Pro:Centric Smart
Cinema Screen
Hybrid Streaming
Pre-Loaded App.
Web Kit & HTML5
Wi-Fi Built-In
Smart Mirroring
Smart Share
DLNA
Key Feature
- Pro:Centric P(Smart)
- Pro:Idiom
- Customizable UI_Web Kit & HTML5
- Web Browser / Pre-Loaded App.
All Spec
VIDEO
XD Engine
Yes
24p Real Cinema (24p 5:5/2:2 Pull down)
Yes
Eye Care (Anti Dazzling)
Yes
AUDIO
Audio Output
10W + 10W
Invisible Speaker
Yes
Clear Voice II
Yes
PANEL SPECIFICATION
Size
55"
Backlight Type
Cinema Screen
Native Resolution
1920 x 1080 (FHD)
Dynamic Contrast Ratio
1,000,000:1
Viewing Angle Degree
178 x 178
INTERFACE(SIDE)
USB (2.0)
2
INTERFACE(REAR)
RF In
1
AV In
1
Digital Audio Out (Coaxial / Optical)
1 (Optical)
HDMI/HDCP Input
3
RGB In (D-sub 15pin) - PC
1
PC Audio Input
1
RS-232C(D-Sub 9pin)
1(SVC, Power outlet 12V)
LAN Port
2
RJ45(RJP interface)
1
External Speaker Out(3.5mm phone jack)
1
TV link Configuration(phone jack type)
1
MPI Port
1
CABINET
Weight (with Stand)
50 lbs.
Weight (Carton)
63.5 lbs.
WxHxD (without Stand)
48.7" x 28.9" x 1.4"
WxHxD (with Stand)
48.7" x 31.6" x 13.5"
WxHxD (Carton)
61.4" x 34.4" x 7.3"
Swivel (angle)
Yes (± 20/45/90°)
Flame Retardent
Yes(Press B/C)
VESA Compatible
400mm x 400mm
POWER
Voltage, Hz
110 ~ 240V, 50/60Hz
Stand-by
< 0.5W
SPECIAL FEATURES
Pro:Centric
Yes
Hybrid Streaming (IP & RF) ※ MultiCast/HTTP Data Carousel
Yes
RF(1/2Tuner)
Yes (2 Tuner)
Preloaded APP.(P:C Smart)
Yes
Web Browser
Yes
HCAP (GEM/FLASH/HTML) ※ Service Carousel (TLX)
GEM / Flash / HTML5
EzManager(Simplicity)
Yes
Remote Diagnosis
Yes
Smart Share
Yes(Smart Share)
DLNA(Movie/Photo/Music)
Yes(W/O DMR)
WiDi
Yes
WiFi Direct
Yes
Simplink(HDMI-CEC)
Yes
HTNG
Yes(1.3)
Pro:Idiom
Yes
Instant ON
Yes
WOL
Yes
SI Compatible (TVLink Protocol)
Yes (MPI protocol)
b-LAN
Yes
WiFi
Yes (Built-in type)
Hotel Mode / PDM / Installer Menu
Yes
IR Out (TV Link Tuner)
Yes (MPI Jack)
External Speaker Out
Yes(Variable/Fixed/Line Out, 3.5mm, Stereo, Single ended Type(GRD,L+,R+), 1W with 8Ω)
RJP Interface
Yes (RJ45, HDMI)
RJP Compatibility
LG,Teleadapt (RJ45, HDMI CEC), G-Link(HDMI-CEC)
PIP
Yes (except HDMI-HDMI, AV-AV)
External Power
Yes (RS-232C, 12V/1.0A)
USB
USB2.0
Moving Picture Playback (SD/HD/Plus HD)
Divx HD
JPEG
Audio Codec
AC3(Dolby Digital), EAC3, AAC, Mpeg, MP3, PCM
USB Cloning
Yes
One Channel Map / Logical Channel Map
Yes(LCM)
Multi IR Code
Yes
Welcome Screen (Splash Image)
Yes
Auto Off / Auto Sleep
Yes
Video Mute
Yes
Smart Energy Saving
Yes
ACCESSORIES
Remote type
S-Con
Cable
Power cable
Manual / ESG
Simple book
REQUIRED LISTINGS(CERTIFIACTION)
Safety
UL
EMC
FCC
ETC.
RoHS, cUL, NOM, Energy Star 6.0
WARRANTY
Warranty
2-Year Limited Warranty (Parts/Labor)
