All Spec
ACCESSORY
Accessory
Remote Controller (include 2ea batteries), Power Cord, QSG, DP 1.8M, Regulation Book, Phone to RS-232C Gender, Memory Cover
Optional
Pixel Sensor (KT-SP0), Media Player, OPS Kit (KT-OPSA), HDBaseT (EB-B100)
CONNECTIVITY
Input
HDMI, DP, DVI-D, Audio, USB 3.0, SD Card
Output
DP, Audio
External Control
RS-232C, RJ45, IR Receiver, Pixel Sensor
ENVIRONMENT CONDITIONS
Operation Temperature
0°C to 40°C
Operation Humidity
10% to 80%
MEDIA PLAYER COMPATIBILITY
OPS Type Compatible
Yes
External Media Player Attachable
Yes (MP500 / MP700)
PANEL
Screen Size
75" (189cm)
Panel Technology
IPS
Aspect Ratio
16:9
Native Resolution
3,840 x 2,160 (UHD)
Brightness
500cd/m²
Contrast Ratio
1,200:1
Dynamic CR
4,000,000:1 (DTV Label only)
Viewing Angle (H x V)
178° x 178°
Response Time
6ms (G to G)
Surface Treatment
Low Haze 3%
Life Time
50,000 Hrs
Operating Hours
24 Hrs
Orientation
Portrait and Landscape
PHYSICAL SPECIFICATION
Bezel Colour
Black
Bezel Width
14.9mm
Monitor Dimension(W x H x D)
1,682 x 960 x 58 mm (without logo / handle)
Weight (Head)
41.5kg
Carton Dimensions(W × H × D)
1,816 x 1,123 x 228mm
Packed Weight
49.5kg
VESA™ Standard Mount Interface
600 x 400mm
POWER
Power Supply
100-240V~, 50/60Hz
Power Type
Built In Power
Power Consumption (Typ.)
240W
Power Consumption (Smart Energy Saving)
170W
SOFTWARE COMPATIBILITY
SuperSign W/Lite
Yes
SuperSign C
Yes
SPECIAL FEATURES
Additional
Temperature Sensor, Auto Brightness Sensor, Tile Mode (up to 15x15), Natural Mode@Tile Mode, ISM Method, Internal Memory (8GB, System 4GB), Wi-Fi built-in (802.11n), USB Cloning, Content Scheduling, Sync mode, PM mode, Fail Over, Wake on LAN, BEACON (On/Off), Embedded Template, PIP/PBP (2/3/4)
STANDARD(CERTIFICATION)
Safety
AS/NZS 60950, CB Scheme
EMC
AS/NZS CISPR 22, RCM (Class A)
Energy Rating
N/A
whitePaper
To access more technical documentation and resources, please visit the LG B2B partner portal.
