo_bulk, prod_bvrr, vn_bulk_3.0.15
  • cp_1, bvpage1
  • co_hasreviews, tv_2, tr_33
  • loc_en_US, sid_MD05030060, prod, sort_[SortEntry(order=SUBMISSION_TIME, direction=DESCENDING)]
  • clientName_lg
  • bvseo_sdk, java_sdk, bvseo-4.0.0
  • CLOUD, getReviews, 36ms
  • REVIEWS, PRODUCT

ASK & ANSWER

Ask your questions. Share your answers.
Please review the detailed product information and help guides in the
Product Support section for this product prior to posting a question.

Hello- I have this in right and was wondering if I can switch the panel out for stainless steel? Is it possible to get these parts?

Asked by: charliesangel
To find replacement parts and accessories for the LG Semi-Integrated Dishwasher with Flexible EasyRack™ System, Model # LDS5040WW you can contact the LG Authorized Parts Distributor in your region: Andrews Electronics 25158 Avenue Stanford Santa Clarita, CA 91355 Sales : 877-389-6384 Fax : 800-289-0301 http://lge.andrewselectronics.com...^IFV
Answered by: LGJoel
Date published: 2015-11-18

My dishwasher stopped working in middle of cycle and won't go on.

Asked by: Nade
We regret the trouble you have experienced with this dishwasher. It is recommended to deactivate the circuit breaker to this device for about 30 seconds, and then reactivate it. Check to see if the unit can begin operating again. If it does not, then it may require service. To make service arrangements, you may either contact our Customer Interactive Center at 800-243-0000, or you can check our Repair Provider Lookup on our website, at http://www.lg.com/us/support/repair/support-repair-provider-lookup.jsp.
Answered by: NeilE
Date published: 2015-10-08

Is there a grey or stainless face option instead of white?

Asked by: Hornswoggle
The LG Semi-Integrated Dishwasher with Flexible EasyRack™ System, Model # LDS5040** is available in Black and in Stainless Steel...^IFV
Answered by: LGJoel
Date published: 2015-09-23

Does LG have Dishwasher with Custom Panel ready door

Asked by: Archemeritus
Regrettably no. The LG Semi-Integrated Dishwasher with Flexible EasyRack™ System, Model # LDS5040WW does not have a Custom Panel ready door. LG does not do Custom Ready Panels...^IFV
Answered by: LGJoel
Date published: 2017-01-27

Does the LDS5040WW have a 3rd rack? The video under features shows a 3rd rack but my dishwasher doe not have one. It is misleading

I ordered this dishwasher because the video shows a 3rd rack however it seems this model does not come with one. Why show a video that is misleading on its features? Otherwise I am happy with this dishwasher. I would love an answer before I review the product. Thanks!
Asked by: foxglove22
We regret your dissatisfaction with this dishwasher. Our documentation for this model all shows a 2 wash rack design. The images of the interior of this model, which are posted on our website, all show 2 wash racks inside this unit. There are no installation points available for another rack of dishes.
Answered by: NeilE
Date published: 2015-04-24

Is there a recommended dishwashing detergent for LG dishwasher

The installer told me that only finish tablets were to be used. I've always used Cascade liquid. Is there really a reason to only use Finish?
Asked by: denise123
We appreciate your interest in this dishwasher. We do not recommend any one particular detergent over another. What is recommended is that a RINSE AGENT also be used in conjunction with the detergent. The RINSE AGENT should be added to the appropriate dispenser.
Answered by: NeilE
Date published: 2014-06-27

what is the hybrid condensing drying system on a dishwasher?

how does the lg dishwasher dry
Asked by: lowes
Our old dishwasher had an electric element that heated the dishes after washing to dry them. We never used it. The dishes always dried by themselves. The LG has no element. The dishes dry by themselves without any additional heat. It is an electricity saving step I believe.
Answered by: Daviddi
Date published: 2013-12-05

What does error alert FE stand for?

We get an alert of FE at least 2-3 times per month ever since we got the unit. Once we start the cycle over again, it usually makes it through without another error. Would like to know what this means and how to avoid it in the future.
Asked by: kgoldt
We regret the trouble you have experienced with this dishwasher. The FE Error Code indicates an excessive amount of water has been supplied. In such a situation, the unit will likely require service. To make service arrangements, you may either contact our Customer Interactive Center at 800-243-0000, or you can check our Repair Provider Lookup on our website, at http://www.lg.com/us/support/repair/support-repair-provider-lookup.jsp.
Answered by: NeilE
Date published: 2013-12-04
