Display Technology
0.7 DMD
Native Resolution
XGA(1024x768)
Brightness(ANSI-Lumens)
4000
Contrast Ratio (FIFO)
2800:1
Noise (dB)
High Brightness: 32, Economic: 30
Uniformorty(min)JBMA
>90%
Colour wheel
4 segment(RGBW)
Projection Lens
Focus: Manual, Zoom: Manual 1.2x
Projection Image
Screen Size: 40~300inch, Standard: 100inch 3.2m, Throw Ratio: 1.569
Projection Offset
1
Lamp Power (W)
300W
Lamp life (hours)
2500
Menu Language
Korean/ English / French/ Spanish/ German/ Italian/ Swedish /Portuguese / Chinese Simplified/ polski/ Brazilian Portuguese
Aspect Ratio Control
Native 4:3, Support 16:9
Dimension (mm)
346 x 263 x 109
Weight (kg)
4.5
Power Consumption (W)
100Vac : 380, 240Vac : 350 Stand-By 5 under
Power Supply
AC 100~240V(Free Voltage), 50/60Hz
Input Signal Compatibility
Digital(DVI,HDMI): 1080i/720p/576p/480p, up to SXGA+(1400x1050@60Hz), RGB: 1080i/720p/576p/480p, up to SXGA+(1400x1050@60Hz), Component Video: 1080i/720p/576p/576i/480p/480i, Composite Video (incl. S-Video): NTSC-M/NTSC 4.43/PAL/PAL-M/PAL-N/SECAM
RGB Input
1xRGB in
RGB Output
1xRGB out
Video Input
1xS Video, 1xComposite, 1xComponent(thru RGB), 1xRS-232C
Digital
HDMI: No, 1xDVI
USB
1xUSB(Type B/SVC)
Digital Keystone Correction
Yes
Picture Still
Yes
Quick Power on/off
Yes
Auto Sleep
Yes
Smart Picture Mode
Yes
Presentation Timer
Yes
Brilliant Color™
Yes
Expert control (RGBCMY Gain/Sat/Hue Adjustment)
Yes
VIDI™
Yes
Cabinet Color
Silver
Power code
Yes
Cable
Power code, D-sub 15 pin cable
Remote control
Yes
Quick setup Guide
Yes
Lens Cap
Yes
CD Manual
Yes
AAA * 2EA Battery
Yes
