LMV1680WW

Over the Range Microwave

KEY FEATURES

  • Turntable Activation with Dual Distribution Technology
  • Melt/Soften Setting
Over the Range Microwave

COOKING FEATURES

    • Convection Bake and Roast
    • No
    • Combination Speed Cook
    • No
    • Power Levels
    • 10
    • Auto and Rapid Defrost
    • Yes
    • Popcorn Key
    • no
    • EZ-On
    • no
    • More/Less
    • Yes
    • Custom Set
    • no
    • Custom Cook
    • no
    • Hold/Warm
    • Yes
    • Add 30 Seconds
    • Yes

CONVENIENCE FEATURES

    • Cooking Rack
    • Bi-Level
    • Turntable Type
    • Round
    • Turntable Diameter
    • 12.7"
    • Turntable On/Off w/Dual Distribution Technology
    • Yes
    • Recessed Turntable
    • no
    • Clock
    • Yes
    • Timer
    • Yes
    • Completion Beeper
    • Yes

LIGHTING

    • Cooktop Lighting
    • Incandescent
    • Hi / Low / Off
    • no
    • Night Light
    • Yes

VENTING SYSTEM

    • Filtration
    • Carbon Coated Charcoal Filter
    • Speed (Step)
    • 2
    • Auto Time Set
    • no
    • Vent Grill Type
    • Hidden Vent
    • Vent Air Flow (CFM)
    • 300

DIMENSIONS

    • Cavity (WxHxD)
    • 21 9/16" x 8 3/4" x 14 1/8"
    • Exterior (WxHxD)
    • 29 15/16" x 16 7/16" x 15 5/8"
    • Weight (Product)
    • 52 lbs.

SUMMARY

    • Capacity
    • 1.1 cu. ft.
    • Wattage
    • 1000
    • Exterior Design
    • Traditional
    • Color
    • White
    • Type
    • Over-the-Range
    • Control Type
    • Keypad
    • Display
    • LED
    • Convection Heat
    • no
    • Sensor Cook
    • Yes
    • Sensor Reheat
    • Yes
    • Melt/Soften
    • Yes
    • Child Lock
    • Yes
    • Warranty
    • 1 Year Parts and Labor, 10 Year Limited on Magnetron
    • Accessories
    • Recirculating Charcoal Filter
    • Other Colors
    • Black, Stainless Steel

What people are saying

Rated 3 out of 5 by from Door handle broke, now front cracked! Not happy with the quality. Door handle broke, replaced it. Now front of microwave below door handle is cracked.
Date published: 2020-05-18
Rated 4 out of 5 by from Very good microwave for the price. I have had this microwave for around 7 or 8 years. It has performed extremely well and we use it alot for reheating and cooking. We have had no door issues as I saw others complain about. Yesterday the light bulb burned out. And that is the only support we have ever needed. I haven't looked yet, but assume replacing it will be simple. My only "con" is that it is very loud, but for the price, it's acceptable.
Date published: 2019-07-24
Rated 3 out of 5 by from door handle issue. Same issue as others, the door handle broke. Have had it for several years, still works, but have to buy new as the door handle no longer opens it.
Date published: 2018-02-28
  • y_2021, m_4, d_12, h_16
  • bvseo_bulk, prod_bvrr, vn_bulk_3.0.14
  • cp_1, bvpage1
  • co_hasreviews, tv_3, tr_58
  • loc_en_US, sid_MD00000604, prod, sort_[SortEntry(order=SUBMISSION_TIME, direction=DESCENDING)]
  • clientName_lg
  • bvseo_sdk, java_sdk, bvseo-4.0.0
  • CLOUD, getReviews, 8ms
  • REVIEWS, PRODUCT

ASK & ANSWER

Ask your questions. Share your answers.
Please review the detailed product information and help guides in the
Product Support section for this product prior to posting a question.

The vent is off and can’t stop it

Asked by: Zs12012
Hello Zs12012. If the temperature gets too hot around the LG Over the Range Microwave, Model # LMV1680WW, the fan in the vent hood will automatically turn on at the LOW setting to cool the oven. It may stay on up to an hour to cool the oven. When this occurs, the fan cannot be turned off manually. It is a safety feature to prevent overheating. If that is not the issue, the microwave oven will require repair service. You can visit us at https://www.lg.com/us/support/find-service-center to see if there are any LG Authorized Service Center in your area that you can make arrangements with to have the microwave repaired or you can contact our Support Center at (800) 243-0000 for assistance...^IFV
Answered by: Ivanf
Date published: 2020-10-02

Why won't my microwave heat up? It's less than 5 years old.

Purchased LMV1680WW in early 2010 and it stopped heating this week.
Asked by: RIFRAF
I have a Gold Star Microwave Oven - Model # MV1610ST _ everything operates on the microwave but it won't heat up. It is 6 years old. How do I know if it is a Magnatron, thermal fuse, High Limit Thermostat, etc.or if in fact it is repairable. I don't want to pay for a repairman to come out and tell me it is not repairable. That would then mean that charge, a new microwave charge and another installation charge.
Answered by: Mury
Date published: 2015-11-02

Need Installation Instructions and Template

Originally included with the LMV1680 microwave were an installation instructions booklet (NOT the Owner's Manual - I have that) and an installation template. Is it possible for me to get replacement copies of those 2 items? I checked the downloadable documentation on the LG website, and only the Owner's Manual and product spec seem to be available. Please let me know where I can get the installation instructions and template (I do not need replacement parts - I have all necessary parts). Thank you for your time.
Asked by: SteffyReed
Hi SteffyReed. Please contact the LG Customer Interactive Center for the installation instructions and template for the LG Over the Range Microwave, Model # LMV1680WW. Their number is (800) 243-0000...^IFV
Answered by: LGJoel
Date published: 2015-08-01

changing from vented to non vented

how do I convert this unit from venting in the back to non vented?
Asked by: jdpyper
We appreciate your interest in this microwave oven. This model leaves the factory configured to vent into the room, rather than to the outside. The unit will have to be removed from its installation. The circulation fan, on the top, back of the cabinet, will have to be removed, turned, and then reinstalled. Return the microwave to its mounted installation. If there are any questions, please contact our Customer Interactive Center at 800-243-0000.
Answered by: NeilE
Date published: 2014-12-19

The turntable in our microwave has cracked. Can we get a replacement? Not sure why this one has cracked since we haven't removed it from the unit.

Asked by: Kdgqueen
Accessories can be obtained through our parts distributor, MCM Electronics. Their contact number, for placing orders, is 800-824-9491. You can also use their website, at http://www.mcmelectronics.com/content/en-US/forms/lg_parts. The part number for this Glass Tray is 3390W1A027A.
Answered by: NeilE
Date published: 2014-07-24

How do you mount the LMV1680WW? I do NOT have the mounting kit or instructions.

I have bought this model used and so I do not have the mounting instructions. I printed out the owners manual but it doesn't include any mounting instructions.
Asked by: Beachy
Accessories can be obtained through our parts distributor, MCM Electronics. Their contact number, for placing orders, is 800-824-9491. You can also use their website, at http://www.mcmelectronics.com/content/en-US/forms/lg_parts. The part number for the Mounting Bracket is 3300W0A030A, while the Installation Kit is 3861W1A043A. Will the vent be blowing through a duct? If so, then the part number for the Vent Adapter is 4810W1A151A, and its Damper is 4900W1A001B.
Answered by: NeilE
Date published: 2020-09-10

what is the power and minutes when you use the popcorn key to cook microwave popcorn

we have an over the reange LMV1680ww and when we hit to popcorn key it shows 3.5. then 2:05 We are doing sience experiments and need the exact power - is it using full power? and is 2:05 the minutes/seconds? Thanks
Asked by: perlite
We appreciate your interest in this microwave oven. The POPCORN setting runs at 100% full power during the preset time frame generated. This is a 1000W microwave for its full operation. Yes, the 2:05 is 2 minutes and 5 seconds.
Answered by: NeilE
Date published: 2013-10-22

missing part on support for turntable

the support bracket that has three white plastic "wheels" that fit onto the nipples protruding out side of this round bracket (that turn- table sits on) is missing!
Asked by: verda
Accessories can be obtained through our parts distributor, MCM Electronics. Their contact number, for placing orders, is 800-824-9491. You can also use their website, at http://www.mcmelectronics.com/content/en-US/forms/lg_parts. The part number for the Rotating Ring Assembly is 5889W2A012F.
Answered by: NeilE
Date published: 2013-10-22
