28BQ780-B
27.6” 16:18 SDQHD DualUp Ergonomic Monitor with Nano IPS Technology, USB-Type C™, Dynamic Action Sync, & Flicker Safe
/
1/16
27.6” 16:18 SDQHD DualUp Ergonomic Monitor with Nano IPS Technology, USB-Type C™, Dynamic Action Sync, & Flicker Safe
$
699.00
Stack It Up
Free up desk space and multitask efficiently with a new, 16:18 aspect ratio stacked setup that swivels, freeing up your desk without giving up the screen space of a double monitor.
*Simulated image.
-
Stunning Image Quality
SDQHD (2560 x 2880) Nano IPS
DCI-P3 98% (Typ.) & HDR10 -
Ergonomics
Ergonomic Stand with C-Clamp
Various Movement of Display -
User Convenience
USB Type-C™
Easy Installation
Ergo Stand
Customizable Display
Tap into the flexibility of the Ergo Stand to optimize your setup. Adjust the monitor by moving it forward or backwards, swiveling, rotating, tilting and more. Configure the setup to increase your productivity and immerse yourself in your work.
*Ergo Stand: Extend/Retract 210mm, Swivel ±335°, Pivot 90° (Counterclockwise), Height 130mm, Down Height 35mm, Tilt ±25°
**The product images in the video are for illustrational purpose only and might differ from the real product.
**The product images in the video are for illustrational purpose only and might differ from the real product.
SDQHD Nano IPS Display
Color Your Work
The 27.6-inch SDQHD Nano IPS display supports a wide color spectrum - DCI-P3 98%** - offering a vibrant color reproduction.
*The images simulated to enhance feature understanding. It may differ from actual use.
**DCI-P3 Typical 98%, Minimum 90%
**DCI-P3 Typical 98%, Minimum 90%
Ambient Light Sensor
Ambient Light Sensor with Auto Brightness
The ambient light sensor makes the screen brighter in bright lighting conditions and decreases the brightness in darker lighting conditions.
*The images simulated to enhance feature understanding. It may differ from actual use.
Flexible Workstation for Flexible Creating, Developing, and Multitasking
The LG DualUp Monitor with Ergo stand helps boost productivity by creating a flexible workstation and allowing for a better, more comfortable posture.
For Programmers
When coding, see more code and text on the screen without needing to scroll
For Creators & Streamers
Edit, stream, and view email, chat, or other collaborative tools.
For Designers
The 28BQ780-B’s wide screen allows for editing many layers at a glance while also taking up less surface area within a workspace.
For Office Workers
Increase efficiency by viewing multiple files simultaneously on the vertically extended display.
*The images simulated to enhance feature understanding. It may differ from actual use.
USB Type-C™
Multiple Devices—One Cable
Seamlessly connect to external devices or charge your laptop with the convenience of USB Type-C™ with up to 90W power delivery.
Display
Power Delivery
Data
*To work properly, the USB Type-C™ cable included in the package is required to connect the USB Type-C™ port to the monitor.
Additional Ways to Utilize the DualUp Monitor
-
![PBP, picture-by-picture, built-in KVM]()
Picture-by-Picture & Built-in KVM*
With the PBP feature you can display content from two different computers on the monitor and use the KVM feature to manage the content with a single keyboard and mouse.
-
![By connecting two cables, you can utilize a dual monitor setup.]()
One Source Picture by Picture**
By connecting your laptop to the LG DualUp monitor via the HDMI, DisplayPort***, or USB Type C™, you can easily control both displays without using software or shortcut keys.
*KVM: Keyboard, Video Monitor, and Mouse.
**It can be connected via the USB Type-C™ cable, HDMI cable, and USB2.0 upstream cable included with the package.
***DisplayPort cable is NOT included with the package.
**It can be connected via the USB Type-C™ cable, HDMI cable, and USB2.0 upstream cable included with the package.
***DisplayPort cable is NOT included with the package.
Clutter-Free Desk Setup
Fully Use Your Desk
The Ergo Stand's compact design takes up very little desk surface, helping users achieve a clutter-free environment, while the C-Clamp & Grommet and One Click Mount make it easy to install.
*For detailed installation instructions, see the product manual at LG.com Support page.
*The product images in the video are for illustrational purposes only and might differ from the real product.
*Simulated image.
*Actual features, functionality, and other product specifications may differ and are subject to change without notice.
*The product images in the video are for illustrational purposes only and might differ from the real product.
*Simulated image.
*Actual features, functionality, and other product specifications may differ and are subject to change without notice.
DISPLAY
-
- Diagonal
- 27.6"
- Resolution
- 2560 x 2880
-
- Panel Type
- IPS
- Backlight Technology
- LED
-
- Backlight Type
- Edge
- Backlight Array
- H1B
-
- Backlight Dimming Technology
- Global Dimming
- Aspect Ratio
- 16:9
-
- Pixel Pitch
- 0.18195 x 0.18195mm
- Brightness (Typ.)
- 300nits
-
- Color Gamut (Typ.)
- DCI-P3 98% (CIE1976)
- Color Depth (Number of Colors)
- 1.07B
-
- Color Bit
- 10bit (8bit+FRC)
- Contrast Ratio (Typ.)
- 1000:1
-
- Contrast Ratio with DFC
- Mega
- Response Time
- 5ms (GtG)
-
- Viewing Angle (CR≥10)
- 178° (R/L), 178° (U/D)
- Surface Treatment
- Anti-Glare
FEATURES
-
- HDR 10
- Yes
- HDR Effect
- Yes
-
- Nano IPS™ Technology
- Yes
- Wide Color Gamut
- Yes
-
- Color Calibrated
- Yes
- Auto Brightness
- Yes
-
- Flicker safe
- Yes
- Picture Mode
- (Non HDR Contents) ‐‐> Custom, Vivid, HDR Effect, Reader, Cinema, FPS, RTS, Color Weakness
-
- Reader Mode
- Yes
- Super Resolution+
- Yes
-
- Black Stabilizer
- Yes
- Dynamic Action Sync
- Yes
-
- User Define Key
- Yes
- Auto Input Switch
- Yes
-
- PBP
- Yes (2PBP)
- Others Features
- Low Blue Light, Built‐in KVM
SW APPLICATION
-
- Dual Controller
- YES
- OnScreen Control / Switch
- Yes
INTERFACES
-
- HDMI
- Yes (2ea)
- HDMI Version
- 2.0
-
- HDMI (HDCP Version)
- 2.2
- HDMI (V Frequency)
- 60Hz
-
- HDMI (Max. Resolution at Hz)
- 2560 x 2880 @ 60Hz
- DisplayPort
- Yes (1ea)
-
- DP Version
- 1.4
- DP (HDCP Version)
- 2.2
-
- DP (V Frequency)
- 60Hz
- USB‐C
- Yes (1ea)
-
- USB‐C (DP Version)
- 1.4
- USB‐C (HDCP Version)
- 2.2
-
- USB‐C (Max. Resolution at Hz)
- 2560 x 2880 @ 60Hz
- USB‐C (DP Alternate Mode)
- Yes
-
- USB‐C (Data Transsmission)
- Yes
- USB‐C (Power Delivery)
- 96W
-
- USB Upstream Port
- Yes (1ea/ver2.0)
- USB Downstream Port
- Yes (2ea/ver3.0)
-
- Headphone Out
- Yes
SOUND
-
- Speaker
- 7W
- Speaker_Output (unit)
- 2ch
SOUND
-
- Speaker_Channel
- Down Firing
SOUND
-
- Maxx Audio
- Yes
MECHANICAL & POWER
-
- Type
- External Power(Adapter)
- AC Input
- 100‐240Vac, 50/60Hz
-
- DC Output
- 19.5V 10.8A
- Power Consumption (Sleep Mode)
- Less than 0.5W
-
- Power Consumption (DC Off)
- Less than 0.3W
- Borderless Design
- 3‐Side Virtually Borderless Design
-
- Color (Front Cabinet)
- Charcoal gray Texture
- Color (Middle Cabinet)
- Charcoal gray Texture
-
- Color (Back Cover)
- Charcoal gray Texture
- Color (Stand Body)
- Black Texture
-
- Color (Stand Base)
- Black Texture
- Display Position Adjustments
- Tilt/Height/Swivel/Pivot/Extend/Retract
-
- Tilt
- ‐25° to 25°
- Swivel
- ‐335º to 335º
-
- Height Range
- 130mm
- Down Height
- 35 mm
-
- Pivot
- Counterclockwise
- Extend/Retract
- 210 mm
-
- Wall Mountable
- 100 x 100 mm
- Base Detachable
- Yes
-
- Assembly Step
- Two‐Step
- OneClick Stand
- Yes
-
- Dimensions with Stand (W x H x D)
- 19.0 x 33.2 x 18.2 in / 481.5 x 843.2 x 461.3 mm
- Dimensions without Stand (W x H x D)
- 19.0 x 18.1 x 1.8 in / 481.5 x 549.5 x 44.9 mm
-
- Shipping Dimensions (W x H x D)
- 29.3 x 21.9 x 9.5 in / 745 x 557 x 241 mm
- Weight with Stand
- 19.8 lbs / 9.0 kg
-
- Weight without Stand
- 9.6 lbs / 4.35 kg
- Shipping Weight
- 28.4 lbs / 12.9 kg
WARRANTY & OTHER
-
- Warranty
- 3 Year Limited
- TUV‐TYPE
- Yes
-
- EPA 8.0
- Yes
- UL (cUL)
- Yes
-
- FCC‐B
- Yes
- ErP
- Yes
-
- ROHS, REACH
- Yes
ACCESSORIES
-
- Adapter
- Yes
- Adapter (Color)
- Black
-
- Power Cord
- Yes
- Power Cord (Color/Length)
- Black / 1.5m
-
- HDMI
- Yes
- HDMI (Color/Length)
- Black / 2m
-
- DisplayPort Cable
- Yes
- Display Port Cable (Color/Length)
- Black / 2.0m
-
- USB‐C
- Yes
- USB‐C (Color/Length)
- Black / 1.8m
-
- Calibration Report (Paper)
- Yes
- Others
- DC Extension cable 1.4m Black w/ Holder, USB2.0 Upstream Cable 1.8m Black, Ergo+ stand, Body cable cover, Body top cover, Wrench
