- Brillo: 390 nit (sin vidrio, típ.)
- Punto multitáctil: 20 puntos (máx.)
- Interfaz: HDMI (3), RGB (1), entrada de audio (1), entrada RS-232C (1), RJ45 (1), USB 3.0 tipo A (3), USB 2.0 tipo A (1), tipo USB 3.1 C (1), salida de audio/salida óptica, USB táctil (2)
Todas las especificaciones
PANEL
Screen size
86"
panel technology
IPS
Back Light Type
Direct
aspect ratio
16:9
native resolution
3840 x 2160 (UHD)
Refresh Rate
60Hz
Brightness
490nit (wo Glass Max.),390nit (wo Glass Typ.), 335nit (wo Glass, Min.) 450nit (w Glass, Max.),350nit (w Glass, Typ.), 300nit (w Glass Min.)
contrast ratio
1200:1
Color gamut
NTSC 68% (Typ.)
Viewing angle (H x V)
178x178
color depth
10 bits (8 bits + FRC)
Response time
6.5ms(G to G)
Surface Treatment(Haze)
Anti Glare, 7Mohs, Haze 28%
Life time
30,000 Hrs (Typ.)
Operation Hours (Hours/Day)
16/7
Portrait / Landscape
No / Yes
CERTIFICATION
Safety
CB / NRTL
EMC
FCC Class "A" / CE
ErP / Energy Star
Yes / No
MECHANICAL SPECIFICATION
bezel color
Black
Bezel Width
17.7/17.7/17.7/45.7mm
Weight(Head)
65.75Kg
packed weight
75.9kg
Monitor Dimension(W x H x D)
1957×1160×87mm
Carton Dimensions(W x H x D) (Box outer size)
2110×225×1283mm
Handle
Yes
VESA™ Standard Mount Interface
800 x 600
KEY FEATURE
HW
Internal Memory 32GB, Built-in Wi-Fi (Slot type), Power Indicator, Local Key Operation
SW
webOS ver. (Android 9.0), Background Image (Booting Logo Image), Screen Share (Screenshare pro), 3rd Party Compatibility Crestron Inside, Power (Smart Energy Saving, PM mode, Wake on LAN, Network Ready), HDMI-CEC
SOUND
Speaker
Yes (12W x 2)
OPS COMPATIBILITY
OPS type compatible
Yes (Slot)
OPS Power built in
Yes
SOFTWARE COMPATIBILITY
Signage 365 Care
Yes
LANGUAGE
OSD
English, Simplified Chineses, Catalan, Czech, Denmark, Arabic(Egypt), Finnish, French, German, Greek, Italian, Japanese, Korean, Netherlands(Dutch), Norwegian, Polski, Portugues(Europe),Portugues(Brazil) Romanian, Russian, Spanish, Swedish, Turkish, Ukrainian, Traditional Chinese, Hungarian, Latvian, Thai
ACCESSORY
Basic
Power Cord 3 M*1, USB Cable (Type A-Type B) 5 M*1, HDMI Cable 3 M*1, Writing Pen*2pcs, User Manual, QSG, Carton Box, Remote Controller(include battery 2ea), Wifi module
ANDROID SYSTEM
SoC
Quad Core A73
GPU
Mail G52 Multi Core 2
Internal Memory - Storage
32GB
Internal Memory - RAM
4GB
Wi-Fi
802.11a/b/g/n/ac
LAN
Gigabit LAN
bluetooth
Bluetooth 5.0
CONNECTIVITY(JACK INTERFACE)
Input
HDMI (3, HDCP2.2/1.4),Audio In, RS232C IN, RJ45(LAN), IR IN, USB3.0 Type A(4), USB2.0 Type A(1), USB3.1 Type C (1, USB-PD, DP-Alt. Mode)
Output
HDMI Out, Audio Out, Optical,Touch USB (2), RJ45(LAN)
ENVIRONMENT CONDITIONS
Operation Temperature
0 °C to 40 °C
Operation Humidity
10% ~90%RH
POWER
Power Supply
AC 100-240V~, 50/60Hz
Power Type
Built-In Power
POWER CONSUMPTION
Typ.
TBD
Max.
575W
BTU (British Thermal Unit)
TBD
DPM
Yes
Power off
0.5W↓
SPECIAL FEATURE
Touch - Available object size for touch
Ø3 mm ↑
Touch - Reponse Time (PC Win10)
60ms ↓ (Android)100ms ↓ (Windows)
Touch - Accuracy
±2mm
Touch - Interface
USB2.0
Touch - Protection Glass Thickness
4T (Anti-Glare)
Touch - Protection Glass Transmission
87%
Touch - Operating System Support
Windows 7/8/10/WindowsXP/Linux/Mac/Android(WindowsXP/Linux/Mac Support one point touch)
Touch - Multi touch point
Max 20 Points
