Discontinued
55EC9300
Curved OLED 1080p Smart TV - 55'' Class (54.6'' Diag)
  • OLED for True Blacks & Stunning Color
  • webOS 2.0 Simplicity
  • Elegant, Pencil-Thin, Curved Design
  • GREENGUARD GOLD Certified
Curved OLED 1080p Smart TV - 55" Class (54.6" Diag)

Dimensions

View of an LG 55EC9300 showing its dimensions. View of an LG 55EC9300 showing its dimensions.

SUMMARY

  • Diagonal Class
    55 inches
    Diagonal Size
    54.6 inches
  • Resolution
    1920 x 1080
    Display Type
    OLED
  • Display Format
    Full HD 1080p
    HDMI Port(s)
    4
  • Other Input(s)
    3 USB 2.0, 1 RF In (Antenna/Cable), 1 Component Video In(Y, Pb, Pr + Audio), 1 Composite In (AV) - shared w/Component, 1 Digital Audio Out (Optical), 1 LAN, 1 RS-232 (mini jack)
    Smart TV Operating System
    webOS 2.0
  • Refresh Rate
    -
    Speaker System
    2ch Speaker System
  • Other Features
    Triple XD Engine, Tru Color Generator, Resolution Upscaler, Perfect Black Panel, Wide Viewing Angle

LG SMART TV FEATURES

  • Premium Content
    Yes
    Full Web Browser
    Yes
  • Magic Remote Control
    Yes
    Natural Voice Recognition
    Yes
  • Universal Control Capability
    Yes
    Launcher Bar
    Yes
  • Games
    Yes
    Easy Setup
    Yes
  • Recent/Multitasking
    Yes
    LivePlus
    Yes
  • Live Menu
    Yes
    LG Content Store (App Store)
    Yes

Smart Share

  • Media Share
    Yes
    - Remote App
    Yes
  • - Network File Browser
    Yes
    - YouTube Send-to-TV
    Yes
  • Screen Share
    Yes
    - MHL (Mobile HD Link)
    Yes
  • - Miracast
    Yes
    - WiDi
    Yes

Audio

  • Speaker System
    2ch Speaker System
    Mono/Stereo/Dual (MTS/SAP)
    Yes
  • Dolby® Digital Decoder
    Yes
    DTS Decoder
    Yes
  • Audio Output (Watts - THD 10%)
    40W
    Sound System
    ULTRA Surround
  • Sound Mode
    6 Modes
    Clear Voice II
    Yes
  • Sound Optimizer
    3 Modes
    Optical Sound Sync
    Yes
  • Wireless Sound Sync
    Yes
    Smart Sound Mode
    Yes

CONNECTIVITY

  • Wi-Fi® Built-in
    Yes
    Wi-Fi Direct
    Yes
  • SIMPLINK™ (HDMI™ CEC)
    Yes
    USB
    Yes
  • - Video
    DivX HD
    - Photo
    JPEG, JPS, MPO
  • - Audio
    AC3 (Dolby Digital), EAC3, HE-AAC, AAC, MPEG, MP3, PCM, DTS

AV INPUTS/OUTPUTS

  • RF In (Antenna/Cable)
    1 (Rear)
    Component Video In(Y, Pb, Pr + Audio)
    1 (Rear)
  • Composite In (AV)
    1 (shared w/Component)
    HDMI®
    4 HDMI (3 Side, 1 Rear)
  • Digital Audio Out (Optical)
    1 (Rear)
    USB 2.0
    3 (Side)
  • LAN
    1 (Rear)
    RS-232 (mini jack)
    1 (Side)

POWER

  • Power Supply (Voltage, Hz)
    100V ~ 240V, 50/60 Hz
    Standby Mode
    0.3W

DIMENSIONS / WEIGHT

  • TV without Stand (WxHxD)
    48.2" x 28.1" x 3.1"
    TV with Stand (WxHxD)
    48.2" x 29.6" x 8"
  • TV without Stand Weight
    31.7 lbs
    TV with Stand Weight
    36.1 lbs
  • TV Shipping Dimensions (WxHxD)
    52.4" x 33.3" x 10"
    Shipping Weight
    49.2 lbs

Warranty / UPC

  • Limited Warranty
    1 Year Parts & Labor
    UPC
    719192594388

PANEL SPECIFICATIONS

  • Screen Size Class (diagonal)
    55" Class (54.6" diagonal)
    Resolution
    1920 x 1080
  • Display Type
    OLED

VIDEO

  • Triple XD™ Engine
    Yes
    Resolution Upscaler
    Yes
  • Tru Color Generator
    Yes
    Smart Picture Mode
    Yes
  • Picture Mode
    8 Modes
    Aspect Ratio
    8 Modes
  • Just Scan (1:1 Pixel Matching)
    HDMI, Component, RF: 0% OverScan 1080i, 1080p, 720p
    Real Cinema 24p (2:2 pull down)
    Yes
  • Picture Wizard III
    Yes

LG CINEMA 3D FEATURES

  • 3D Type
    FPR (Passive)
    3D to 2D/2D to 3D
    Yes
  • 3D Depth Control
    Yes
    3D Viewpoint Control
    20 Levels
  • 3D Image Correction
    Yes

CABINET / ACCESSORIES

  • Remote Control
    Magic Remote
    3D Glasses
    F314 (Clip 2EA, F310 2EA)
  • Wall Mounting Bracket
    Wall Mount OSW100 required and sold separately.
What people are saying
Rated 1 out of 5 by from TV's Life is NOT Good Just short of 3 years the panel has to be replaced.Part is too expensive to fix TV unless LG authorize repair.LG's Executive Department no help. Why LG will not replace the part so my TV can be fixed.
Date published: 2018-11-15
Rated 5 out of 5 by from Best Picture Ever I love this TV. The LG apps work great. The picture is the best you can get and burn in has not been in issue for the 4 years I have owned the TV.
Date published: 2018-10-06
Rated 4 out of 5 by from Inspiring design with great features. I have had this LG TV for 4 years now. I love the features and functions of my TV. However, a flawed power supply is not representative of a quality product. Power supply are simple and have been mastered for many years by electronic manufacturers
Date published: 2018-05-21
  • y_2019, m_10, d_20, h_8
  • bvseo_bulk, prod_bvrr, vn_bulk_2.0.13
  • cp_1, bvpage1
  • co_hasreviews, tv_1, tr_110
  • loc_en_US, sid_MD05118600, prod, sort_[SortEntry(order=SUBMISSION_TIME, direction=DESCENDING)]
  • clientName_lg
  • bvseo_sdk, java_sdk, bvseo-4.0.0
  • CLOUD, getReviews, 6ms
  • REVIEWS, PRODUCT
ASK & ANSWER

Ask your questions. Share your answers.
Please review the detailed product information and help guides in the
Product Support section for this product prior to posting a question.

How do download Hulu?

Asked by: Julie22
Applications are downloadable through the Content Store. If an application is not listed in the content store it is not available for download.
Answered by: ChrisPSM
Date published: 2019-08-04

Is it possible to listen to headphones as well as the main sound on the TV simultaneously?

Asked by: emylesquinn
The built-in speakers and audio outputs on the LG Curved OLED 1080p Smart TV - 55" Class (54.6" Diag), Model # 55EC9300 will be deactivated when streaming audio to Bluetooth headphones or speaker...^IFV
Answered by: LGJoel
Date published: 2019-03-15

I need lg55ec9300 model panel you have the panel

Asked by: Abhimitha
Hello, for a panel repair, you will need to have a service technician. This may be done through our website: https://www.lg.com/us/support/repair-service/schedule-repair-continued or for a list of service centers in your area: https://www.lg.com/us/support/repair-service/find-repair-provider ^AC
Answered by: Amber C
Date published: 2019-01-15

speakers at bottom of unit only 2 in center sound like they are working.

Asked by: Magmag
Performing a sound test will test all of the speakers on your TV and let you know if there are any issues to be aware of. For information regarding how to perform a sound test please refer to the following user guide: http://www.lg.com/us/support-product/lg-55EC9300#manuals ^CP
Answered by: ChrisPSM
Date published: 2018-05-02

What LG wireless headphones are compatible with this TV?

Asked by: Enitsirhcxxx
Bluetooth headsets with Sound Sync capability are compatible with this TV. ^CP
Answered by: ChrisPSM
Date published: 2017-12-09

How much would it cost to get my tv fixed I don't kno what's wrong wit it. 55EC9300 series

Asked by: Jose412
We regret the inconvenience you have experienced with this television. Unfortunately, without knowing the cause of the problem, it will not be possible to speculate on the repair charges; especially since service technicians set their own service rates. To make service arrangements, you may either contact our Customer Interactive Center at 800-243-0000, or you can check our Repair Provider Lookup on our website, at http://www.lg.com/us/support/repair/support-repair-provider-lookup.jsp.
Answered by: NeilE
Date published: 2017-06-28

What is the small blue dot on screen?

Asked by: Noner
We regret the inconvenience you have experienced with this television. There are no features of this model which are designed to place a blue dot on the screen. If this is a recurring symptom on this screen, then the TV may require service. To make service arrangements, you may either contact our Customer Interactive Center at 800-243-0000, or you can check our Repair Provider Lookup on our website, at http://www.lg.com/us/support/repair/support-repair-provider-lookup.jsp.
Answered by: NeilE
Date published: 2017-04-24

Where can I purchase this TV? Are there other LG TV'S of comparable size, features, and value as the 55EC9300?

Asked by: Potential Cistomer
The LG Curved OLED 1080p Smart TV - 55" Class (54.6" Diag), Model # 55EC9300 is a 2014 model that is now discontinued and is no longer available in stores unless a retailer has some models in their inventory. Unfortunately, once a product is discontinued, we will not have information on who would still have it. There are other 55" OLED TVs in our lineup that you may be interested in looking at like the LG C6 Curved OLED 4K HDR Smart TV - 55" Class (54.6" Diag), Model # OLED55C6P or the LG Curved OLED 4K Smart TV - 55" Class (54.6" Diag), Model # 55EG9600 or the LG Curved OLED 1080p Smart TV - 55" Class (54.6" Diag), Model # 55EG9100. There are other 55" OLEDs in our lineup that have flat screens and are not curved and you can find those at http://www.lg.com/us/oled-tvs...^IFV
Answered by: LGJoel
Date published: 2017-02-23
