All Spec
INFO
-
Product
-
Standard (UHD)
-
Year
-
Y23
-
Month
-
M05
PANEL
-
Screen Size (Inch)
-
65"
-
Panel Technology
-
IPS
-
Back Light Type
-
Direct
-
Aspect Ratio
-
16:9
-
Native Resolution
-
3840 x 2160 (UHD)
-
Refresh Rate
-
60Hz
-
Brightness (Typ.)
-
500nit (Typ.)
-
Contrast Ratio
-
1,000:1
-
Dynamic CR
-
1,000,000:1
-
Color gamut
-
BT709 95%
-
Viewing Angle(H x V)
-
178 x 178
-
Color Depth
-
10bit(D), 1.07Billion colors
-
Response Time
-
Tr : 8ms / Tf :10ms
-
Surface Treatment(Haze)
-
0.28
-
Life Time
-
50,000Hrs (Min.)
-
Operation Hours (Hours/Day)
-
24/7
-
Portrait / Landscape
-
Yes / Yes
CONNECTIVITY(JACK INTERFACE)
-
HDMI IN
-
Yes(3), 3840x2160@60Hz, HDCP 2.2/1.4
-
DP IN
-
Yes(1), 3840x2160@60Hz, HDCP2.2/1.3
-
RS232C IN
-
Yes(1), 4pin Phone-jack
-
RJ45(LAN) IN
-
Yes(1)
-
IR IN
-
Yes(1)
-
USB IN
-
USB2.0 Type A(1)
-
HDMI Out
-
Yes(1), 3840x2160@30Hz, Input : HDMI1/2/3/DP
-
Audio Out
-
Yes(1)
-
RS232C Out
-
Yes(1), 4pin Phone-jack
-
Daisy Chain
-
Yes(Input HDMI, DP / Output HDMI)
MECHANICAL
-
Bezel Color
-
Black
-
Bezel Width
-
T/R/L/B: 12.4mm(Even)
-
Weight (Head)
-
21.6Kg
-
Packed Weight
-
28.4Kg
-
Monitor Dimensions (W x H x D)
-
1458 x 833 x 57.7mm (Without IR)
-
Carton Dimensions (W x H x D)
-
1600 x 970 x 179mm
-
VESATM Standard Mount Interface
-
300 x 300
HW FEATURE
-
Internal Memory
-
16GB
-
Wi-Fi (Built-in)
-
Yes
-
Temperature Sensor
-
Yes
-
Auto Brightness sensor
-
Yes(외장 IR)
-
Acceleration(Gyro) Sensor
-
Yes
-
Local Key Operation
-
Yes
-
Speaker (Built-in)
-
Yes
SW FEATURE
-
OS ver.
-
webOS6.0
-
Local Contents Scheduling
-
Yes
-
Group Manager
-
Yes
-
USB Plug & Play
-
Yes
-
Fail over
-
Yes
-
Booting Logo Image
-
Yes
-
No Signal Image
-
Yes
-
RS232C Sync
-
Yes
-
Local Network Sync
-
Yes
-
PIP
-
Yes
-
PBP
-
Yes(4)
-
Screen Share
-
Yes
-
Video Tag
-
Yes(4)
-
External Input Rotation
-
Yes
-
Play via URL
-
Yes
-
Screen Rotation
-
Yes
-
Gapless Playback
-
Yes
-
Tile Mode Setting
-
Yes (Max. 15x15)
-
Setting Data Cloning
-
Yes
-
ISM Method
-
Yes
-
SNMP
-
Yes
-
Auto Set ID
-
Yes
-
Status Mailing
-
Yes
-
Control Manager
-
Yes
-
Cisco Certi.
-
Yes
-
Crestron Inside
-
Yes
-
Smart Energy Saving
-
Yes
-
PM mode
-
Yes
-
Wake on LAN
-
Yes
-
Network Ready
-
Yes
-
Beacon
-
Yes
-
HDMI-CEC
-
Yes
-
SI Server Setting
-
Yes
-
Pro:Idiom
-
Yes
-
webRTC
-
Yes
ENVIRONMENT CONDITIONS
-
Operation Temperature
-
0 °C to 40 °C
-
Operation Humidity
-
10% ~ 80%
POWER
-
Power Supply
-
AC 100-240V~, 50/60Hz
-
Power Type
-
Built-In Power
-
Power Consumption (Typ.)
-
145W
-
Power Consumption (Max.)
-
200W
-
Power Consumption (British Thermal Unit)
-
495 BTU/Hr(Typ.), 682 BTU/Hr(Max)
-
Power Consumption (Smart Energy Saving, ~70%)
-
101.5W
-
Power Consumption (DPM)
-
0.5W
-
Power Consumption (Power Off)
-
0.5W
CERTIFICATION
-
Safety
-
CB / NRTL
-
EMC
-
FCC Class "B" / CE / KC
-
ErP / Energy Star
-
Yes (NewErP) / Yes
-
ISTA6
-
Yes(~'23.9월, US Suffix Only)
-
Carbon Trust
-
Yes(~'23.9, CO2 Measured)
SOFTWARE COMPATIBILITY
-
SuperSign CMS
-
Yes
-
SuperSign Control / Control+
-
Yes / Yes
-
SuperSign WB
-
Yes
-
SuperSign Cloud
-
Yes
-
Promota
-
Yes (Not available for EU/CIS)
-
Mobile CMS
-
Yes
-
Connected Care
-
Yes
LANGUAGE
-
OSD
-
English, French, German, Spanish, Italian, Korean , Chinese(Simplified), Chinese(Original), Portugues(Brazil), Swedish, Finnish, Norwegian, Danish, Russian, Japanese, Portugues(Europe), Dutch, Czech, Greek, Türkiye, Arabic
ACCESSORY
-
Basic
-
Remote Controller(include battery 2ea), Power Cord, QSG, Regulation Book, Phone to RS232C Gender
-
Optional
-
Slim Wall Mount (WB21LMA/B), 일반 Wall Mount (OLW480A/B) Wall Mount Adapter (AM-B330S)
SPECIAL FEATURE
-
Tilt (Face Down)
-
Yes(Max 30º degree, 40ºC temperature)
-
IP Rating
-
IP5X
-
Conformal Coating (Power Board)
-
Yes
