27.6-inch 16:18 DualUp Monitor with Ergo Stand and USB Type-C™
27.6-inch 16:18 DualUp Monitor with Ergo Stand and USB Type-C™
SDQHD (2560 x 2880) Nano IPS
DCI-P3 98% (Typ.) & HDR10
Ergonomic Stand with C-Clamp
Various Movement of Display
USB Type-C™
Easy Installation
*The images simulated to enhance feature understanding. It may differ from actual use.
*The product images in the video are for illustrational purposes only and might differ from the real product.
DualUp monitor only occupied compact space for one monitor but this 16:18 aspect ratio monitor support, two 21.5-inch monitors (16:9 aspect ratio), at one screen. It enhances work efficiency and productivity at the same time.
*The images simulated to enhance feature understanding. It may differ from actual use.
*Ergo Stand: Extend/Retract 210mm, Swivel ±335°, Pivot 90° (Counterclockwise), Height 130mm, Down Height 35mm, Tilt ±25°
**The product images in the video are for illustrational purpose only and might differ from the real product.
*The images simulated to enhance feature understanding. It may differ from actual use.
*TÜV Rheinland certification ID (Low Blue Light - Hardware Solution): 1111250391.
*The images simulated to enhance feature understanding. It may differ from actual use.
*The images simulated to enhance feature understanding. It may differ from actual use.
LG DualUp Monitor, a new style display of 16:18 aspect ratio, helps to boost efficiency and productivity. You can check more information at a glace within the extended upper and lower space.
*The images simulated to enhance feature understanding. It may differ from actual use.
USB Type-C™
USB Type-C™ port allows from display and data transferring to connected device charging (up to 90W), enabling support for your laptop all at the same time over a single cable.
*To work properly, the USB Type-C™ cable included in the package is required to connect the USB Type-C™ port to the monitor.
*KVM: Keyboard, Video Monitor, and Mouse.
**It can be connected via the USB Type-C™ cable, HDMI cable, and USB2.0 upstream cable included with the package.
**DisplayPort cable is NOT included with the package.
*For detailed installation instructions, see the product manual at LG.com Support page.
*The product images in the video are for illustrational purposes only and might differ from the real product.
Size [Inch]
27.6
Resolution
2560 x 2880
Panel Type
IPS
Aspect Ratio
16:18
Color Gamut (Typ.)
DCI-P3 98% (CIE1976)
Curvature
NO
Refresh Rate (Max.) [Hz]
60
Response Time
5ms (GtG at Faster)
Display Position Adjustments
Tilt/Height/Swivel/Pivot/Extend/Retract
Product name
DualUp
Year
2022
Size [Inch]
27.6
Size [cm]
70.1
Resolution
2560 x 2880
Panel Type
IPS
Aspect Ratio
16:18
Pixel Pitch [mm]
0.18195 x 0.18195
Color Gamut (Min.)
DCI-P3 90% (CIE1976)
Color Gamut (Typ.)
DCI-P3 98% (CIE1976)
Color Depth (Number of Colors)
1.07B
Contrast Ratio (Min.)
700:1
Contrast Ratio (Typ.)
1000:1
Response Time
5ms (GtG at Faster)
Refresh Rate (Max.) [Hz]
60
Viewing Angle (CR≥10)
178º(R/L), 178º(U/D)
Curvature
NO
Brightness (Min.) [cd/m²]
240
Brightness (Typ.) [cd/m²]
300
HDR 10
YES
Dolby Vision™
NO
VESA DisplayHDR™
NO
HDR Effect
YES
Mini-LED Technology
NO
Nano IPS™ Technology
YES
Advanced True Wide Pol.
NO
Color Calibrated in Factory
YES
HW Calibration
NO
Auto Brightness
YES
Flicker Safe
YES
Reader Mode
YES
Color Weakness
YES
Super Resolution+
YES
Motion Blur Reduction Tech.
NO
NVIDIA G-Sync™
NO
AMD FreeSync™
NO
VRR
NO
Black Stabilizer
YES
Dynamic Action Sync
YES
Crosshair
NO
FPS Counter
NO
OverClocking
NO
User Defined Key
YES
Auto Input Switch
YES
RGB LED Lighting
NO
PBP
2PBP
PIP
NO
Smart Energy Saving
NO
Camera
NO
Mic
NO
Others (Features)
Low Blue Light
LG Calibration Studio (True Color Pro)
NO
Dual Controller
YES
OnScreen Control (LG Screen Manager)
YES
LG UltraGear™ Control Center
NO
LG UltraGear™ Studio
NO
D-Sub
NO
DVI-D
NO
HDMI
YES
Thunderbolt
NO
USB-C
YES
Display Port
NO
USB A to B
YES
Remote Controller
NO
Others (Accessory)
DC Extension cable 1.4m Black, Ergo+ stand, Body cable cover, Body top cover, Wrench
D-Sub
NO
D-Sub (Max. Resolution at Hz)
N/A
DVI-D
NO
DVI (Max Resolution at Hz)
N/A
HDMI
YES(2ea)
DisplayPort
YES(1ea)
DP Version
1.4
Thunderbolt
NO
Thunderbolt (Max. Resolution at Hz)
N/A
Thunderbolt (Data Transsmission)
NO
Thunderbolt (Power Delivery)
N/A
USB-C
YES(1ea)
USB-C (Max. Resolution at Hz)
2560 x 2880 at 60Hz
USB-C (Data Transsmission)
YES
USB-C (Power Delivery)
90W
Daisy Chain
NO
USB Upstream Port
YES(1ea/ver2.0)
USB Downstream Port
YES(2ea/ver3.0)
Built-in KVM
YES
LAN (RJ-45)
NO
SPDIF out (Optical Digital Audio Out)
NO
Audio In
NO
Mic In
NO
Headphone out
3-pole (Sound Only)
Line out
NO
Speaker
7W x 2
Bluetooth Conectivity
NO
DTS HP:X
NO
Maxx Audio
YES
Rich Bass
NO
Type
External Power(Adapter)
AC Input
100~240V (50/60Hz)
Power Consumption (Typ.)
40W
Power Consumption (Max.)
190W
Power Consumption (Energy Star)
28.31W
Power Consumption (Sleep Mode)
Less than 0.5W
Power Consumption (DC Off)
Less than 0.3W
Display Position Adjustments
Tilt/Height/Swivel/Pivot/Extend/Retract
Wall Mountable [mm]
100 x 100
Dimension with Stand (W x H x D) [mm]
481.5 x 843.2 x 461.3
Dimension without Stand (W x H x D) [mm]
481.5 x 549.5 x 44.9
Dimension in Shiping (W x H x D) [mm]
745 x 240 x 557
Weight with Stand [kg]
9
Weight without Stand [kg]
4.3
Weight in Shipping [kg]
13.2
