KEY FEATURES

  • 21.3-inch 3MP IPS Display
  • 1100 cd/m² (Typ.)
  • Easy Calibration Sensor
  • Pathology Mode, Focus View Mode
  • Down & Wall Lighting
  • Ergonomic Design
21.3” 3MP IPS Diagnostic Monitor with Ergonomic Design, Daisy Chain, and Front Sensor Calibration
$
21.3-inch 3MP IPS Display

See Images Clearly for Quality Diagnostic Review

*Image infill for illustration purposes only.

  • Accuracy

    21.3-inch 3MP IPS Display
    Calibration with Front Sensor

  • Efficiency

    Focus View
    5 Hot Keys & Lighting

  • Comfort

    Daisy Chain
    Ergonomic Design

Accurate Imaging

Calibration with Front Sensor

Manage Quality Control

The Integrated Front Sensor allows for calibration without the need for additional measuring equipment. It improves the quality and consistency of medical images that are displayed by maintaining accurate values.
*Image infill for illustration purposes only.

Multi-Resolution Mode

Diagnostic monitors often need to be connected to various modalities, all with differing resolutions. Thanks to the 21HQ513D’s Multi-Resolution Mode, you can adjust the monitor’s resolution to 3MP or 2MP.
*Image infill for illustration purposes only.
Pathology Mode

Incredible Color Reproduction

In Pathology Mode, the 21HQ513D reproduces the same level of detail and color accuracy as seen directly under a microscope to help healthcare professionals make their diagnoses.
*Image infill for illustration purposes only.

Streamlined and Efficient Workflow

Presence Sensor

Energy Efficiency & Strong Security

The Presence Sensor automatically turns off the display when no motion is detected. You can save energy and help with patient privacy.
*Image infill for illustration purposes only.
Focus View

Fully Focus on the Region of Interest

With Focus View Mode, this monitor allows you to review a specific part of the medical image closely. This will enable professionals to focus entirely on the image’s region of interest for diagnosis.
*Image infill for illustration purposes only.
Down Lighting & Wall Lighting

Ideal Diagnostic Workspace

Down and Wall Lighting Modes reduce the contrast between the monitors’ brightness and ambient lighting conditions, allowing you to work comfortably without adjusting the lighting to view paper documents in the darkroom.
21.3” 3MP IPS Diagnostic Monitor Down & Wall Lighting 21.3” 3MP IPS Diagnostic Monitor Down & Wall Lighting
*Image infill for illustration purposes only.

Hot Key Controls

Five Hot Keys make changing between screen modes more straightforward and intuitive than operating through an onscreen menu. The Hot Keys are fast and easy to use while working, allowing you to change mode and lighting settings without disrupting your workflow.
*Image infill for illustration purposes only.

Ergonomic and Comfortable Workspace

Auto Luminance Sensor

The Auto Luminance Sensor automatically adjusts screen brightness according to the ambient lighting conditions. As a result, it helps to reduce eye strain by maintaining an optimal screen brightness.
*Image infill for illustration purposes only.
Daisy Chain

Reducing Clutter on Your Desk and Simplifying Cable Management

With 2 USB 3.0 Upstream Port and DisplayPort support Daisy Chain Setup, you can establish a productive workstation by connecting two diagnostic Monitors and a PC.
*Image infill for illustration purposes only.
Ergonomic Design

Easy and Comfortable Workspace

Designed to be adjustable for posture, healthcare professionals can review images comfortably with the 21HQ513D.
Stop

icon Pivot Two-way

icon Height 0~110mm

icon Tilt -5~20°

*All images add disclaimer: Image infill for illustration purposes only.

PANEL

    • Panel Type
    • IPS
    • Inch (Aspect Ratio)
    • 21.3-inch (3:4)
    • Resolution
    • 3MP (1536 x 2048)
    • Surface Treatment
    • Anti-glare, 3H
    • Color Gamut (Typ.)
    • NTSC 72%
    • Viewing Angles (CR≥10)
    • 178° (Right/Left), 178° (Up/Down)
    • Brightness (Typ.)
    • 1100 cd/m2
    • Contrast Ratio (Typ.)
    • 1800:1
    • Response Time (GtG*)
    • 5ms

FEATURE

    • DICOM Compliant
    • Yes
    • HW Calibration
    • Yes (PerfectLum) with Internal Front Sensor
    • Display Mode
    • Multi-resolution (3/2MP), Focus View Mode, Light Box Mode, Pathology Mode
    • Super Resolution+
    • Yes

VIDEO SIGNALS

    • Input Terminals
    • DisplayPort x2, DVI x1
    • Output Terminals
    • DisplayPort x1 (Daisy Chain, 3MP/ @60Hz)

CONNECTIVITY

    • USB
    • 2 Upstream, 2 Downstream

POWER

    • AC Input
    • 100-240Vac, 50/60Hz

POWER

    • Power Consumption (Max.)
    • 120W

POWER

    • Power Consumption (DC Off)
    • Less than 0.3W

User Convenience

    • Dual Controller
    • Yes
    • Text Mode / Flicker Safe
    • Yes / Yes
    • Lighting
    • Yes (Down/Wall)
    • Hot Key
    • Yes (5 Keys - Down Light / Wall Light / Presence Sensor / Light Box Mode / Picture Mode)
    • Presence Sensor
    • Yes
    • Auto Luminance Sensor
    • Yes

PHYSICAL SPECIFICATIONS

    • Weight (With Stand)
    • 7.0 kg (15.4 lbs)
    • Weight (Without Stand)
    • 5.0 kg (11.0 lbs)
    • Adjustable Stand
    • Tilt: -5°~20°, Pivot: 90°, Height Range: 110 mm (4.3 in.)

WARRANTY/UPC

    • Warranty
    • 5 Year Limited Warranty
    • UPC
    • 195174 017296

Specification Sheet
