All Spec
PANEL
-
Screen Size
49"(123cm)
-
Panel Technology
IPS
-
Aspect Ratio
16 : 9
-
Resolution
1,920 x 1,080 (FHD), M+ (WRGB)
-
Brightness
3000cd/m2(Typ.) through front protective glass
-
Viewing Angle (H x V)
178 x 178
-
Response Time
8 ms (G to G BW, Typ.)
-
Surface Treatment
AGLR(Haze 3%), QWP
-
QWP Polarizer
Yes
-
Life time
50,000 Hrs
-
Operation Hours
24Hrs
-
Orientation
Portrait only
CONNECTIVITY
-
Input
HDMI, DP, DVI-D, Audio In, USB 3.0
-
Output
DP, External Speaker out
-
External Control
RS232C In/out, RJ45 In
PHYSICAL SPECIFICATION
-
Front glass
6.8mm (AR, Laminate Safety Vandal Glass)
-
Bezel Colour
Black
-
Bezel Width
103.0 mm (T), 262.0 mm (B), 46.5 mm (L/R)
-
Monitor Dimension (W x H x D)
701 x 1,445 x 179 mm
-
Weight (Head)
58.6 kg
-
Packing Dimensions (W x H x D)
863 x 1,624 x 333 mm
-
Packed Weight
73.4 kg
SPECIAL FEATURES
-
SPECIAL FEATURES
Temperature Sensor, Auto Brightness Sensor, Pixel Sensor, Cooling FAN, ISM Method, DPM Select, Energy Saving, Smart Energy Saving, File Play with USB, Internal Memory 8GB (System 4GB + Available 4GB), USB Cloning, Easy Brightness Control, Wake on LAN, Fail Over, DP Daisy Chain, Control Manager
ENVIRONMENT CONDITIONS
-
Operation Temperature
-30°C to 50°C
-
Operation Humidity
5% to 100%
-
Dust / Water Proofing
IP56
POWER
-
Power Supply
100-240V~, 50/60Hz
-
Power Type
Built-In Power
-
Power Consumption (Typ./Max)
270 W / 400 W
-
Power Consumption (Smart Energy Saving)
145 W
STANDARD(CERTIFICATION)
-
Safety
AS/NZS 60950,CB Scheme
-
EMC
AS/NZS CISPR32,RCM(Class A)
SOFTWARE COMPATIBILITY
-
Content Management Software
SuperSign CMS
-
Control and Monitoring Software
SuperSign Control/Control+
ACCESSORIES
-
Basic
Remote Controller, Manual (EIG, ESG), Regulation Book, Phone to RS232C Gender, USB Cable, HDMI Cable
-
Optional
Enclosure Stand (ST-491X, ST-493X), Circuit Breaker & Surge Suppressor (KT-PS)
White Paper
To access more technical documentation and resources, please visit the LG B2B partner portal.
