STANDARD PREMIUM 49LS75C/73C SERIES

Quad Core SoC*

Built into this signage display is a Quad Core Processor. This is the engine behind the webOS display platform that allows fast loading of apps and menu's, as well as multi-tasking between the apps. The result, quick access to content and smooth playback.
*SoC: System-on-Chip

webOS 3.0

With webOS 3.0 you can build apps and construct your own customised signage solutions using the LG Software Development Kit (SDK) and display logos during screen idle time (i.e. boot up, lost signal).

Group Manager

Content can be created, distributed and controlled by a signage without a dedicated PC or server.

PBP (Picture-By-Picture) / PIP (Picture-In-Picture)

PBP (Picture-By-Picture) and PIP (Picture-In-Picture) features enable you to compose various layouts for several digital devices.

IP Streaming Protocol

Various types of IP video streaming protocol are supported, such as RTSP/RTP, MMS, HLS and MPEG-2 TS*.

Secure Communication Protocol

By supporting HTTPS* protocol, communication between server and signage is more secure.

Proxy Server

Web access speed and security can be improved by supporting Proxy Server (A server that acts as an intermediary for requests from clients seeking resources from other servers.)

Mirroring

This signage has built in Wi-Fi and the ability to mirror your Miracast enabled smartphone's screen, so you can share content on a Wi-Fi network.

Soft AP

With SoftAp, the LS75C/LS73C signage can operate as a wireless access point for SoftAp enabled mobile devices.

Simple Installation

Installation has been simplified by removing the external media player and Ethernet/RS232C cables.

BEACON

With BEACON and Bluetooth Low Energy (BLE) supported by LS75C/LS73C*, retail stores can provide coupons and information in real time. When Wi-Fi dongle is connnected, the BEACON is available.

* LS75C/LS73C is enhanced to support iBEACON** and Eddystone***
** iBEACON: Bluetooth Low Energy BEACON profile released by Apple in 2013
*** Eddystone: Bluetooth Low Energy BEACON profile released by Google in 2015

Slimmer Even Bezel & Depth

The thinner bezel & depth allows a perfect fit for a sleek look.

Detachable Logo

Portrait mode allows the logo to be positioned in the desired setting.

PANEL

Screen Size

49" (123cm)

Panel Technology

IPS
Aspect Ratio

16:9

Native Resolution

1920 x 1080 (Full HD)
Brightness

700cd/m2 (LS75C), 500cd/m2 (LS73C)

Contrast Ratio

1,300:1
Dynamic CR

N/A

Viewing Angle (H x V)

178° x 178°
Surface Treatment

Hard coating (3H), Anti-glare treatment of the front polariser (Haze 10%)

Life Time

50,000 Hrs min.
Orientation

Portrait and Landscape

CONNECTIVITY

Input

HDMI (2), DP, DVI-D, Audio in, OPS

Output

DP, External Speaker out
External Control

RS232C in/out, RJ45, IR / Light sensor, Pixel sensor, USB 3.0

PHYSICAL SPECIFICATION

Bezel Colour

Black

Bezel Width

7.4 mm (T/L/R/B even)
Monitor Dimension(W x H x D)

1095mm x 637mm x 32mm

Weight (head)

15.6kg
Carton Dimensions(W × H × D)

1,095 x 700 x 298 mm

Packed Weight

18.7kg
VESA™ Standard Mount Interface

400mm x 400mm

SPECIAL FEATURES

Additional

Temperature sensor, Auto brightness sensor, Tile Mode, DPM select, DPM wake up, Energy saving, Smart energy saving, File play with USB, PIP/PBP(2), Internal memory 16GB (System 4GB + Available 12GB), Wi-Fi dongle ready (802.11n) , USB cloning, Fail over

ENVIRONMENT CONDITIONS

Operation Temperature

0°C to 40°C

Operation Humidity

10% to 80%

POWER

Power Supply

100-240V~, 50/60Hz

Power Type

Built In Power
Power Consumption (Typ./Max)

125 W (TBD)

Power Consumption (Smart Energy Saving)

90 W (TBD)

STANDARD(CERTIFICATION)

Safety

AS/NZS 60950, CB Scheme

EMC

AS/NZS CISPR 22, RCM (Class A)
Energy Rating

N/A

MEDIA PLAYER COMPATIBILITY

OPS Type Compatible

Yes

External Media Player Attachable

Yes (MP500/MP700)

SOFTWARE COMPATIBILITY

SuperSign W/Lite

Yes

SuperSign C

Yes
Interactive White Board S/W

N/A

ACCESSORY

Accessory

Remote controller (2ea batteries included), Power cord, IR/Light sensor receiver, QSG, Regular book (depend on regional standard), HDMI cable

Optional

SP-2100 (External speaker), ST-200T, LSW440S, AN-WF500 (Wi-Fi USB dongle), KT-OPSA (OPS kits), KT-SP0 (Pixel sensor)
