All Spec
PANEL
-
Screen Size
65" (164 cm)
-
Panel Technology
IPS
-
Aspect Ratio
16:9
-
Native Resolution
1920 x 1080 (Full HD)
-
Brightness
450cd/m²
-
Contrast Ratio
1,300 : 1 (Native)
-
Dynamic CR
4,000,000:1
-
Viewing Angle (H x V)
H:178°, V:178°
-
Orientation
Portrait and Landscape
-
Surface Treatment
Hard coating(3H), Anti-glare treatment (Haze 1% Typ.)
-
Operating Hours
24 Hrs
-
Response Time
10ms (G to G BW), 7.6ms (WOT)
CONNECTIVITY INPUT(REAR)
-
Digital
HDMI(1, Support HDCP 2.2), DP(1), DVI-D(1)
-
Analog
RGB (1)
-
Audio
RGB/DVI (1), Speaker (10W x 2)
-
External Control
RS232C (1), RJ45 (1), IR (1), Pixel Sensor (1)
-
USB
Yes (1, USB3.0)
-
SD Card
Yes (1, SDHC/Full Size)
-
Wi-Fi/Bluetooth
Dual Band (802.11n) / (802.15.1)
CONNECTIVITY OUTPUT(REAR)
-
Digital
DP Out (1)
-
Analog
Yes (1)
-
External Control
RS232C (1)
PHYSICAL SPECIFICATION
-
Bezel Width
11.9mm(T/R/L), 18mm(B)
-
Monitor Dimension(W x H x D)
1457mm x 838mm x 56.5mm
-
Dimension with optional stand (W x H x D)
1457mm x 898mm x 220mm
-
Carton Dimensions(W × H × D)
1561mm x 951mm x 170mm
-
Weight (head)
27.9kg
-
Weight(head+stand)
32.9kg
-
Packed Weight
33.8kg
-
VESA™ Standard Mount Interface
300mm x 300mm
SPECIAL FEATURES
-
Additional
Time, Tile Mode, Colour Settings, Languages, Internal Memory(4GB), DPM Select, File Play with USB, USB Cloning, Input Label, Smart Energy Saving, Built -in Speakers, SD Card Slot, Sync Mode
ENVIRONMENT CONDITIONS
-
Operation Temperature
0°C to 40°C
-
Operation Humidity
10% to 80%
POWER
-
Power Supply
100-240V~, 50/60Hz
-
DPM
0.7W
-
Typical / Smart Energy Saving On
125W/85W
-
Power Off
0.5W
-
Power Type
Built In Power
STANDARD(CERTIFICATION)
-
Safety
UL/cUL/CB/TU/KC
-
EMC
FCC Class "B" / CE / KCC / C-Tick
-
ErP/US EPA
NA / Yes (Energy Star 6.0)
MEDIA PLAYER COMPATIBILITY
-
External Media Player Attachable
Yes (MP500/MP700), KT-OPSA(OPS)
SOFTWARE COMPATIBILITY
-
SuperSign-c
Yes
-
SuperSign-w lite
Yes
ACCESSORY
-
Included
Remote Controller (including 2ea battery), Power Cable, QSG, RGB Cable, Regulation Book, Phono to RSC232C Gender, Memory Cover
-
Optional
Stand(ST-652T), Media Player, OPS Kit(KT-OPSA), Wall bracket (LSW230B), Pixel Sensor(KT-SP0), VESA Adapter(AM-B220S), HDBaseT(EB-B100)
-
Warranty
3 years (Parts and Labour)
