N4B2ND4

4 Bay Super Multi NAS with Blu-ray Disc Rewriter

KEY FEATURES

  • Powerful Intel® Atom™ Processor
  • Access all your data anywhere via the internet
  • Built-in Blu-ray Disc Rewriter for additional data backup option & protection
  • Hot Swappable and Lockable Trays
4 Bay Super Multi NAS with Blu-ray Disc Rewriter

SUMMARY

    • Processor
    • Intel® Atom™ D510 (Dual core, 1.6GHz)
    • Memory
    • 1024MB
    • Number of HDD Bays
    • 4 x hot-swappable and lockable tray
    • Interface
    • E-SATA (SATA II)
    • Data Transfer Rates
    • 3Gb/s
    • Recommended HDD Capacity
    • 250GB, 500GB, 750GB, 1.0TB, 1.5TB, 2 TB
    • Supported RAID Levels
    • 0, 1, 5, 1+0, JBOD
    • Operating System
    • Embedded Linux (Kernel 2.6)
    • Client OS Support
    • Win 2000, XP, Vista, Windows Server 2003, Mac OS 10.3 and later; Linux (Redhat 9, Ubuntu, Suse)
    • Warranty
    • 1 Year Limited

HDD

    • Included Storage
    • 4TB (1TB x 4)

LAN INTERFACE

    • Standard Compliance
    • IEEE802.3ab / IEEE802.3u/IEEE802.3 Standard 10/100/1000 Ethernet
    • Data Transfer Rates
    • 10/100/1000Mbps
    • Connector Type
    • RJ-45
    • Number of Ports
    • 1

BLU-RAY RE-WRITER

    • SupportedMedia
    • BD/DVD/CD
    • Writing Speed
    • BD (6xMax.)/ DVD (16xMax.) CD (40xMax.)
    • Reading Speed
    • BD (6xMax.)/ DVD (12xMax.) CD (40xMax.)
    • Interface
    • SATA

USB INTERFACE

    • Standard Compliance
    • USB 2.0
    • Connector Type
    • USB Type A
    • Number of Ports
    • 3 (Front 1 ea., Rear 2 ea.)
    • Data Transfer Rates
    • Max: 480Mbps (High Speed Mode), Max: 12Mbps (Full Speed Mode)

OTHER INTERFACE

    • Memory Card Reader
    • 4 in 1 (SD,MMC,MS, xD)

NETWORK FILE SERVICES

    • Transport Protocol
    • TCP/IP
    • File Sharing Protocol
    • SMB/CIFS, AFP, FTP, DDNS
    • Management
    • HTTP/S
    • Time Syncronization
    • NTP
    • Network Options
    • DHCP IP or Static IP

OTHER

    • Dimensions (WxHxD)
    • 190mm x 295mm x 271mm (7.48" x 11.61" x 10.65")
    • Weight (without HDD)
    • N4B2N (Enclosure) 7.0 Kg / 15.43 lbs.
    • Operating Environment
    • 0-40°C, 15-85% (non condensing)
    • Operating System
    • Embedded Linux (Kernel 2.6)
    • Client OS Support
    • Win 2000, XP, Vista, Windows Server 2003, Mac OS® 10.3 and later Linux (Redhat 9, Ubuntu, Suse)
    • Power Consumption (Typical)
    • IdleMode 38W/ HibernationMode Under 20W
    • Power Supply
    • Internal AC 100-240V, 50/6
    • Regulations & Standards
    • FCC, UL, CE, CE Marking, RoHS
    • Security Design
    • K-Lock security slot for theft prevention

SOFTWARE BUNDLE

    • Comnso backup v2.5, Comnso Sync v2.5, Comnso Restore v2.5, LG NAS Detector v2.1, PowerDVD v.8, PhotoDVD Album v1.0
    • Yes

ASK & ANSWER

Ask your questions. Share your answers.
Please review the detailed product information and help guides in the
Product Support section for this product prior to posting a question.

Hi I own a N4B2ND4 LG Network Storage and I would like to access the web interface but I don't really have neither the username not the password to access the management interface. I tried calling the international number it always hangs up as? Thanks

Asked by: Abdel
Our offices, in the United States, do not have specific product information units released in the United Kingdom. In order to obtain such information, it is recommended to check our subsidiary’s website, at http://www.lg.com/uk/support/contact/support-here-to-help.jsp.
Answered by: NeilE
Date published: 2016-08-29

Does the installed Blu-Ray burner on the LG N4B2ND4 support BDXL (100/128GB) disks?

I imagine that it does, but I would rather not purchase these disks and find out the expensive way.
Asked by: Audie
Please contact LG's Customer Service team at www.LGusa.com/support for assistance.
Answered by: LGJoel
Date published: 2017-01-27

Does the N4B2ND/F include print server functions?

And if so, is its implementation documented in a user/operation manual?
Asked by: dfrench
No, it does not support print server functions.
Answered by: LGJoel
Date published: 2018-11-12

Can I use the BD rewriter to burn video disks?

I'd like to use the BD rewriter to burn Bluray video disks. Can I use software like Roxio Creator to burn video disks?
Asked by: Rude Dog
Yes, you can burn bluray video discs.
Answered by: LGJoel
Date published: 2013-10-22

Is this unit DLNA ccertified?

Asked by: Jim
Firmware Version 2682 added a DLNA media server.
Answered by: LGJoel
Date published: 2013-10-22

Any news on the updated firmware?

Firmware that was supposed to add OSX Lion support is still not available. Can you give us new information on when to expect this? It has been released for the N2 versions but not for the N4 yet.... it's been almost a year since OSX Lion was released and at the moment my NAS is more or less just an expensive brick.
Asked by: MikkelF
We regret the delays you have experienced with getting this update. The last ETA date we have listed for this particular model was November 18th. Some updates have been released, so this is being worked. Unfortunately, at this time, we do not have an ETA data available for you.
Answered by: NeilE
Date published: 2013-10-22

Updated firmware with OSX Lion Timemachine support?

We are stil waiting for an update to the current firmware which will allow access to Timemachine under OSX Lion. Do you have new info on the expected timeframe for this? A lot of other manufacturers have already delivered firmware updates.
Asked by: mikkelf
We regret the delays you have experienced with the new updates for this device. According to my latest information, the Mac OS X Lion with Time Machine support, for the N4B2, is currently scheduled for release on November 18th. This release date is subject to change at any time, but this is our most recent data.
Answered by: NeilE
Date published: 2013-10-22

Will I be able to use the blu-ray burner to play media or be shared over the network?

Asked by: erik
Yes, you can use the blu-ray burner to play media. Yes, you can share it over the network.
Answered by: LGJoel
Date published: 2013-10-22
