DLEX5680V

7.3 cu.ft. Ultra Large High Efficiency SteamDryer™ w/ SteamSanitary™

KEY FEATURES

  • Ultra Large 7.3 cu. ft. Capacity
  • Steam Technology
  • SteamFresh™ Cycle
  • SteamSanitary™ Cycle
7.3 cu.ft. Ultra Large High Efficiency SteamDryer™ w/ SteamSanitary™

CAPACITY

    • Capacity
    • 7.3 cu. ft.

APPEARANCE

    • Design Look
    • Rear Control
    • Intelligent Electronic Controls with Dual LED Display
    • Yes
    • Touch Buttons
    • Yes
    • Dial-A-Cycle™
    • Yes

DRYING PROGRAMS

    • No. of Programs
    • 14
    • Programs (Sensor Dry)
    • Cotton/Normal, Perm. Press/Casual, Heavy Duty, Bulky Bedding, Delicates, A nti-Bacterial, Towels, Small Load, Sports Wear, SteamFresh™, SteamSanitary™
    • Programs (Manual Dry)
    • Speed Dry, Freshen Up, Air Dry
    • No. of Options
    • 10
    • Options
    • More Time, Less Time, Wrinkle Care, Custom Program, Child Lock, ReduceStatic™, E asyIron™, Damp Dry Signal, End of Cycle Signal, Rack Dry
    • Temperature Settings
    • High, Medium High, Medium, Low, Ultra Low
    • Drying Levels
    • Very Dry, More Dry, Normal Dry, Less Dry, Damp Dry
    • Manual Dry Times
    • 60 min., 50 min., 40 min., 30 min., 20 min., More Time/Less Time

FABRIC CARE FEATURES

    • SteamFresh™ Cycle
    • Yes
    • SteamSanitary™ Cycle
    • Yes
    • ReduceStatic™ Option
    • Yes
    • EasyIron™ Option
    • Yes
    • Sensor Dry
    • Yes
    • Precise Temperature Control with Variable Heater
    • Yes

CONVENIENCE FEATURES

    • LoDecibel™ Quiet Operation
    • Yes
    • SmartDiagnosis™
    • Yes
    • FlowSense™ Duct Clogging Indicator
    • Yes
    • Anti-Bacterial Cycle
    • Yes
    • Wrinkle Care Option
    • Yes
    • Remaining Time Display/Status Indicator(s)
    • Yes
    • End of Cycle Signal
    • Yes
    • Child Lock
    • Yes
    • Drum Light
    • Yes
    • Reversible Door
    • Yes
    • Leveling Legs
    • 4 Adjustable Legs
    • Venting Option
    • Electric: 4 Way Venting / Gas: 3 Way Venting
    • 3 Minute Installation Check
    • Yes
    • Drying Rack
    • Yes

MATERIALS AND FINISHES

    • NeveRust™ Stainless Steel Drum
    • Yes
    • Cabinet
    • Painted Steel
    • Control Panel
    • Plastic
    • Top Cover
    • Painted Steel
    • Diamond Glass Door
    • Transparent (White), Dark Gray Tint (Graphite Steel)
    • Available Colors
    • White (W), Graphite Steel (V)

POWER SOURCE

    • Ratings
    • CSA Listed
    • Electrical Requirements
    • 120V, 15 Amps (Gas) / 240V, 30 Amps (Electric)
    • Type
    • Gas/Electric

OPTIONS

    • LP Conversion Kit
    • 4948EL4002B
    • Side Venting Kit
    • 383EEL9001B

DIMENSIONS

    • Product (WxHxD)
    • 27" x 45 3/8" x 28 3/8" (50 1/4" H with door open)
    • Carton (WxHxD)
    • 29 1/2" x 48" x 31 1/4"
    • Weight (Product/Carton)
    • 134 lbs/155 lbs

Warranty/UPC

    • Limited Warranty
    • 1 Year Parts and Labor
    • UPC
    • 048231013512

What people are saying

Rated 1 out of 5 by from worst ever Another laundry day more reason to hate this equipment. The day we bought this stuff, dryer DLEX 5680V and washer WT 5680HUA. The worst day of our lives, what pieces of junk!!!!
Date published: 2016-12-12
Rated 5 out of 5 by from Great features Have had this for about a year and I love it. Would recommend!!
Date published: 2016-08-16
Rated 5 out of 5 by from Great Features Love the steam feature & the other features of it.
Date published: 2016-01-26
  • y_2021, m_4, d_13, h_20
  • bvseo_bulk, prod_bvrr, vn_bulk_3.0.14
  • cp_1, bvpage1
  • co_hasreviews, tv_1, tr_37
  • loc_en_US, sid_MD05083311, prod, sort_[SortEntry(order=SUBMISSION_TIME, direction=DESCENDING)]
  • clientName_lg
  • bvseo_sdk, java_sdk, bvseo-4.0.0
  • CLOUD, getReviews, 36ms
  • REVIEWS, PRODUCT

ASK & ANSWER

Ask your questions. Share your answers.
Please review the detailed product information and help guides in the
Product Support section for this product prior to posting a question.

We have 2014 lg dryer. Model is DLEX5680V. Handy man kneeled on the top of it and dented it. How much would cost to fix it?

Asked by: VDWA
We regret the trouble you have experienced with this electric dryer. Parts and accessories can be obtained through our parts distributor, MCM Electronics. Their contact number, for placing orders, is 800-824-9491. You can also use their website, at http://www.mcmelectronics.com/content/en-US/forms/lg_parts. The part number for this item is: Top Plate Assembly - AGU72925509.
Answered by: NeilE
Date published: 2016-09-08

Beeping noise heard during antibacterial drying cycle.....what causes this?

Asked by: Ronni70
We regret the trouble you have experienced with this dryer. There does not appear to be a beep associated with this Anti-Bacterial cycle. If this alert continues, please contact our Customer Interactive Center at 800-243-0000 for assistance.
Answered by: NeilE
Date published: 2016-02-03

I'm here with a repairman who can't open the top up to service.  Any suggestion?

Asked by: Dave t
You need to check that this repairman working on your LG 7.3 cu.ft. Ultra Large High Efficiency SteamDryer™ w/ SteamSanitary™, Model # DLEX5680V is an LG Authorized repairman, he should access to the service manual for the dryer or should be trained in how to repair LG dryers. If he is not an LG Authorized Service Technician then regrettably, he will not be able to get a service manual and there is not much else that we can suggest...^IFV
Answered by: LGJoel
Date published: 2018-01-21

i need specs of backside for venting install. DLEX5680V

Asked by: RickyBoy
Although the LG 7.3 cu.ft. Ultra Large High Efficiency SteamDryer™ w/ SteamSanitary™, Model # DLEX5680V has been tested for a spacing of 1 inch in the sides and rear of the unit, the recommended spacing is 5 inches in the rear and 1 inch on the sides. The unit itself has a total height in the back of 45 7⁄16" (115.3 cm). It has a depth of 28 15⁄16" (73.4 cm) and the door is 21 1⁄4" (54 cm) so that when it is opened 90 degrees, the total depth is 50 1⁄4" (127.5 cm)...IFV
Answered by: LGJoel
Date published: 2015-08-05

How to adjust the door on the dryer

When emptying the dryer the door keeps drifting closed, This is inconvenient holding the door open. How can it be adjusted to stay open all the way until closed
Asked by: outlaw
We regret the inconvenience you have experienced with this dryer and its door. If the door is sealing properly and operating normally, there would be no adjustments available for the door to change the manner in which it operates. Be certain that the dryer is level front-to-back to ensure that gravity is not pulling the door shut.
Answered by: NeilE
Date published: 2015-06-25

Does the drum spin when using the drying rack?

I'd prefer if the drum didn't spin when using the drying rack it's useless energy usage. Would using the "rack dry" feature prevent the drum from spinning?
Asked by: Rangel
Hi Rangel. When using the "Rack Dry" option on the LG 7.3 cu.ft. Ultra Large High Efficiency SteamDryer™ w/ SteamSanitary™, Model # DLEX5680W, the drum does spin...^IFV
Answered by: LGJoel
Date published: 2015-06-14

Is the door drop-down or side opening?

I cannot find anywhere on your site or the web which says or shows if the DLEX5680V''s door is drop-down or side opening.
Asked by: nfordlgdryr
Side opening and you can reverse the direction in which it opens if you choose (left to right/right to left), but you have to follow the instructions in the manual.
Answered by: Iscus
Date published: 2015-07-25

Does the DLEX5680V Dryer ship with the duct hose?

Asked by: John1999999
No.
Answered by: Iscus
Date published: 2015-07-25
