Pantalla Interactiva UHD 86’’ TR3PJ

Pantalla Interactiva UHD 86’’ TR3PJ

Pantalla Interactiva UHD 86’’ TR3PJ

86TR3PJ-B
LG Pantalla Interactiva UHD 86’’ TR3PJ, 86TR3PJ-B
LG Pantalla Interactiva UHD 86’’ TR3PJ, 86TR3PJ-B
LG Pantalla Interactiva UHD 86’’ TR3PJ, 86TR3PJ-B
LG Pantalla Interactiva UHD 86’’ TR3PJ, 86TR3PJ-B
LG Pantalla Interactiva UHD 86’’ TR3PJ, 86TR3PJ-B
LG Pantalla Interactiva UHD 86’’ TR3PJ, 86TR3PJ-B
LG Pantalla Interactiva UHD 86’’ TR3PJ, 86TR3PJ-B
LG Pantalla Interactiva UHD 86’’ TR3PJ, 86TR3PJ-B
LG Pantalla Interactiva UHD 86’’ TR3PJ, 86TR3PJ-B
LG Pantalla Interactiva UHD 86’’ TR3PJ, 86TR3PJ-B
LG Pantalla Interactiva UHD 86’’ TR3PJ, 86TR3PJ-B
LG Pantalla Interactiva UHD 86’’ TR3PJ, 86TR3PJ-B
LG Pantalla Interactiva UHD 86’’ TR3PJ, 86TR3PJ-B
LG Pantalla Interactiva UHD 86’’ TR3PJ, 86TR3PJ-B

Características principales

  • Brillo: 390 nit (sin vidrio, típ.)
  • Punto multitáctil: 20 puntos (máx.)
  • Interfaz: HDMI (3), RGB (1), entrada de audio (1), entrada RS-232C (1), RJ45 (1), USB 3.0 tipo A (3), USB 2.0 tipo A (1), tipo USB 3.1 C (1), salida de audio/salida óptica, USB táctil (2)
Imprimir

Todas las especificaciones

PANEL

  • Screen size

    86"

  • panel technology

    IPS

  • Back Light Type

    Direct

  • aspect ratio

    16:9

  • native resolution

    3840 x 2160 (UHD)

  • Refresh Rate

    60Hz

  • Brightness

    490nit (wo Glass Max.),390nit (wo Glass Typ.), 335nit (wo Glass, Min.) 450nit (w Glass, Max.),350nit (w Glass, Typ.), 300nit (w Glass Min.)

  • contrast ratio

    1200:1

  • Color gamut

    NTSC 68% (Typ.)

  • Viewing angle (H x V)

    178x178

  • color depth

    10 bits (8 bits + FRC)

  • Response time

    6.5ms(G to G)

  • Surface Treatment(Haze)

    Anti Glare, 7Mohs, Haze 28%

  • Life time

    30,000 Hrs (Typ.)

  • Operation Hours (Hours/Day)

    16/7

  • Portrait / Landscape

    No / Yes

CONNECTIVITY(JACK INTERFACE)

  • Input

    HDMI (3, HDCP2.2/1.4),Audio In, RS232C IN, RJ45(LAN), IR IN, USB3.0 Type A(4), USB2.0 Type A(1), USB3.1 Type C (1, USB-PD, DP-Alt. Mode)

  • Output

    HDMI Out, Audio Out, Optical,Touch USB (2), RJ45(LAN)

MECHANICAL SPECIFICATION

  • bezel color

    Black

  • Bezel Width

    17.7/17.7/17.7/45.7mm

  • Weight(Head)

    65.75Kg

  • packed weight

    75.9kg

  • Monitor Dimension(W x H x D)

    1957×1160×87mm

  • Carton Dimensions(W x H x D) (Box outer size)

    2110×225×1283mm

  • Handle

    Yes

  • VESA™ Standard Mount Interface

    800 x 600

KEY FEATURE

  • HW

    Internal Memory 32GB, Built-in Wi-Fi (Slot type), Power Indicator, Local Key Operation

  • SW

    webOS ver. (Android 9.0), Background Image (Booting Logo Image), Screen Share (Screenshare pro), 3rd Party Compatibility Crestron Inside, Power (Smart Energy Saving, PM mode, Wake on LAN, Network Ready), HDMI-CEC

ENVIRONMENT CONDITIONS

  • Operation Temperature

    0 °C to 40 °C

  • Operation Humidity

    10% ~90%RH

POWER

  • Power Supply

    AC 100-240V~, 50/60Hz

  • Power Type

    Built-In Power

POWER CONSUMPTION

  • Typ.

    TBD

  • Max.

    575W

  • BTU (British Thermal Unit)

    TBD

  • DPM

    Yes

  • Power off

    0.5W↓

SOUND

  • Speaker

    Yes (12W x 2)

CERTIFICATION

  • Safety

    CB / NRTL

  • EMC

    FCC Class "A" / CE

  • ErP / Energy Star

    Yes / No

OPS COMPATIBILITY

  • OPS type compatible

    Yes (Slot)

  • OPS Power built in

    Yes

SOFTWARE COMPATIBILITY

  • Signage 365 Care

    Yes

LANGUAGE

  • OSD

    English, Simplified Chineses, Catalan, Czech, Denmark, Arabic(Egypt), Finnish, French, German, Greek, Italian, Japanese, Korean, Netherlands（Dutch), Norwegian, Polski, Portugues(Europe),Portugues(Brazil) Romanian, Russian, Spanish, Swedish, Turkish, Ukrainian, Traditional Chinese, Hungarian, Latvian, Thai

ACCESSORY

  • Basic

    Power Cord 3 M*1, USB Cable (Type A-Type B) 5 M*1, HDMI Cable 3 M*1, Writing Pen*2pcs, User Manual, QSG, Carton Box, Remote Controller(include battery 2ea), Wifi module

SPECIAL FEATURE

  • Touch - Available object size for touch

    Ø3 mm ↑

  • Touch - Reponse Time (PC Win10)

    60ms ↓ (Android)100ms ↓ (Windows)

  • Touch - Accuracy

    ±2mm

  • Touch - Interface

    USB2.0

  • Touch - Protection Glass Thickness

    4T (Anti-Glare)

  • Touch - Protection Glass Transmission

    87%

  • Touch - Operating System Support

    Windows 7/8/10/WindowsXP/Linux/Mac/Android(WindowsXP/Linux/Mac Support one point touch)

  • Touch - Multi touch point

    Max 20 Points

ANDROID SYSTEM

  • SoC

    Quad Core A73

  • GPU

    Mail G52 Multi Core 2

  • Internal Memory - Storage

    32GB

  • Internal Memory - RAM

    4GB

  • Wi-Fi

    802.11a/b/g/n/ac

  • LAN

    Gigabit LAN

  • bluetooth

    Bluetooth 5.0
