• 7.3 cu. ft. Ultra Large Capacity with NeveRust™ Stainless Steel Drum
  • EcoHybrid™ Technology
  • TrueSteam® Technology
  • SteamFresh™ Cycle
  • ENERGY STAR® Qualified
7.3 cu. ft. Ultra Large Capacity Dryer with EcoHybrid™ Technology


    • Dryer Type
    • Electric
    • SteamDryer™
    • Yes
    • Stackable
    • Yes
    • Heat Pump
    • Yes


    • Capacity
    • 7.3 cu. ft.


    • Design Look
    • Front Control
    • Intelligent Electronic Controls with Dual LED Display
    • Yes
    • Dial-A-Cycle™
    • Yes


    • ENERGY STAR® Qualified
    • Yes


    • No. of Programs
    • 14
    • Programs (Sensor Dry)
    • Cotton/Normal, Perm. Press, Heavy Duty, Bulky/Large, LowTemp Dry+, Delicates, Power Dry, Towels, Sports Wear, SteamFresh™, SteamSanitary™
    • Programs (Manual Dry)
    • Speed Dry, Air Dry, Download Cycle
    • Options
    • EcoHybrid™, Wrinkle Care, Custom Program, Child Lock, More Time, Less Time, ReduceStatic™, EasyIron™, Damp Dry Signal, Rack Dry, Program Save, Drum Light
    • Temperature Settings
    • High, Medium High, Medium, Low, Ultra Low
    • Drying Levels
    • Very Dry, More Dry, Normal Dry, Less Dry, Damp Dry
    • Manual Dry Times
    • 60 min., 50 min., 40 min., 30 min., 20 min.
    • Signal Volume Level
    • High, Medium, Low, Off


    • SteamFresh™ Cycle
    • Yes
    • TrueSteam® Technology
    • Yes
    • SteamSanitary™ Cycle
    • Yes
    • ReduceStatic™ Option
    • Yes
    • EasyIron™ Option
    • Yes
    • Sensor Dry
    • Yes
    • Precise Temperature Control with Variable Heater
    • Yes


    • NFC Tag On
    • Yes
    • LoDecibel™ Quiet Operation
    • Yes
    • SmartDiagnosis™
    • Yes
    • FlowSense™ Duct Clogging Indicator
    • Yes
    • Wrinkle Care Option
    • Yes
    • Remaining Time Display/Status Indicator(s)
    • Yes
    • End of Cycle Signal
    • Yes
    • Child Lock
    • Yes
    • Drum Light
    • Yes
    • Reversible Door
    • Yes
    • Leveling Legs
    • 4 Adjustable Legs
    • Venting Option
    • 1 Way Venting
    • 3 Minute Installation Check
    • Yes
    • Drying Rack
    • Yes


    • NeveRust™ Stainless Steel Drum
    • Yes
    • Cabinet
    • Painted Steel
    • Control Panel
    • Plastic
    • Transparent Glass Door
    • Yes
    • Door Rim
    • Large Square Chrome Rimmed Glass Door with Dark Blue Tinted Cover
    • Available Colors
    • Smooth White (W), Graphite Steel (V)


    • Ratings
    • CSA Listed
    • Electrical Requirements
    • 240V, 26 Amps (Electric)
    • Type
    • Electric


    • Pedestal
    • WDP4W, WDP4V
    • Pedestal (WxHxD)
    • 27" x 13 3/5" x 28 2/5"
    • Stacking Kit
    • KSTK1


    • Product (WxHxD)
    • 27" x 30" x 39" (51" D with door open)
    • Carton (WxHxD)
    • 29 1/2" x 31" x 43"
    • Weight (Product/Carton)
    • 167.5 lbs/171.3 lbs


    • Limited Warranty
    • 1 Year Parts and Labor
    • UPC
    • 048231013758

What people are saying

  • bvseo_sdk, java_sdk, bvseo-4.0.0
  • CLOUD, getReviews, 10ms
  • bvseo-msg: The resource to the URL or file is currently unavailable.;

Choose a support option below:


Ask your questions. Share your answers.
Please review the detailed product information and help guides in the
Product Support section for this product prior to posting a question.

Model: DLHX4072V Is it ventless? Can I plug in 110V?

Asked by: ASDFG
The ENERGY STAR® Qualified LG 7.3 cu. ft. Ultra Large Capacity Dryer with EcoHybrid™ Technology, Model # DLHX4072V is not ventless and has to be vented. It has its own terminal block that must be connected to a separate 240 VAC, 60 Hertz, single-phase circuit, fused at 30 amperes. The circuit must be fused on both sides of the line...^IFV
Answered by: LGJoel
Date published: 2017-09-12

We own a Sensor Dry DLE2301R dryer for 6 yrs now. Six weeks ago it would not work and the repair person installed a new computer panel   Now it won't turn on again and the repair person came over and stated that the panel has no warranty?  Contact LG

Asked by: Wilma maldonado
We regret the trouble you have experienced with this dryer. Parts purchased from LG’s parts department, and installed by an Authorized LG Service Technician, carry a 90-day part warranty for any failures caused by the manufacturing of the part itself. However, if the tech obtained the part from a 3rd party distributor, LG will have no control over the available warranty.
Answered by: NeilE
Date published: 2019-08-06

Is the Height and Depth of this product switched? Are the washer and dryer 30 inches Tall/High ? ?

I have a spot for a new washer dryer that is 60 wide (left to right) 40 deep (front to back) and 38 1/2 tall (bottom to top). I really like the LG but I didn't think it fit when I measured it in the store. However this model fits based on measurements you give. But I think you have the height and depth confused. What are the correct measurements? These are the dimensions on your web page: Product: 27" x 30" x 39" (51" D with door open) Carton: 29 1/2" x 31" x 43" Weight: 167.5 lbs/171.3 lbs
Asked by: PamelaR
Luckily I read the answer from Burk and checked the installation instructions. I did have to cancel the pedestal and side kick order because they would be too tall to fit my space using the correct 39" height. Glad I didn't have to wait until delivery to find that out. Even the owner's manual has the height and depth switched but the installation instructions show the height needed to stack them or place in a cabinet which confirmed that they had the dimensions switched. I think LG Joel must have just read the manual rather than get out a tape measure. Since this is new and quite expensive they aren't going to sell many if they don't figure out why their posted washer and dryer dimensions would never match up or fit the pedestal or side kick.
Answered by: Kuala 1313
Date published: 2017-09-22

Is there a reset sequence. We moved the washer and dryer to the new addition and now there is no heat.

Asked by: housekeeper
We regret the trouble you have experienced with this dryer. It is recommended to check the circuit breaker associated with this outlet, and ensure that the power cord is secure on the dryer. It may also be considered to check the wiring of this new addition, or to check the dryer in its original location. If this does not resolve the matter, then it may require service. To make service arrangements, you may either contact our Customer Interactive Center at 800-243-0000, or you can check our Repair Provider Lookup on our website, at
Answered by: NeilE
Date published: 2017-01-30

Are the doors switchable on either the washer or dryer so you can open from left to right or right to left?

Asked by: mileskr
The door on the LG 7.3 cu. ft. Ultra Large Capacity Dryer with EcoHybrid™ Technology, Model # DLHX4072V is reversible. This unit can stacked on most 27" washers but not all of them have reversible doors. Since there isn't a specific washer that is designated as the match to this dryer, if there is a washer that interests you that you would like to find out if it has a reversible door, we would be more than happy to provide you with that information...^IFV
Answered by: LGJoel
Date published: 2016-01-13

How much does this dryer cost to operate compared with a similar sized gas dryer?

Asked by: CGinCO
Hi CGinCO. The Estimated Annual Energy Use expressed in kilowatts which is based on the Combined Energy Factor and an annual usage of 283 cycles per year as referenced by the US Department of Energy test procedure, is listed as 556 kWh/yr. The Estimated Yearly Costs for this unit will depend on your utility rates, so if you check your utility bill for the rates, you will be able to calculate what your yearly costs would be for this unit. The rates will differ for other similarly sized Gas dryers depending on the unit, so if you have a specific unit you would like to compare this unit to, we could give you an appropriate response...^IFV
Answered by: LGJoel
Date published: 2017-01-27

Energy Star 'Energy Guide' Label

Hi LG - Wondering why there's no Energy Star Energy Guide label for this dryer. Is there a plan to provide this, or an estimated energy use for the heat pump dryer? I have seen reference to 'up to 44%' less energy, but without the Energy guide's easy to read - and easy to interpret reference - it feels a bit disingenuous. I've uploaded an EnergyGuide label from the "Model WM8000H*A" washing machine as a reference to what I'm discussing.
Asked by: Melman
Melman, we appreciate your interest in the LG 7.3 cu. ft. Ultra Large Capacity Dryer with EcoHybrid™ Technology, Model # DLHX4272V. This dryer isn’t just ENERGY STAR® certified—it actually earned the 2014 ENERGY STAR Emerging Technology Award! You can visit the Energy Star site to verify that it is indeed Energy Star certified. It was qualified on 07/28/2014, and is listed on Energy Star's site as having an Estimated Annual Energy Use (kWh/yr) of 556 and has a Combined Energy Factor (CEF) of 4.3 lbs/kWh...^IFV
Answered by: LGJoel
Date published: 2017-03-04


Asked by: WILBBUR
We appreciate your interest in our products. Energy Star information can be found at
Answered by: NeilE
Date published: 2020-05-25
