55" Outdoor Display
All Spec
ACCESSORIES
Basic
Remote Controller, Manual (EIG, ESG), Regulation Book, Phone to RS232C Gender, USB Cable, HDMI Cable
Optional
Enclosure Stand (ST-550X)
CONNECTIVITY
Input
HDMI, DP, DVI-D, Audio In, USB 3.0, SD Card
Output
DP, External Speaker out
External Control
RS232C In/out, RJ45 In
ENVIRONMENT CONDITIONS
Operation Temperature
-30°C to 50°C
Operation Humidity
5% to 100%
Dust / Water Proofing
IP56
PANEL
Screen Size
55“ (139cm)
Panel Technology
IPS
Aspect Ratio
16 : 9
Resolution
1,920 x 1,080 (FHD), M+ (WRGB)
Brightness (only Typ.)*
3000cd/m2 through front protective glass* With Front Protective Glass
Viewing Angle (H x V)
178 x 178
Response Time
9 ms (G to G BW, Typ.)
Surface Treatment
AGLR(Haze 3%), QWP
QWP Polarizer
Yes
Life time
50,000 Hrs
Operation Hours
24Hrs
Orientation
Landscape & Portrait
PHYSICAL SPECIFICATION
Front glass
7.5 mm (AR, Tempered & Laminated Glass)
Bezel Colour
Black
Bezel Width
66.4 mm (T/B), 31.0 mm (L/R)
Monitor Dimension (W x H x D)
745.3 x 1,345.4 x 160.0 mm
Weight (Head)
70 kg
Monitor with Optional Stand Dimensions (W x H x D)
745.3 x 1,877 x 420 mm
Weight (Head+Stand)
103.5 kg
Packing Dimensions (W x H x D)
1,027 x 1,491 x 309 mm
Packed Weight
100.5 kg
POWER
Power Supply
100-240V~, 50/60Hz
Power Type
Built-In Power
Power Consumption (Typ. / Max.)
350 W / 500 W
Power Consumption (Smart Energy Saving)
178 W
SOFTWARE COMPATIBILITY
Content Management Software
SuperSign CMS
Control and Monitoring Software
SuperSign Control/Control+
SPECIAL FEATURES
SPECIAL FEATURES
Temperature Sensor, Auto Brightness Sensor, Pixel Sensor, Cooling FAN, ISM Method, DPM Select, Energy Saving, Smart Energy Saving, File Play with USB, Internal Memory 8GB (System 4GB + Available 4GB), USB Cloning, Easy Brightness Control, Wake on LAN, Fail Over, DP Daisy Chain, Control Manager
STANDARD(CERTIFICATION)
Safety
AS/NZS 60950,CB Scheme
EMC
AS/NZS CISPR32,RCM(Class A)
