Name: Window Facing Display
Brand: LG

Window Facing Display

Find a Dealer

Window Facing Display

75XS4P-B

Key Features

UL Verified Display Anti-discoloration Characteristics
Resolution : 3,840 × 2,160 (UHD)
Brightness : 4,000 nit (Typ.), 3,200 nit (Min.)
Portrait / Landscape
Space Efficiency

UL Solutions

Display Anti-Discoloration Characterstics verified

Attract Passing Customers with a Bright Display Presented Through a Window

A large LED display is installed on the window inside the convenience store, vividly and brightly showcasing advertisements through the glass.

*All images are for illustrative purposes only.

*Please follow the installation guide to get warranty.

*UV-Film is recommended depending on installation site.

World’s First UL Verification for Display Anti-Discoloration Characteristics

By focusing on the pain points of our customers, we obtained the world’s first UL Verification for Display Anti-Discoloration Characteristics. Our new technology helps prevent ‘screen-yellowing’, while safeguarding display quality and performance stability.

The left side of the screen has yellowing, degrading its quality, but with XS4P, which acquired the UL Verification for Display Anti-Discoloration Features, the screen is clear, safeguarding display quality.

*For more details about UL Verification, please visit https://verify.ul.com/verifications/1382.

*World's first UL Verification in the manufacturing industry.

Window-facing Display

LG offers advanced technical solutions for cost-effective operations. The XS4P can maintain an astonishing brightness of 4,000 nits, yet has lower power consumption compared to RGB panels at the same brightness level.

Three different sizes of XS4P are installed on the window inside the cafe. The content plays clearly and vividly through the glass, even in the bright atmosphere.

Brightness Beyond the Window

A window-facing display requires higher nits, as it is exposed to direct sunlight through a window. The XS4P is designed especially for window-facing environments, providing brilliant brightness. Vibrant and dynamic content displayed through the window will attract customers to your business, despite the viewers wearing polarized sunglasses.

Three different sizes of XS4P are installed on the window inside the phone store. The content plays vividly through the glass, allowing passersby to see it clearly, even in the bright atmosphere.

Optimized Design for Space Utilization

With its compact size and slim design, the XS4P integrates smoothly into any store's interior. Its bezel is thinner than conventional models, enabling closer installation to windows and offering an improved visual experience for customers. Additionally, standard UHD signage can be attached to the back of the XS4P, allowing it to function as a double-sided display.

A sleek bezel XS4P is installed on the window inside the cafe, and the backside of the XS4P, with another LED display, is displaying content, effectively utilizing both sides.

*The conventional model refers to the XS2E.

*The bracket accessory is sold separately.

*Exclusively available for 75XS4P.

High-performance with webOS 6.0

Quad Core SoC (System-on-Chip) can execute several tasks at the same time without a separate media player. In addition, webOS 6.0 platform enhances not only user convenience with intuitive UI but also web-app integration with updated Node JS / Chromium version.

It has improved user convenience by utilizing the SoC and webOS.

Remotely Managed, Real-time Mastery
(Content Manager)

A significant advantage of window-facing displays over temporary displays is their ability to effortlessly manage frequently changing promotional content and pricing information. LG’s web-based content solution is intuitive and user-friendly, providing users with complete access to current and historical data anytime, anywhere, through their mobile devices. This allows users to monitor, adjust, and control the unit remotely in real-time.

Users can monitor and control their displays through a mobile phone and a laptop.

*Feature accessible through wired LAN connectivity.

Wide Range of Operating Temperature

The XS4P can be used under a wide range of operating temperature from 0℃ to 40℃.

A display is working well in an environment of 0~40°C.

*Confirmed by LG internal testing, Operating temperature: 0℃~40℃ (without direct sunlight; with direct sunlight in cooling system), 0℃~30℃ (with direct sunlight).

Conformal Coating

The conformal coating with dust protection shields the circuit and power boards from dust, metal particles, moisture, and other contaminants, providing solid durability and long-term reliability.

*Confirmed by LG internal testing.

Upgraded Quite Mode

The XS4P addresses concerns about display noise. It features an Upgraded Quiet Mode that operates at 2,500 nits with minimal fan noise.

The real estate office has two displays installed inside the window. The XS4P model's low fan noise enables smooth communication and conversation even when sitting close to the display.

Convenient Operation

The XS4P features LAN Daisy Chain functionality, enabling the control of multiple displays with a single master remote, offering significant convenience. Moreover, with Wi-Fi, Bluetooth, and Beacon capabilities, content and software can be distributed to the XS4P, allowing store managers to effortlessly provide coupons and information to multiple devices in real-time.

*Exclusively available for 75XS4P.

Users can operate and control their displays through a mobile phone and a laptop.

Professional Content Partners

Pairing the XS4P Series with LG SW solutions would enhance its utilization.

*Sold separately.

Partner content is being utilized to compose the content intended for playback on the signage.

Convenient Installation with Calculated Precision

The XS4P is equipped with a Leveler Tool that shows users the tilt of the device, allowing for precise display installation. Additionally, the Horizontal Sensor Tool assists users in verifying the correct installation direction. The XS4P even provides warning messages for proper installation if it is installed incorrectly.
