55" class - Immersive Screen with Smart Platform Ultra HD UH5C Series

55UH5C-B

()

LG 55" class - Immersive Screen with Smart Platform Ultra HD UH5C Series, 55UH5C-B

Key Features

Quad Core SoC*
WebOS 3.0
Group Manager
PBP (Picture-By-Picture) / PIP (Picture-In-Picture)

Ultra HD Resolution (3,840 x 2,160)

Ultra HD Large screen delivers immersive viewing experience by 4 times higher definition picture quality than FHD.

High Efficiency Video Coding

Supports HEVC-based content which has the double data compression ratio than the H.264, so network traffic can be reduced by half.

Mirroring

Content sharing is more convenient on a Wi-Fi network.

Low Power Consumption Using The M Panel

The M panel offers excellent energy efficiency and cost savings and decreases power consumption by approx. 31 compared to conventional RGB panels*.

IP Streaming Protocol

Various types of IP video streaming protocol are supported, such as RTSP/RTP, MMS, HLS and MPEG-2 TS*.

* RTSP (Real-Time Streaming Protocol), RTP (Real-time Transport Protocol), MMS (Microsoft Media Server), HLS (http live streaming)

Secure Communication Protocol

By supporting HTTPS* protocol, communication between server and signage is more secure.

* HTTPS : Hypertext Transfer Protocol over Secure Socket Layer

Proxy Server

Web access speed and security can be improved by supporting Proxy Server (A server that acts as an intermediary for requests from clients seeking resources from other servers.)

Quad Core SoC*

The high-performance SoC can execute several tasks at the same time and provides smooth content playback.

*SoC : System-on-Chip

WebOS 3.0

The webOS 3.0 platform provides powerful and convenient creation tools, including app development materials.

Group Manager

Content can be created, distributed and controlled by a signage without a dedicated PC or server.

Soft AP

The UH5C with Soft AP software can operate as a wireless access point for mobile devices.

PBP(Picture-By-Picture) / PIP(Picture-In-Picture)

PBP (Picture-By-Picture) and PIP (Picture-In-Picture) features enable you to compose various layouts for several digital devices.

Quad Core SoC*
WebOS 3.0
Group Manager
PBP (Picture-By-Picture) / PIP (Picture-In-Picture)

All Spec

PANEL

Screen Size

55"
Panel Technology

IPS
Aspect Ratio

16 : 9
Native Resolution

3,840 x 2,160 (UHD)
Brightness

500cd/m²
Contrast Ratio

1,100:1
Dynamic CR

1,000,000 : 1
Viewing Angle (HxV)

178 x 178
Response Time

8ms (G to G)
Surface Treatment

Low Haze 1%
Life time (Typ.)

50,000 Hrs (Typ.)
Operation Hours

24 hours
Orientation

Portrait & Landscape

CONNECTIVITY

Input

HDMI, DP, DVI-D, Audio, USB 3.0, SD Card
Output

DP, External Speaker out
External Control

RS232C, RJ45, IR Receiver, Pixel Sensor

PHYSICAL SPECIFICATION

Bezel Color

Black
Bezel Width

12.1 mm (T), 12.6 mm (R/L), 15.7 mm (B)
Monitor Dimension (W x H x D)

1,239.8 x 725.2 x 38.6 mm
Weight (Head)

16.6 kg
Carton Dimensions (W x H x D)

1,330 x 807 x 170 mm
Packed Weight

21.1 kg
VESA TM Standard Mount Interface

300 x 300 mm

SPECIAL FEATURES

Yes

Temperature Sensor, Auto Brightness Sensor, Tile Mode (up to 15x15), Natural Mode@Tile Mode, ISM Method, Internal Memory (8GB, System 4GB), Wi-Fi built-in (802.11n), USB Cloning, Content Scheduling, Sync mode, PM mode, Fail Over, Wake on LAN, BEACON (On/Off), Embedded Template, PIP/PBP

ENVIRONMENT CONDITIONS

Operation Temperature Range

0°C to 40°C
Operation Humidity Range

10 % to 80 %

POWER

Power Supply

100–240V~, 50/60Hz
Power Type

Built-In Power
Power Consumption-Typ

116 W
Power Consumption Smart Energy Saving

80 W

STANDARD(CERTIFICATION)

Safety

UL / cUL / CB / TUV / KC
EMC

FCC Class "A" / CE / KCC
ErP / Energy Star

Yes (EU Only) / Yes (Energy Star 8.0)

MEDIA PLAYER COMPATIBILITY

OPS type compatible

Yes
External Media Player Attachable

Yes (MP500/MP700)

SOFTWARE COMPATIILITY

SuperSign W/Lite

Yes
SuperSign C

Yes

ACCESSORIES

Basic

Remote Controller (2ea batteries included), Power cord, QSG, HDMI cable, Regulation book, Phone to RS232C gender, Memory cover
Optional

Speaker (SP-5200), Stand (ST-201T), Pixel sensor (KT-SP0), Media player, Wall bracket (LSW350B), VESA Adapter (AM-B330S), OPS Kit (KT-OPSA), HDBaseT (EB-B100)
