Name: 65" class (64.5" measured diagonally) LCD Widescreen Full HD Capable Monitor
Brand: LG

65" class (64.5" measured diagonally) LCD Widescreen Full HD Capable Monitor

Find a Dealer

65" class (64.5" measured diagonally) LCD Widescreen Full HD Capable Monitor

65VS10-BAA

PD Panel

Create a visual spectacle on an impressive scale with the 65VS10-BAA large format LCD monitor. The 65VS10-BAA is manufactured at the highest quality level and is designed for 24/7 continuous operation. Digital signage such as advertisements, menu boards, financial information, or flight information is rendered with the striking brilliance of full HD 1080p resolution. With landscape, portrait and tile mode matrixing capabilities, the 65VS10-BAA adapts to your signage needs.

All Spec

PANEL

Panel Technology

IPS
Display Area

64.5” measured diagonally
Pixels (H x V x 3)

6220800
Aspect Ratio

16:9
Surface Treatment

Hard Coating (3H), Anti-glare
Tni

75°C
Native Resolution

1920 x 1080 (FHD)
Brightness

700 cd/m2
Color Depth

1.07 Billion (8-bit)
Color Gamut

0.72
Contrast Ratio

5,000:1 (Typ.), 10,000:1(DCR)
LCD Panel Type

65” class
Viewing Angle

178°/178°
Lifetime

50,000 Hr., Portrait & Landscape
Response Time

8ms (G to G)

VIDEO

Pixel Frequency

148.5 MHz (RGB, HDMI/DVI/DP)
Sync Compatability

Separate/Composite/Digital
V-Scanning Frequency

56~75Hz (RGB), 60Hz (HDMI/DVI)
Video Input

RGB, HDMI/DVI
Color temperature

Warm/Medium/Cool
H-Scanning Frequency

30 ~83 kHz (RGB, HDMI/DVI/DP)
Max Input Resolution

1920 X 1080 @ 60Hz @ 60Hz (RGB, HDMI/DVI/DP)
Picture mode

Vivid/Standard/Cinema/Sports/Game/Expert 1/ Expert 2
Recommended Resolution

1920 X 1080 @ 60Hz @ 60Hz (RGB, HDMI/DVI/DP)

INPUT(REAR)

Digital

HDMI/DVI with HDCP
Analog

Component(BNC), Composite(BNC), RGB
Audio

RGB/DVI Audio, Component Audio(RCA), Composite Audio(RCA)
External Control

RS232C, RJ45
HDTV Formats

Component: 720p/1080i/1080p HDMI: 720P / 1080i / 1080p
USB

Yes (x1)

OUTPUT(REAR)

Analog

RGB, Composite(BNC)
Audio

Composite Audio(RCA), External speaker
External Control

RS232C

CABINET

Bezel Width

49.0mm
Monitor Dimensions (W x H x D)(head only)

60.5" x 35.7" x 5.4"
Monitor Weight (head only)

114.6 lbs
Carton Dimensions (W x H x D)(head only)

66.5” x 40.6” x 13.0”
Packed Weight

114.6 Ibs
Color

Black
VESA TM Standard Mount Interface

600mm x 400mm

ENVIRONMENT CONDITIONS

Operation Tempature

0°C ~40°C
Operation Humidity

10% ~80%

POWER

Power Supply

100 -240V~, 50/60Hz
Power Consumption DPMS Off

1.0W(RGB)/1.0W(HDMI/DVI)
Power Consumption Power Off

0.5W
Power Type

Built-in Power
Power Consumption Max/Normal

480W(Max), 420W(Typ)

STANDARD(CERTIFICATIONS)

Erp/ENERGY STAR 5.1

Yes /Yes
EMC

FCC Class "B" / VCCI / C-tick / CE / KCC
Safety

UL / cUL / CB scheme / TUV

MEDIA PLAYER COMPATIBILITY

External Media player Attatchable

Yes

SOFTWARE COMPATIBILITY

Supersign Compatibility

Elite-s

LIMITED WARRANTY

WARRANTY

3 Years (Parts/Labor)

UPC CODE

UPC

7 19192 18898 3

ACCESSORIES

Accessory

Remocon, Power cable, RGB Cable, Manual (CD+Book)

OPTIONAL ACCESSORIES

Hidden Speakers (SP0000K)

Black
Speaker Dimensions (W x H x D)

1.6" x 12.9" x 2.2"
Speaker Weight (each)

0.8 Ibs
Packaging Dimensions (W x H x D)

15.1" x 5.3" x 6.9"
Packed Weight

2.4 Ibs (2 Speakers/1 Package)

EZ-NET MANAGERCOMPATIBILITY

ez-Net MANAGERCOMPATIBILITY

Single/Group WAN control, Scheduling, Instant Messaging, Self Diagnosis(Temp, FAN, Lamp, Power Detect), Alarm Service through mailing, Easy Tile mode setup, S/W upgrade via Network, USB Playback

SPECIAL FEATURES

ISM Method

Normal/White wash/Orbiter/Inversion
Advanced

Color Temp, Dynamic Contrast, Dynamic Color, Noise Reduction, Gamma, Black Level, Film Mode
Key Lock

Yes
Temp Sensor

Yes
Information Display

Serial Number, MNT S/W Version, LAN S/W Version, IP Address, MAC Address
Language(OSD/USB Playback)

English/French/Spanish/Italian/German/ Portuguese/Korean/Japanese/Chinese/Russian
Language(CD Manual)

English/French/Spanish/Italian/German/ Portuguese/Korean/Japanese/Chinese/Russian/ Hungarian/Greek/Dutch/Kazakh/Ukrainian/ Polish/Arabic/Indonesian/Turkish/Czech/Slovak
Power Indicator On/Off

Yes
Time

Clock/On/off Timer/Sleep Timer/Auto off, Power on Delay
DPM Select

Yes
Position/Size

Yes
Source Selection

HDMI/DVI, RGB, Component, AV
Split Zoom (Self Video Wall, 5 x 5 Max)

Yes, supports natural mode
Auto Config/Phrase

Yes
Auto Power/Source Memory

Yes
Brightness/Contrast/Backlight

Yes
Cooling FAN

Yes
Energy Saving

Yes, Level1/Level2/Level3
File Play with USB

Yes
Input Label

Yes
