Discontinued
WM5005HKA
4.5 cu.ft. Ultra Large Capacity w/ On-Door Control Panel & TurboWash®
  • 4.5 cu. ft. Ultra Large Capacity
  • SmartThinQ™ Technology
  • TurboWash® Technology
  • LG Steam Technology
  • Direct Drive Motor 10-Year Limited Warranty
  • LG SideKick™ Compatible
4.5 cu.ft. Ultra Large Capacity w/ On-Door Control Panel & TurboWash®

SUMMARY

  • Design Style
    Front Loader
    Capacity
    4.5 cu.ft.
  • Dimensions (WxHxD)
    27" x 38 13/16" x 32 13/16" (55" D with door open)
    TurboWash™
    Yes

APPEARANCE

  • On-Door Electronic Control Panel with LED Display
    Yes
    Touch Buttons
    Yes
  • Dial-A-Cycle™
    Yes

WASH PROGRAMS

  • No. of Programs
    14
    Wash Programs
    Cotton/Normal, Perm. Press/Casual, Delicates, Speed Wash, TubClean™, Sanitary, Allergiene™, Heavy Duty, BrightWhites™, Towels, Rinse+Spin, Download, Sportswear, Bedding
  • No. of Options
    14
    Options
    Prewash, Delay Wash, Extra Rinse, Child Lock, ColdWash™, FreshCare™, PGM Save, Steam, TurboWash™, Custom Program, Drum Light, Smart Grid, Wi-fi Connect, Remote Start
  • No. of Wash/Rinse Temps
    5 (Extra Hot, Hot, Warm, Cold, Tap Cold (All Cold Rinses)
    Spin Speeds
    Extra High (1,300 max.), High, Medium, Low, No Spin
  • No. of Water Levels
    Automatically adjusts to the size of load
    No. of Soil Levels
    5

FABRIC CARE FEATURES

  • TurboWash® 2.0 Technology
    Yes
    Steam Technology
    Yes
  • Sanitary Cycle
    Yes
    ColdWash™ Option
    Yes
  • SenseClean™ System
    Yes

CONVENIENCE FEATURES

  • TrueBalance™ Anti-Vibration System
    Yes
    4 Tray Dispenser
    Prewash, Main Wash (with liquid detergent cup), Bleach, Fabric Softener
  • LoDecibel™ Quiet Operation
    Yes
    End of Cycle Signal
    Yes
  • LoadSense
    Yes
    Child Lock
    Yes
  • Auto Suds Removal
    Yes
    Forced Drain System
    Yes
  • Easy Loading TilTub™
    Yes
    Leveling Legs
    4 Adjustable Legs
  • SmartDiagnosis™
    Yes (v 3.0)
    Smart ThinQ™ (Wi-Fi)
    Smart Grid Ready, Smart Access, Smart Adapt, Energy Monitoring, Laundry Starts

MOTOR AND AGITATOR

  • Motor Type
    Inverter Direct Drive Motor
    Motor Speed
    Variable
  • Max RPM
    1,300
    Axis
    Horizontal

MATERIALS AND FINISHES

  • NeveRust™ Stainless Steel Drum
    Yes
    Cabinet
    PCM
  • Control Panel
    Plastic
    Top Plate
    Painted
  • Door Rim
    Glass/Chrome
    Door Cover
    Dark Black Tinted Round Cover
  • Door Opening
    40 1/2"
    Available Colors
    Black Stainless Steel (K)

POWER SOURCE

  • Ratings
    UL Listed
    Electrical Requirements
    120V, 10 Amps
  • Type
    Electric

ACCESSORIES

  • Hose Included
    Yes

OPTIONS

  • Pedestal
    WDP4K
    Pedestal (WxHxD)
    27" x 13 3/5" x 28 2/5"
  • LG Sidekick™ Pedestal Washer
    WD100CK
    LG Sidekick™ Pedestal Washer (WxHxD)
    27” x 14 1/10” x 30 4/5”

DIMENSIONS

  • Product (WxHxD)
    27" x 38 13/16" x 32 13/16" (55" D with door open)
    Carton (WxHxD)
    29 7/32" x 42 3/8" x 33 7/32"
  • Weight (Product/Carton)
    210.0 lbs / 232.0 lbs

WARRANTY

  • Limited Warranty
    1 Year Parts and Labor, 10 Years Motor, Lifetime on Drum
    UPC
    048231020657
What people are saying
Rated 1 out of 5 by from Circuit Board Failed 2 Months After Delivery When this washer worked, it was great. I purchased this washer in Nov 2016. In January 2017, two months after delivery the keypad began randomly blinking and locked. The washer was totally inoperative. I performed the troubleshooting and followed the LG reset procedure. This procedure is to turn off the breaker (or unplug the washer), hold the on/off button for 10 seconds, then turn on the breaker (or plug the washer back in). After doing the LG reset procedure, it worked normally for about 2 weeks. Then it did the same thing again. The washer worked normally after one reset. Then it did the same thing again about one week after that. Reset worked, but since I had purchased the service plan via Lowe's, I called Lowe's. The earliest technician appointment was 10 days after that initial call. During the 10 days the problems with the washer continued to escalate, random blinking and beeping, and a locked keypad. Multiple resets were required to get the washer to work. It went to a daily occurrence and then every load. Finally the day prior to the scheduled service appointment, the washer totally failed. No lights, nothing. Reset 6-10 times with no effect. Tested outlet, it was fine. Switched to a different outlet, washer still totally inoperative. Plugged another appliance into the outlet the washer had been in, that appliance worked fine, so there's nothing wrong with the outlet. It's the washer. This morning the technician called before coming out to the scheduled appointment and told me the circuit boards and keypads are backordered and he doesn't know if it will be days, weeks, or months before they come in. He also said even after the board and keypad come in, it will be at least a week before he can come out to install them. This is unacceptable! This washer is less than 4 months old! It seems LG didn't accurately anticipate the demand for circuit boards and keypads for this washer and didn't manufacture enough spares. Whether that's because they anticipated a lower failure rate, or there's a supplier issue, I don't know and it's irrelevant...parts should be available in a reasonable amount of time. I don't consider this reasonable...I waited 10 days for the service appointment to be told there is an indefinite backorder, and another week after that for installation. It's going to take a lot for me to ever purchase another LG product again, of any type.
Date published: 2017-03-14
  • y_2019, m_9, d_17, h_7
  • bvseo_bulk, prod_bvrr, vn_bulk_2.0.13
  • cp_1, bvpage1
  • co_hasreviews, tv_0, tr_1
  • loc_en_US, sid_MD05786649, prod, sort_[SortEntry(order=SUBMISSION_TIME, direction=DESCENDING)]
  • clientName_lg
  • bvseo_sdk, java_sdk, bvseo-4.0.0
  • CLOUD, getReviews, 192ms
  • REVIEWS, PRODUCT
ASK & ANSWER

Ask your questions. Share your answers.
Please review the detailed product information and help guides in the
Product Support section for this product prior to posting a question.

Can i use the dryer without going throu a was cycle

Asked by: GWWW
We are sorry; we are only able to support products in the USA. For the proper support channels, please see www.lg.com/mx/soporte ^AC
Answered by: Amber C
Date published: 2018-02-27

I just got one of these washing machines and the sidekick pedestal delivered yesterday along with the matching dryer. Just wondering if there was supposed to be a laundry detergent sample pack included with the washing machines? Last machine I bought did.

Asked by: A Friend In Florida
We appreciate your interest in this washer and its accessories. This unit does not include any type of laundry detergent sample pack.
Answered by: NeilE
Date published: 2017-10-03

How to I get rid of terrible sour smell.from my lg front loading washer.   What is your recommendation

Asked by: Abcdefgz
We regret the trouble you have experienced with this washing machine. It is recommended to check the drain hose for any obstructions that might produce such a smell. It is also suggested to run the TUB CLEAN cycle using about a cup of vinegar, which can break down any soap residue which might be generating this smell. Please contact our Customer Interactive Center at 800-243-0000 for additional support.
Answered by: NeilE
Date published: 2017-09-12

There was a problem with this style washer not being compatible with iOS. Has that been remedied?

Asked by: Nickerson13
The issue with the LG 4.5 cu.ft. Ultra Large Capacity w/ On-Door Control Panel & TurboWash®, Model # WM5005HKA not being compatible with iOS was about the LG Smart Laundry & DW app for the SmartDiagnosis™ (v. 3.0) feature that you can download from the iTunes Store for iOS devices. Although the App (Version 2.1.0) is available in the iTunes Store, the issue is that it requires NFC for it to work. Apple added NFC hardware to the iPhone 6 and iPhone 6 Plus to support the Apple Pay mobile payment system in the fall of 2014 . But that was the only thing the iPhone could do with NFC. Apple didn’t open up SDK access to the NFC controller for other developers, so the NFC hardware inside the phone was severely limited to the types of applications it could be used for and it cannot use the other tag technologies that include printed barcodes and QR codes, Bluetooth based tags such as Apple’s iBeacon and BLE, UHF RFID and a handful of other lesser known technologies...IFV
Answered by: LGJoel
Date published: 2017-11-14

Can this be stacked with a Dryer?

Asked by: Mike55
No, due to the drawer for detergent being located on top.
Answered by: Nickerson13
Date published: 2018-04-22

Does this washer have a fan to circular the air until the clothes are taken out like other washers?

Asked by: Witt
The LG 4.5 cu.ft. Ultra Large Capacity w/ On-Door Control Panel & TurboWash®, Model # WM5005HKA does not "have a fan in it to circulate the air until clothes are taken out like other washers"...^IFV
Answered by: LGJoel
Date published: 2017-09-23

The. Letters CL keep flashing on the time remaining light

Asked by: Angel83
The CL indicator is shown when the CHILD LOCK feature is active, as is shown on page 30 of the owner’s manual. Press and hold the PREWASH button for 3 seconds in order to deactivate this option.
Answered by: NeilE
Date published: 2017-01-19

Ours vibrates when on high spin, anything I can do to remedy it? It's located on the second floor laundry room.

Asked by: Wired360
We regret the trouble you have experienced with this washing machine. Confirm that this washing machine has been properly leveled, and that the floor is stable to the point that it will not transfer vibration from the machine to the walls. If this does not resolve the matter, then the washer may require service. To make service arrangements, you may either contact our Customer Interactive Center at 800-243-0000, or you can check our Repair Provider Lookup on our website, at http://www.lg.com/us/support/repair/support-repair-provider-lookup.jsp.
Answered by: NeilE
Date published: 2017-01-10
