- High brightness with IPS for wide viewing angles
- High operating temperature
- Conformal coating
- Optimised design for double-sided display
All Spec
PANEL
Screen Size (Inch)
75
Panel Technology
IPS / M+
Back Light Type
Direct
Aspect Ratio
16:9
Native Resolution
3840 x 2160 (UHD)
Refresh Rate
60Hz
Brightness
3,000nit (Typ.), 2,800nit (Min.)
Contrast Ratio
1,200:1 (Typ.)
Dynamic CR
500,000:1
Color Gamut
NTSC 68%
Viewing Angle (H x V)
178º x 178º
Color Depth (Number of Colors)
1.07 Billion colors
Response Time
8ms (G to G)
Surface Treatment (Haze)
Haze 3%
Life time
50,000Hrs (Typ.)
Operation Hours (Hours/Day)
24/7
Portait / Landscape
YES / YES
Transparency
N/A
QWP (Quarter Wave Plate)
N/A
CONNECTIVITY
HDMI In
YES (2ea)
HDMI In (HDCP Ver.)
2.2
DP In
YES (HDCP 1.3)
DVI-D In
YES
RGB In
NO
Audio In
YES
RS232C In
YES
RJ45(LAN) In
YES (1ea)
IR In
YES
USB In
USB2.0 Type A (1ea)
HDMI Out
NO
DP Out
YES
Audio Out
NO
Touch USB
NO
External Speaker Out
YES
RS232C Out
YES
RJ45(LAN) Out
YES
IR Out
NO
Daisy Chain
NO
MECHANICAL SPECIFICATION
Bezel Color
Black
Bezel Width
Even bezel : 11.8mm
Weight (Head)
37.5Kg
Weight (Head+Stand)
N/A
Packed Weight
47Kg
Monitor Dimensions (W x H x D)
1675.2 x 953.6 x 128.9mm
Monitor Dimension with Stand (W x H x D)
N/A
Carton Dimensions (W x H x D)
1816 x 1106 x 285mm
Handle
YES
VESA Standard Mount Interface
N/A
PROTECTION GLASS
Thickness
N/A
Degree of Protection
N/A
Tempered / Chemical strengthening
N/A
Anti-Reflective
N/A
Infrared - Resistance (IR)
N/A
Shatter-Proof
N/A
FEATURE - HARDWARE
Internal Memory (eMMC)
8GB
Wi-Fi/BT (Built-in)
NO
Temperature Sensor
YES
Auto Brightness Sensor
YES
Pixel Sensor
NO
Proximity Sensor
NO
Current Sensor
YES
BLU Sensor
YES
Humidity Sensor
YES
Acceleration(Gyro) Sensor
NO
Power Indicator
NO
Local Key Operation
NO
FAN (Built-in)
YES
FEATURE - SOFTWARE
OS Ver. (webOS)
webOS 3.0
Local Contents Scheduling
YES
Group Manager
NO
USB Plug & Play
YES
Fail over
YES
Booting Logo Image
YES
No Signal Image
YES
RS232C Sync
YES
Local Network Sync
YES
Backlight Sync
YES
PIP
NO
PBP
NO
Screen Share
NO
Video Tag
YES (2 Video Tag)
Play via URL
NO
Screen Rotation
YES
External Input Rotation
YES
Gapless Playback
YES
Tile Mode Setting
YES
Setting Data Cloning
YES
SNMP
YES
ISM Method
YES
Auto Set ID
YES
Status Mailing
YES
Control Manager
YES
Cisco Certification
NO
Crestron Connected
NO
Smart Energy Saving
YES
PM mode
YES
Wake on LAN
YES
Network Ready
YES
Beacon
NO
HDMI-CEC
YES
SI Server Setting
YES
webRTC
NO
Pro:Idiom
YES
Brightness Compensation
YES
W/B Setting by Grey scale
NO
Scan Inversion
NO
ENVIRONMENT CONDITIONS
Operation Temperature
0 °C to 40 °C (with Solar) 0 °C to 50 °C (without Solar)
Operation Humidity
10 % to 80 %
POWER
Power Supply
AC 100-240V~, 50/60Hz
Power Type
Built-In Power
POWER CONSUMPTION
Typ.
620W (Full White) 353W (IEC 62087)
Max.
700W
BTU (British Thermal Unit)
2116 BTU/Hr(Typ.), 2388 BTU/Hr(Max.)
DPM
0.5W
Power off
0.5W
SOUND
Speaker (Built-in)
NO
CERTIFICATION
Safety
CB / NRTL
EMC
FCC Class "A" / CE / KC / VCCI
ERP / Energy Star
YES / NO
ePEAT(US only)
NO
OPS COMPATIBILITY
OPS Type compatible
NO
OPS Power Built-in
NO
SOFTWARE COMPATIBILITY
SuperSign CMS
YES
SuperSign Control+
YES
SuperSign WB
NO
SuperSign Cloud
NO
Promota
NO
Mobile CMS
NO
Connected Care
YES
LANGUAGE
OSD
English, French, German, Spanish, Italian, Korean, Chinese(Simplified), Chinese(Original), Portugues(Brazil), Swedish, Finnish, Norwegian, Danish, Russian, Japanese, Portugues(Europe), Dutch, Czech, Greek, Türkçe, Arabic, Polski
ACCESSORY
Basic
Remote Controller(Including Battery 2ea), HDMI Cable(1ea), USB Cable(2ea), Manual (IG&EIG), Regulation Book, Phone to RS232C Gender(1ea), LAN extension cable(2ea), SMA Cable(2ea), IR Cable(1ea), JCD 5P PWR Cable(3ea), JCD 8P PWR Cable(1ea), Cord Grip rubber(5ea), Screw (6ea), JCD Corner Bracket(4ea)
Optional
NO
SPECIAL FEATURE
Overlay Touch Compatibility
N/A
Smart Calibration
N/A
Tilt (Face up)
N/A
Tilt (Face down)
N/A
IP Rating
N/A
Conformal Coating (Power Board)
YES
Power Protection
YES
Direct Sunlight
YES
DEDICATED FEATURE - TOUCH
Available Object Size for Touch
N/A
Response Time ('Paint' app on Windows 10 PC)
N/A
Accuracy (Typ.)
N/A
Interface
N/A
Protection Glass Thickness
N/A
Protection Glass Transmission
N/A
Operating System Support
N/A
Multi Touch Point
N/A
