Alle specificaties
SEIZOENSEFFICIËNTIEGEGEVENS(VERWARMING)
-
Seizoensgebaseerde ruimteverwarming eff. klasse (35℃ / 55℃)
-
A+++/A+++
-
Seizoensgebaseerde ruimteverwarming efficiëntie (ηS) (35℃ / 55℃)
-
215 / 156
-
SCOP (35℃ / 55℃)
-
5.45 / 3.97
NOMINALE CAPACITEIT EN COP(A+7/W+35)
-
Verwarmingscapaciteit (kW)
-
12.00
-
COP
-
4.70
NOMINALE CAPACITEIT EN COP(A+2/W+35)
-
Verwarmingscapaciteit (kW)
-
12.00
-
COP
-
3.72
NOMINALE CAPACITEIT EN COP(A-7/W+35)
-
Verwarmingscapaciteit (kW)
-
11.80
-
COP
-
3.27
NOMINALE CAPACITEIT EN COP(A+7/W+55)
-
Verwarmingscapaciteit (kW)
-
10.00
-
COP
-
3.10
NOMINALE CAPACITEIT EN COP(A-7/W+55)
-
Verwarmingscapaciteit (kW)
-
9.30
-
COP
-
2.32
NOMINALE CAPACITEIT EN EER(A+35/W+18)
-
Koelingscapaciteit (kW)
-
11.50
-
EER
-
3.78
NOMINALE CAPACITEIT EN EER(A+35/W+7)
-
Koelingscapaciteit (kW)
-
10.50
-
EER
-
3.12
OPERATIONEEL GEBRUIK(BUITENLUCHTTEMPERATUUR)
-
Verwarming en warm water (Min. ~ Max.) (℃)
-
-28 ~ 35
-
Koeling (Min. ~ Max.) (℃)
-
5 ~ 48
OPERATIONEEL GEBRUIK(WATERTEMPERATUUR BIJ UITSTROOM)
-
Verwarming (Min. ~ Max.) (℃)
-
15 ~ 75
-
Koeling (Min. ~ Max.) (℃)
-
5 ~ 27
-
Warm water (Min. ~ Max.) (℃)
-
15 ~ 80
KOELMIDDEL
-
Type
-
R290
-
GWP
-
3
-
Voorgeladen hoeveelheid (g)
-
1,200
PIJPLEIDINGEN(WATER/BUITENEENHEID)
-
Inlaatdiameter (inch)
-
Male PT 1"
-
Uitlaatdiameter (inch)
-
Male PT 1"
PIJPLEIDINGEN(WATER/BINNENEENHEID)
-
Inlaat-/uitlaatdiameter voor ODU-verbinding (inch)
-
Male PT 1"
-
Inlaat-/uitlaatdiameter voor ruimteverwarming (inch)
-
Male PT 1"
GELUIDSNIVEAU(BUITENEENHEID)
-
Nominaal / laag geluidsniveau (dB(A))
-
49 / 48
GELUIDSNIVEAU(BINNENEENHEID)
-
Nominaal (dB(A))
-
39
GELUIDSDRUKNIVEAU OP 5 METER(BUITENEENHEID, OMZETTING MET SWL)
-
Nominaal / laag geluidsniveau (dB(A))
-
27 / 26
GELUIDSDRUKNIVEAU OP 1 METER(BINNENEENHEID, OMZETTING MET SWL)
-
Nominaal (dB(A))
-
31
AFMETINGEN
-
Buiteneenheid (B × H × D) (mm)
-
1,560 x 1,019 x 520
-
Binneneenheid (B × H × D) (mm)
-
490 x 850 x 315
GEWICHT
-
Binneneenheid (leeg) (kg)
-
30.0
-
Buiteneenheid (leeg) (kg)
-
181.0
BUITEN
-
Kleur van chassis buiteneenheid (kleur/RAL-code)
-
Dawn gray / RAL 7037
-
Kleur van rooster voorkant buiteneenheid (kleur/RAL-code)
-
Dark dawn gray / RAL 7012
-
Binneneenheid (kleur/RAL-code)
-
Noble white / RAL 9016
STROOMTOEVOER
-
Voltage, fase, frequentie voor buiteneenheid (V, Ø, Hz)
-
380 ~ 415, 3, 50
-
Voltage, fase, frequentie voor binneneenheid (V, Ø, Hz)
-
220 ~ 240, 1, 50
INFORMATIE OVER NALEVING
